3 Installing the TBC1-1VDSL1SFP expansion card

Chapter 3 Installing the TBC1-1VDSL1SFP expansion card

This chapter provides information on how to install and uninstall the TBC1-1VDSL1SFP expansion card in Teldat M/
iM routers.
This information includes:

3.1 Requirements prior to installation

To configure the card, you must be able to access the Teldat M/iM router through a console or a Telnet connection.
For further information, please see the Connecting for configuration section under the Teldat-Dm569-I Teldat M1 In-
stallation manual.
For the TBC1-1VDSL1SFP expansion cards to operate properly, you need to load the appropriate firmware file for
each card into the router.
If the firmware has not been loaded in the device prior to installing the card, you'll still be able to find out what firm-
ware file you need.

3.1.1 Determining the firmware file

There are two options to determine the firmware file needed for the installed xDSL card:
3.1.1.1 FTP quote site listfirmwares command
The FTP command quote site listfirmwares returns a list containing the names of the firmware files needed for the
device to operate properly:
ftp> quote site listfirmwares
211 fw000013.bfw
ftp>
3.1.1.2 FTP system firmwares-required monitoring command
The system firmwares-required monitoring command displays the same information as the previous command, but
in the local console:
+system firmwares-required
List of required firmwares for detected hardware
------------------------------------------------
Filename
------------- ---------------------------- ---------------
fw000013.bfw
+
Once the necessary firmware file has been detected, load it into the device through an FTP connection.
For further information on how to load firmware files in the router, please see the Teldat-Dm 748-I Software Updating
manual.

3.2 Installing or replacing the TBC1-1VDSL1SFP expansion card.

To install or replace a TBC1-1VDSL1SFP card, please see the Expansion Slot section under the Teldat-Dm569-I
Teldat M1 Installation manual.
6
• Requirements prior to installation.
• Installing or replacing a TBC1-1VDSL1SFP expansion card.
Description
Broadcom 63268 TSS-mode
Version/Subv
v3.1
Teldat S.A.
TBC1-1VDSL1SFP card
