- Page 1 HUMIDIFIER HU-15OG USER MANUAL 02-03-2016 version 1.7...
- Page 2 HU-15OG Contronics Engineering B.V., Ambachtsweg 8, 5492 NJ Sint-Oedenrode, The Netherlands, hereby declares that product HU-15OG, produced and delivered by Contronics Engineering B.V., is in accordance with the following CE directives: EMC-Directive : 2014/30/EU Directive for low-voltage electrical installation : 2014/35/EU...
-
Page 3: Table Of Contents
HU-15OG Table of contents 1. PREFACE ��������������������������������������������������������������������������������������������������������� 4 2. INTRODUCTION ��������������������������������������������������������������������������������������������� 5 3. SAFETY REGULATIONS ������������������������������������������������������������������������������ 6 4. PACKING ���������������������������������������������������������������������������������������������������������� 6 5. CONNECTIONS AND FUNCTIONS ����������������������������������������������������������� 7 6. INSTALLATION INSTRUCTIONS ���������������������������������������������������������������� 8 7. ELECTRICAL CONNECTIONS �������������������������������������������������������������������� 9 8. WATER CONNECTIONS AND FLUSHING CYCLE ������������������������������� 10 9. -
Page 4: Preface
Through the construction, flushing programme and materials used, Contronics has ensured that the stimulation of bacterial growth is kept to the absolute minimum. In order to ensure the supply of pure water, it is strongly recommended that demineralised water is used (see the Contronics product range). -
Page 5: Introduction
This will also prevent certain substances that are contained in tap water, such as calcium, salts, minerals and bacteria, ending up in the area to be humidified. Contronics has various filters available in its product range, operating on the basis of reverse osmosis. -
Page 6: Safety Regulations
2 minutes afterwards. Ensure that the water is always discharged via the outlet and ensure that this is never blocked. The humidifier may only be dismantled by authorized Contronics technicians. 4. PACKING The HU is delivered in recyclable packaging that should be kept for re-shipping the unit for maintenance activities. -
Page 7: Connections And Functions
HU-15OG 5. CONNECTIONS AND FUNCTIONS Figure 1 Connections and functions 1. Water supply 3/4”, min. 1 bar / max. 6 bar. 2. Water discharge 15 mm free passage. 3. Display. 4. LED indication (blue) constant for adjustment of the capacity. (Flashing --> ozone) 5. -
Page 8: Installation Instructions
HU-15OG 6. INSTALLATION INSTRUCTIONS IMPORTANT The guarantee will become void if the humidifier is installed incorrectly or if it is handled in an improper manner. Air outlet > 75 cm Length < 50 cm Diameter > ½” R.O Unit 230 VAC... -
Page 9: Electrical Connections
HU-15OG 7. ELECTRICAL CONNECTIONS Supply voltage (230V AC ± 10%) Ensure there is an earthed wall socket next to the humidifier. If necessary, connect it in parallel to any external ventilators. This will ensure that the ventilators and the humidifier switch on and off simultaneously. -
Page 10: Water Connections And Flushing Cycle
The HU-15OG is provided with protection. This protection starts to work when the water supply is closed off or does not work. The water valve is then closed to prevent damage to the water valve. -
Page 11: Air Connections
HU-15OG Standard cycle The humidifier’s “flushing/alarm” LED will light up every hour. The device will start the flushing cycle: The fogging will stop. The water tank will be flushed for approx. 15 seconds (depending on the water pressure). The water will be discharged. - Page 12 HU-15OG Start up and functional test Open the water valve Set the % RH knob on maximum position Switch on the power and check if: a. The water runs to the humidifier. b. The water flow stops after about 60 seconds.
-
Page 13: Ozone Generator
A programmable timer has been incorporated in the humidifier for switching the ozone generation on and off. Contronics sets this timer to a default setting of 2 hours of ozone generation between 2.00 a.m. and 4.00 a.m. while the humidification is switched off. -
Page 14: Maintenance
HU-15OG 12. MAINTENANCE IMPORTANT All maintenance must be carried out by Contronics or by an organisation authorized by Contronics. Regular maintenance is important for the optimum operation of the humidifier and to maintain hygiene. The yearly maintenance of the water reservoir will depend on the quality of the water and the purity of the air that is sucked in. -
Page 15: Replacing Spare Parts
Remove ceramic plate from the holder. 14. REPLACING SPARE PARTS Replacing the transducers The replacement of the transducers can only be done by Contronics or representatives authorised by Contronics. 15. APPLICATIONS OF THE HUMIDIFIER Various information sheets and drawings are available covering different applications. -
Page 16: Menu Overview
HU-15OG 16. MENU OVERVIEW Settings Scroll to the desired setting using the button. Press to confirm the selection. Scroll using the button to <<<<. Press to leave the menu. Screen display after switching on: The current status will be displayed on the screen after the mains voltage has been switched on. - Page 17 HU-15OG Information Capacity mode Not activated No water OG settings ̶̶ ̶̶ ̶̶ ̶̶ ̶̶ ̶̶ ̶̶ ̶̶ ̶̶ ̶̶ ̶̶ ̶̶ ̶̶ ̶̶ ̶̶ ̶̶ ̶̶ ̶̶ ̶̶ ̶̶ ̶̶ ̶̶ ̶̶ ̶̶ ̶̶ ̶̶ ̶̶ ̶̶ ̶̶ ̶̶ ̶̶ ̶̶ ̶̶ ̶̶ ̶̶ ̶̶ ̶̶ ̶̶ ̶̶ ̶̶ Time settings ̶̶ ̶̶ ̶̶ ̶̶ ̶̶ ̶̶ ̶̶ ̶̶ ̶̶ ̶̶ ̶̶ ̶̶ ̶̶ ̶̶ ̶̶ ̶̶ ̶̶ ̶̶ ̶̶ ̶̶ ̶̶ ̶̶ ̶̶ ̶̶ ̶̶ ̶̶ ̶̶ ̶̶ ̶̶ Start 1 ̶̶...
-
Page 18: Factory Setting And Range
HU-15OG 17. FACTORY SETTING AND RANGE Parameter Max. Min. Factory Unit setting OG settings Time settings Start 1 23.59 00:00 02:00 hours-min. Stop 1 23.59 00:00 04:00 hours-min. Start 2 23.59 00:00 00:00 hours-min. Stop 2 23.59 00:00 00:00 hours-min. -
Page 19: Malfunctions
HU-15OG 18. MALFUNCTIONS... -
Page 20: Technical Specifications
HU-15OG 19. TECHNICAL SPECIFICATIONS HU-15OG Transducer frequency 1,7 MHz Maximum capacity 0-0,5 kg/hour (adjustable) Service life of the transducers 10.000-20.000 hours Size of the water droplets 1-3 micron Diameter of outlet flange 1 x 40 mm Diameter of suction flange... - Page 21 HU-15OG DISCLAIMER Contronics works continuously on the further development of its humidifiers. We therefore reserve the right to modify the design, construction and technology of the product at any time. For this reason, no claims can be made based on the data, illustrations and description in this user manual.
- Page 22 HU-15OG...
- Page 23 HU-15OG...
- Page 24 HU-15OG P.O. Box 144 5490 AC Sint-Oedenrode The Netherlands Telephone: +31(0)413-487000 Telefax: +31(0)413-473903 Website: www.contronics.nl E-mail: info@contronics.nl...
