HOLMAN FINAL TOUCH FINISHING OVENS (MODEL FT1(W), FT2(W)
HEAT AND HOLD OVENS (MODELS HH1(W), HH2(W)
AND GARLIC BREAD TOAST AND HOLD OVEN (MODEL FT2BH(W)
HH1, HH2
F\USERS\BOB\MANUAL\VAMANUAL\FT2VA.DOC
HGO107
OPERATORS MANUAL
(For Service Information Call: 800-225-3958)
TABLE OF CONTENTS
DRAWINGS
WIRING DIAGRAMS
PAGE 1
PAGE 1
PAGE 1
PAGE 1
PAGE 2
PAGE 2
PAGE 3 & 4
PAGE 5
PAGE 7
PAGE 6
PAGE 5
PAGE 8
PAGE 9
PAGE 10
REV 07/20/00 RRD
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Holman FT1W
Summary of Contents for Holman FT1W
-
Page 1: Table Of Contents
90 INDUSTRIAL PARK ROAD, SACO, ME/U.S.A. 04072 (207) 282-1589 800-225-3958 FAX (207) 282-6283 OPERATORS MANUAL HOLMAN FINAL TOUCH FINISHING OVENS (MODEL FT1(W), FT2(W) HEAT AND HOLD OVENS (MODELS HH1(W), HH2(W) AND GARLIC BREAD TOAST AND HOLD OVEN (MODEL FT2BH(W) (For Service Information Call: 800-225-3958) -
Page 2: Uncrating And Inspection
NEMA 5-15 plug for plug in installation in a grounded 120 Volt outlet. Model FT2BH is furnished with a 4 foot cord and NEMA 6-20 plug. Your HOLMAN oven should be the only appliance connected to the electrical line and should have its own fuse or breaker in the electrical box. -
Page 3: Cooking Procedures
PAGE 2 OPERATORS MANUAL HOLMAN FINAL TOUCH FINISHING OVENS (MODEL FT1(W), FT2(W) HEAT AND HOLD OVENS (MODELS HH1(W), HH2(W) AND GARLIC BREAD TOAST AND HOLD OVEN (MODEL FT2BH(W) OPERATION A. Turn switch on. Panel light comes on; fan motor is activated; inferred radiant heaters are now at 1/4 power (total of 300 watts in FT1 and HH1;... -
Page 4: Trouble Shooting Guide
PAGE 3 OPERATORS MANUAL HOLMAN FINAL TOUCH FINISHING OVENS (MODEL FT1(W), FT2(W) HEAT AND HOLD OVENS (MODELS HH1(W), HH2(W) AND GARLIC BREAD TOAST AND HOLD OVEN (MODEL FT2BH(W) TROUBLE SHOOTING GUIDE CAUTION - ALWAYS DISCONNECT UNIT FROM POWER SOURCE BEFORE SERVICING A. - Page 5 2. Check to see if the air intake area (louvers in left side panel) is free of dust, grease or other obstructions. 3. If no obstruction to the air intake can be found, call the Holman Cooking Equipment Department for assistance (the toll free number is on the unit).
-
Page 6: Maintenance Procedures
PAGE 5 OPERATORS MANUAL HOLMAN FINAL TOUCH FINISHING OVENS (MODEL FT1(W), FT2(W) HEAT AND HOLD OVENS (MODELS HH1(W), HH2(W) AND GARLIC BREAD TOAST AND HOLD OVEN (MODEL FT2BH(W) MAINTENANCE PROCEDURES A. REPLACING HEATER TUBES (See below) 1. DISCONNECT UNIT FROM POWER SOURCE. -
Page 7: Left Side Exploded View
PAGE 6 OPERATORS MANUAL HOLMAN FINAL TOUCH FINISHING OVENS (MODEL FT1(W), FT2(W) HEAT AND HOLD OVENS (MODELS HH1(W), HH2(W) AND GARLIC BREAD TOAST AND HOLD OVEN (MODEL FT2BH(W) (Maintenance procedures cont.) 7. Using the same four screws, secure new fan motor to side panel and fan grill in the same manner as the old motor. -
Page 8: Parts List
PAGE 7 OPERATORS MANUAL HOLMAN FINAL TOUCH FINISHING OVENS (MODEL FT1(W), FT2(W) HEAT AND HOLD OVENS (MODELS HH1(W), HH2(W) AND GARLIC BREAD TOAST AND HOLD OVEN (MODEL FT2BH(W) PART # QTY. PAGE # DESCRIPTION 200543 ON/OFF Switch 200731 Timer, 6 minute... - Page 9 115383 CONTACTOR MUST BE FIXTURED AND WIRED AS SHOWN MODELS: FT1 120/220/240V, 60Hz, 2 Tube FT2 120/220/240V, 60Hz, 2 Tube STAR MANUFACTURING INTERNATIONAL INC. THIS DRAWING CONTAINS INFORMATION CONFIDENTIAL TO STAR MFG. INT'L. INC. 030037 Rev - 4/05/2000 NO REPRODUCTION OR DISCLOSURE OF ITS CONTENTS IS PERMITTED.
-
Page 10: Ft2Bh
TOP HEAT MODELS: FT1 240V, 50Hz, 4 Tube, w/Timer FT2BH 208/240V, 60Hz, 4 Tube, w/Timer FT2BH 220V, 50Hz, 4 Tube, w/Timer HH1, 220V, 60Hz, 4 Tube, w/Timer HH2, 208/220/240V, 60Hz, 4 Tube, w/Timer HH2, 220V, 50Hz, 4 Tube, w/Timer, CE STAR MANUFACTURING INTERNATIONAL INC. - Page 11 115383 CONTACTOR MUST BE FIXTURED AND WIRED AS SHOWN MODELS: FT2NT, FT2WNT 120/, 60Hz, 2 Tube, NO TIMER STAR MANUFACTURING INTERNATIONAL INC. THIS DRAWING CONTAINS INFORMATION CONFIDENTIAL TO STAR MFG. INT'L. INC. 030065 Rev - 4/05/2000 NO REPRODUCTION OR DISCLOSURE OF ITS CONTENTS IS PERMITTED.
- Page 12 STAR MANUFACTURING 10 Sunnen Drive, St. Louis, MO 63143 U.S.A. (800) 807-9054 (314) 781-2777 Parts & Service (800) 807-9054 www.star-mfg.com...
