American Bus Video SD4HD User Manual

Mobile video solutions
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
SD4HD, SD4HW, SD4HC
(Mobile Video Solutions)
User Manual
May 1, 2016 Version 1.1
American Bus Video Inc.
sales@AmericanBusVideo.com
AmericanBusVideo.com
DriverSafetyCameras.com
FleetDriverRiskManagement.com
770.263.8118
29 Years of Fleet Driver Safety System Sales & Service Experience
All Rights Reserved. © American Bus Video Inc. 2016

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SD4HD and is the answer not in the manual?

Questions and answers

Related Manuals for American Bus Video SD4HD

Summary of Contents for American Bus Video SD4HD

  • Page 1 SD4HD, SD4HW, SD4HC (Mobile Video Solutions) User Manual May 1, 2016 Version 1.1 American Bus Video Inc. sales@AmericanBusVideo.com AmericanBusVideo.com DriverSafetyCameras.com FleetDriverRiskManagement.com 770.263.8118 29 Years of Fleet Driver Safety System Sales & Service Experience All Rights Reserved. © American Bus Video Inc. 2016...
  • Page 2 Memory Storage Required The SD4HD, SD4HW and SD4HC series are sold WITHOUT memory storage device, as the size of the SD memory cards will not only be up the customer but in many cases customers can source the cards at a lower cost than ABV can.
  • Page 3 (2 Warning) American Bus Video Inc (ABV) provides network solutions that require at a minimum Microsoft Certified Systems Administrator (MCSA) or better yet Microsoft Certified Systems Engineer (MCSE) in house, to assure you are...
  • Page 4 Before installing and using, be sure to read the Manual, then you will properly use and protect your machine. The first part of the statement concerns the matters to be attention to before installing and using. Attention " To protect your rights, before using and installing, please carefully read the contents of the manual.

  • Page 5: Table Of Contents

    Contents Product Overview ..............................5 Basic functions ................................5 Audio/Video Compression Format ......................... 5 Audio/video recording mode........................... 5 Image quality when monitoring, recording, playback..................5 Total Resources ............................... 6 Audio video synchronous recording ....................... 6 Access detection.............................. 6 Signal loss alarming function.......................... 6 Alarm linkage..............................

  • Page 6: Product Overview

    1 Product Overview The four-channel embedded digital SD card video recorder is designed for car safety. It uses embedded processor and embedded operating system, combined with video / audio compression / decompression, GPS, car recorder, and the capacity SD card storage technology to confirm the high intelligence and high stability. Widely used for bus, ship, train, and other areas of security.

  • Page 7: Total Resources

    The monitoring, recording and playback are all with 25fps " Horizontal resolution for monitoring More than 270TV lines per channel. " Horizontal resolution for playback More than 270TV lines per channel. Total Resources 4CH 960H: " Support 4 channels 960H (960*576) simultaneous recording, total 100fps. "...

  • Page 8: Alarm Pre-Recording

    500mA, switch ON); When the alarm is triggered, the audio recording will be started automatically (30-330s, adjustable).Alarm out will close for (5s-900s, adjustable) and send alarming signal, responding in less than 1s. Alarm pre-recording " Alarm video mode, alarm pre - recorded more than 5 s video, audio, positioning data. Full 2.10 duplex...

  • Page 9: Authority, Encryption, Data Safety

    " Transfer the SD card data to computer, download and play the media via our unique DVR player software. Users can also switch the SD files into universal AVI format to make it workable in other players. 2.16 Authority, encryption, data safety "...

  • Page 10: Index And Playback

    3.4 Index and Playback " Index and playback by time. " Support 4CH audio, 1CH video (any channel can be chosen), index and playback at the same time, support amplifying in one channel. Data only played by DVR playback software "...
  • Page 11 1 Channel VGA Support 1920*1080 1280*720 1024*768 Resolution Video Display 1 Or 4 Screen Display Video Standard PAL:25frames/Sec;NTSC:30frames/Sec System Resources PAL:100 Frames; NTSC:120 Frames Audio Input Four Channels Independent Input 600Ω Audio Output 1 Channel(4 Channels Can Be Convert Freely) Basic Output Level 1.0—2.2V Audio...
  • Page 12 G-Sensor G-Sensor Can Expand Module Inside Canbus not support, need to customize Power Consumption DC8-36V 8W without SD Others Working Temperature ~ +85 Clock Built-In Clock, Calendar Product Size 132(L)*119(W)*40(H)mm Packaging Product Weight 0.6KG(without SD) Items Device parameters SDVR Performance index 4CH 960H Name Product Name...
  • Page 13 NTSC: 1 or 2*720P 1280*720 +4*960H 960*576 Audio Bitrate 4KByte / s / channel Audio Taking Up Of 14MByte / hour / channel Hard Disk SD Storage Double SD card storage, Support Max 2* 128GB Image Quality Eight Grades to Choose Alarm in 4 Channels Independent Input.

  • Page 14: Instruction Of Installation

    5 Instruction of Installation Instruction of External Interface Wiring Page 13...
  • Page 15 Remarks: " If the power supply is 12V, then the current of 12V output can be just 1A. So if there are more than 3pcs cameras, we suggest customers to get power for other cameras from the 12V vehicle power directly or use Our special car power supply.

  • Page 16: Instruction Of Sd Card Installation

    5.2 Instruction of SD Card Installation Unlock the main board with key, make sure the “arrowhead” point to the left “turn on” and then switch it to the “turn off”. Note: The lock in the main board can also control the power. When the main board is locked, it also means the machine starts.

  • Page 17: Instruction Of Remote Control Operation

    LOCK: while removing the hard drive, use the key to unlock in order to remove the hard drive, unlock after machine’s auto-disconnects the power, the power auto-connect after being locked. 1: SD card1 slot 2: SD card2 slot A/V OUT: Audio/ Video output, Voice intercom input MIC input Instruction of Remote Control Operation Lead to menu...
  • Page 18 Lead to menu Return Record Enter the sub-menu to set and confirm Playback on the mobile DVR Stop when recording or playback; Delete Pause/Play when playback Fast-forward when playback video , play speed can be x2, x4, x8, press one time is x2, press two times is x4, and press 3 times is x8. Fast Backward when playback video, one press back for 10seconds For PTZ wiper customized Enter PTZ control mode.

  • Page 19: Menu Setting Instruction

    Towards to right for MENU selection or MENU setup. ”Right” direction for PTZ control mode. screen zoom the first channel video when surveillance, record Enter password or set system password. shortcut keys, press the first key shortcut to switch the number 1, press the second key shortcut to switch the capital letter a, press the third key shortcut toggles the lowercase letters a, press the up and down keys to change value.
  • Page 20 pressing these buttons" " ,then press " "to enter. System Settings: " includes options of “Setup”, “Vehicle” , “Other”, “System info”, “Log”, “Config” . " Setup setting: includes options of “Base”, “User” , “Serial”, “PTZ”, “GPS”, “G-sensor” and “NTP” " Base setting: Set the System time, TV system, Language etc.
  • Page 21 Date format: Offer 3 display methods like “y/m/d, m/d/y, d/m/y” for personal habit. Daylight saving time: suitable for according countries or areas. Date: Adjust the date of HDD recorder Time: Adjust the time of HDD recorder Language: Set "Chinese", "English", "Portuguese", "Russian" and "French", have to restart the DVR after setting.
  • Page 22 Admin user: set up the user name of administrator Password: Enter the default password before changing the new password. New password Enter the new password. Common user: set up the user name of common. Password: Enter the default password before changing the new password. New password Enter the new password.
  • Page 23 RS485 set: support PTZ, led screen, oil sensor, ID card, OBD, person count. Bitrate: support 2400bps, 4800bps, 9600bps,19200bps and 38400bps. PTZ setting: Adjust and control the camera with external PTZ device. " Protocols: default PELCO-D, support PELCO-D and PELCO-P. Channel-Address: Channel one-Device address. Channe2-Address: Channel two-Device address.
  • Page 24 " G-sensor setting: G Sensor-X 2000mg( default value, this value will change accordingly if the X direction gravity accelerated speed value is changeable). G Sensor-Y 2000mg(default value, this value will change accordingly if the Y direction gravity accelerated speed value changeable ). G Sensor-Z 2000mg(default value, this value will change accordingly if the Z direction gravity accelerated speed value is changeable).
  • Page 25 NTP timing different by countries, example: China for UTC+08 NTP Interval time data upload interval, used with NTP server. " Vehicle information: details of car plate number, route and driver code. Car ID: can be showed by English, Chinese simplified language, Numbers or common symbols.
  • Page 26 Alarm Phone: set the action of alarm or not. Phone number: click alarm function, set the phone number for alarm. " System information: Display DVR hardware code number software version information( only view, couldn’t be changed) Device encoding: only for this DVR, the code is unique. Firmware version: the version No.
  • Page 27 " Configuration management Import: Import the configuration parameters. Export: Export the configuration parameters. Renew: Restore the factory parameter. " Disk Check and format Disk Name Display the system recognized HDD name. Overwrite: Choose on and off Total Size: Display the total size of HDD. Free Size: Display the remaining Capacity of HDD.
  • Page 28 Select this item there is a format interface after press“ ”,confirm to format, cancel to return the original interface. " Record: the video files setting, It includes “codec” , ”channel” and ”record plan”. " Codec: Channel: select the channel setting (the information of each channel could be set independently) Resolution CIF/HD1/D1/960H/720p/1080p...
  • Page 29 Frame 1-25/30fps The left side is local storage information; The right side is network transmission information. Stream mode: Constants Bit Rate and Variable Bit Rate. Quality Video quality setting The left side is the local video quality(total 10 grades 192kbps/320kbs/512kbps/768kbps/1Mbps/1.2Mbps/1.5bps/2Mbps/3Mbps/4Mbps) The right side is the network transmission quality( total 13 grades 32kbps/48kbs/64kbps/80kbps/112kbps/144kbps/192kbps/256kbps/320kbps/384kbps/512kbp s/768kbps/1024kbps)
  • Page 30 Copy to all: Copy to all channels Record plan " Channel: select the channel setting (the information of each channel could be set independently) Record mode real time and event or no record File length the packaged video files length setting 5/10/15/25/30/60 minutes optional Prerecord Before the alarm recording time(no,5s,10,15s) Event REC time...
  • Page 31 There is video date in the menu, it will show the vide time after press ”Search”, choose the playback time range according to require time, then press “Play “button to replay the video. File format suffix "_P" is power off video file, suffix "_S" indicates an alarm trigger video files, suffix "_T" indicates an timing video files.
  • Page 32 LAN: connecting via RJ45. 3G/4G: insert 3G/4G SIM card into the slot. WIFI: connecting the network of WIFI. IPC: To connect the IPC camera Settings. SIP: Chinese government standard platform CH ID: Chinese government standard platform Local Network Setting " Network Type: LAN and 3G/4G-WIFI optional.
  • Page 33 DNS: please input when the server IP is DNS, and not necessary when IP is static. Server IP: If the units login on our server, please use cvideoview.com, and if the units login on your own server, please use yours. Server Port: Keep it as default of 8101.
  • Page 34 Net type: Select 3G-WIFI when the type is under LAN. DHCP: ON Access Network setup →“WIFI” SSID: WIFI router device name. Password: using password for SSID. Certificate: Support “WPA-PSK”. Encryption: Support ”TKIP”. Access router, check its “WI-FI “encryption. Page 33...
  • Page 35 Notes: Please make sure the router WI-FI encryption keep the same with the setup in MDVR if the units use WI-FI. IPC Setting (This function can only suit for Mobile NVR ) " Channel main channel , different channel set can choose. Time Sync turn on/off means if open the time synchronization between ipc and device.
  • Page 36 Save click the save button to keep the sets after set Note: the network type must be changed to LAN when connect with ipc. " SIP: Foreign users can't use this standard, it’s just suit for chinese client . " CH ID: Foreign users can't use this standard, it’s just suit for chinese client .
  • Page 37 Trigger level High or low level trigger the alarm. linkage Set up ON/ OFF video linkage function. Choose whether to overlay alarm information. Lock Won't cover this alarm video after choose this lock. Alarm: Choose whether to overlay alarm information. Alarm Out Choose whether to alarm out .

  • Page 38: Dvr Video Playback Instruction

    No detect Low sensitivity High sensitivity " Other: other alarm setting. Alarm out time Alarm output time (5s-900s). Low voltage The low voltage alarm about car battery. Low speed The low speed alarm. High speed The high speed alarm. Alarm out enable setup the types of alarms linkage, speed, G-sensor, video lost, Motion detecting alarm, HDD fail, power.
  • Page 39 Users can watch the video playback with the IR remote control, the specific steps are as follows: Enter the main menu, move to “playback” option, press“ ”to enter, next press the key“ ”or “ ”to select the playback date ,and move to “Search”, then press “ ”key to display the video files of the selected date(file named by the record time),same press “...
  • Page 40 % User can watch the video playback with the mouse, the specific steps are as follows: Enter the main menu, Click on the “playback” option to enter, next select the playback date, file type and time frame ,then press “Search” to display the video files of the selected date(file named by the record time).After selected the time and channel , press “Play”...

  • Page 41: Video Backup

    Video Backup Our company System supports 2 video backup ways. Connect the USB disk to the DVR’s USB port for backup Ports on Demand Operating method as follows Connect USB disk to the DVR’s USB port (FAT32 format, backup Max.20G). On the video playback interface, select the backup video files first, then move to “Export”...
  • Page 42 User can control PTZ camera with the mouse, the specific steps are as follows: When DVR is working Click the mouse left button, then the screen would show this picture “ ”, click “PTZ”, There is PTZ control icon would display the PTZ camera would rotate after each command by clicking PTZ icon the PTZ control icon will be displayed on the channel which your mouse to click;...

  • Page 43: Extranet Port Mapping

    6.7 Extranet Port Mapping " Install the CMS server in LAN, Pleass refer to the manual how to install CMS server. First, make sure the PC, which installed the server use Static Public IP, not automatically get. " Access into “Program”→”Run”→”CMD”, fill in “ipconfig”→”Enter” to see if the server IP has been set successfully.
  • Page 44 " Access into router→”Advanced”→”Port forwarding “ " Add the ports of 8001, 8101, 9001 to the port forwarding. Name: fill in a name for MDVR port. Ports to Open: 8001, 8101, 9001 IP Address: Server IP address Inbound Filter TCP UDP Allow ALL, Pls select “Allow All” Page 43...
  • Page 45 Schedule select “Always” " Fill in the ports, and click” Save settings”. " After the port mapping settings, find the “IP Address” in the WAN, the IP Address is your CMS server IP. login the server IP on the CMS client to access. Notes: When extranet access into LAN server, it need do mapping on the router.

  • Page 46: Domain Binding Setting

    “menu”→”Network setting”→”LAN”→”Server IP”→XXX.XXX.XXX.XXX Domain binding setting After finished the server set up and the port mapping, you can login via network IP. There are two ways to access the network as follow. ADSL dial-up: It will assign a different dynamic IP address for each dial Leased line: It will assign a static IP address, and you can access directly So, when set up the server with the way of ADSL dial-up, you can binding DDNS via domain in order to prevent the distribution of different dynamic IP in each dial.
  • Page 47 Enable Dynamic DNS Enable ON if you need to use DDNS Server Address: Fill in accordingly Username or Key: Fill in applied user name Password or Key: Fill in password Verify Password or Key: confirm the password Timeout: Timeout setting Status: Status of connection Notes: DDNS need to be applied by customers if necessary.
  • Page 48 Memory Storage Required The SD4HD, SD4HW and SD4HC series are sold WITHOUT memory storage device, as the size of the SD memory cards will not only be up the customer but in many cases customers can source the cards at a lower cost than ABV can.
  • Page 49 (2 Warning) American Bus Video Inc (ABV) provides network solutions that require at a minimum Microsoft Certified Systems Administrator (MCSA) or better yet Microsoft Certified Systems Engineer (MCSE) in house, to assure you are...
  • Page 50 Page 49...
