Chapter 2 TBC1-1VDSL1SFP Expansion Card

This manual focuses on the TBC1-1VDSL1SFP expansion card.
The SFP (Small Form-Factor Pluggable ) interface provides connectivity to a single Gigabit Ethernet device or to a
network, allowing clients to use different SFPs for special requirements such as distance, cost, existing infrastructure
or future expansions.
VDSL2 stands for Very high bit rate Digital Subscriber Line version 2, which is defined in theITU G.993.2 standard.
VDSL2 has evolved from the ADSL/ADSL2/ADSL2+ technologies and the main differences areas follows:
For further information on ADSL and VDSL technologies, please see the Teldat- Dm741-I ADSL-VDSL manual.
TBC1-1VDSL1SFP card
Fig. 1:

2.1 TBC1-1VDSL1SFP expansion card: Characteristics

The main characteristics of the TBC1-1VDSL1SFP expansion card are as follows:
TBC1-1VDSL1SFP card: SFP characteristics
Ports
Standards
Types
Speed
TBC1-1VDSL1SFP card: xDSL Characteristics
Ports
ADSL
Standards
TBC1-1VDSL1SFP card
• Upstream and downstream channel multiplicity.
• Supports up to 200 Mbps, symmetric (profile 30a).
• It only uses FDM mode, EC mode is not defined (echo cancellation or carrier
overlapping).
• Allows for a new encapsulation to be used: PTM.
• Multiple link diagnostics.
1 SFP Gigabit Ethernet port.
IEEE
• 802.1Q (VLAN).
• 1000-Base-X.
• LX/LH (single-mode 1310 nm).
• SX (multi-mode 850 nm).
• ZX (single-mode 1550 nm).
1000 Mbps full duplex.
One RJ-11 VDSL/ADSL port
ANSI:
