All the below illustrating pictures are for reference only.
M7 Complete User Manual
(Applied to FW1.0.4 or later)
Foreword:
Thank you for purchasing FiiO's high resolution lossless music player M7. To
let you better utilize the M7 to enjoy high-quality music, we have prepared this
complete user manual. We hope this manual will help you get to know the M7 and
unleash its full potential.
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Fiio M7
Summary of Contents for Fiio M7
- Page 1 Thank you for purchasing FiiO’s high resolution lossless music player M7. To let you better utilize the M7 to enjoy high-quality music, we have prepared this complete user manual. We hope this manual will help you get to know the M7 and unleash its full potential.
-
Page 2: Table Of Contents
............25 2. How can I access the micro SD card after connecting the M7 to the computer? ..... 25 3. What kind of Bluetooth codec does the M7 support? Why there's no change after changing the codec setting? ................ - Page 3 10. Can I install any third-party apps on the M7? ........... 26 11. How to upgrade the M7? ............. 26 12. How to set the date and time on the M7? ..........26 13. Does M7 support USB audio out? ............26...
-
Page 4: Introduction
●Introduction: The M7 is a high fidelity, high resolution digital audio player, using Samsung 14nm Exynos 7270, Dual AK4490EN DACs, 2GB native memory, and support external Micro SD Card storage (512GB) , 480* 800 LG IPS screen, supporting multi-touch. The Type C interface supports charging, file transfer, USB Audio output; Bluetooth 4.2 supports SBC/ aptX/ aptX-HD/ LDAC/HWA;... -
Page 5: Buttons And Ports Explained
2) Power / Lock: While M7 is powered off, hold for 2s to turn on; while powered on, hold to display power off / reboot menu; press briefly while powered on to turn screen on / off; Press and hold for 10 seconds to reboot. -
Page 6: Main Menu Display
Tap the Bluetooth in setting as shown in the picture below; 2) If Bluetooth on the M7 is off, turn it on by clicking the switch on the upper right to the “ON” position on the right;... - Page 7 Refresh to search Bluetooth Before connecting Bluetooth device, you can select the Bluetooth audio codec which you want to use as follows: 1) Enter the Settings-Audio settings interface 2) Click on the Wireless Playback quality, select the one you want to use, then disconnect the current connection and connect with your Bluetooth device again.
-
Page 8: Bluetooth Receiver
2. When you turn on the Bluetooth , M7 will automatically connect to the latest available device. Bluetooth receiver When M7 is connected to a new Bluetooth device (such as the mobile phone) as a Bluetooth receiver, turn on the "Bluetooth decoding amp mode" in the Bluetooth settings interface, then the Bluetooth will turned off automatically, turn on the Bluetooth again and you are in Bluetooth receive mode now! (It only supports SBC now, and will support LDAC in the future.) -
Page 9: Audio
Disconnect ●Audio 1. Select output: Switch the output PO/LO; between 2. Balance: Set the Balance between the left and right channels of PO (headphone output). From being biased leftmost (L10) through centre (0) to rightmost (R10), there are 21 settings available. -
Page 10: In-Line Remote
Response to in-line remotes on connected headsets may be enabled or disabled by your choice. 4. USB DAC: Check “USB DAC” and connect the M7 with computer via USB cable. (If you’re using Windows system, please install the driver at https://www.fiio.com/supports; MAC system doesn’t need to install the DAC driver. -
Page 11: Fm Radio
●FM radio 1) Tap FM radio icon on the Main menu to enter the FM radio operation interface. The headphones are required to plug in M7 firstly for listening the radio. -
Page 12: Firmware Update
Here is the steps of upgrading the M7： 1. Download the firmware from FiiO official website, such as “M7-ota-1.0.4.zip” ,and copy this firmware file to the root directory of your micro SD. Note that the file should not be unzipped, and you are recommended not to modify the file name. -
Page 13: Language Setting
3. Press “confirm" button on the prompt window, and then M7 will be rebooted and the update will be completed automatically. Attention 1. Please ensure the battery power is more than 30%, or the device is connected to a power supply. -
Page 14: Key-Lock Settings
●Key-lock Settings You can choose the buttons/knob you want to be available when the screen is off. -
Page 15: General
Power-off timer includes two categories, namely “Sleep” and “Idle power off”: Sleep: once the pre-set power-off time is expired, M7 will power off automatically, no matter whether it is playing or not. The power-off time can be set to any value between 0 to 120 minutes. By default the sleep... -
Page 16: Brightness Level
Idle power off: once the pre-set power-off time is expired and no operation is performed during the time period, M7 will power off automatically. The timer can be set to any value between 0 to 50 minutes. By default the sleep power off is turned off, and it will restore to the default settings once the power-off time is expired. -
Page 17: Factory Data Reset
In Sleep mode, M7 would have low power consumption. To short press the Power button can wake up M7 from Sleep mode. ●Factory data reset “Factory data reset” will clean all the user data in memory and restore to the original default settings. -
Page 18: Technical Support
Firmware update：you can select a local package to update the M7’s firmware; FAQ: List the solutions for some FAQ; Quick start guide: tap to view the quick start guide for the M7. ●FiiO Music The M7 comes with the FiiO Music app, a music playing application that has been highly... -
Page 19: App Homepage
M7 and tailored to the usage needs of advanced music enthusiasts. On first launch of FiiO Music, an illustration of the guide to the app will appear. Below is the introduction of FiiO music app. - Page 20 Settings: tap the icon to go to app settings options; Return to desktop: tap the icon to return to main screen; Playing page: tap the icon to jump to playing page; Recently played: Lists your recently played songs according to the time it is played; Most played: Lists your most popular songs according to playback frequency;...
-
Page 21: Quickly Locate All Music
2. Quickly locate all music When the list is ordered by alphabet (tap the blue circle to the lower right and select the “A->Z” option), you can slide your finger over the alphabet list to the right of the screen and quickly jump to the part of the list that starts with the selected letter. -
Page 22: Function Menu
4. Function menu Tap the shortcuts icon of function menu, the following functions can be performed. Selected sort order: sort by added time, sort by first letter, sort by filename. Bulk management: batched playback, batched adds to my favorite, batched add to playlist, batched delete, exit batch operation 5. -
Page 23: Tap Buttons
The tap buttons from top to bottom on the playing screen: 1) Return: return to Original path 2) Search: Tap to show a full screen search pane for all songs on the M7. Searching for track title, album name and artist name are supported. Recent searching history is saved;... - Page 24 8. EQ FiiO Music has built-in a graphic equalizer. One may choose between the given genre presets directly, or adjust the ten frequency bands from 20 to 20kHz independently from -6 to +6 dB, thus satisfying your personalized listening needs.
-
Page 25: M7 Faq
3) Reset EQ: Tap the reset button at the upper right corner to reset the present EQ preset to its genre default. Note: If a factory reset is performed on the M7, all EQ settings will be reset to defaults. ●M7 FAQ 1. -
Page 26: What Should I Do If The System Crashes Or Freezes
13. Does M7 support USB audio out? A: Yes. But currently it can only guarantee the stable connection with FiiO Q1 Mark II, Q5 or Chord Mojo (this requires the exclusive Type C to Micro USB cable from FiiO, the CL06).
