O p e r a t i o n
A. Initial Setup
1. Connect a 12V DC transformer (included) to the receptable on the back of the control box. The
LED will light up green to indicate power.
2. Be careful not to mount or enclose SmartConnect on or in metal, as this may effect radio
reception
3. Set the MMC RF receiver or motor in its Pairing Mode. Refer to the installation and programming
instructions for the relevant product for this procedure.
4. Using the RF Channel Dial, select the channel to be paired. Letters A through E stand for
channels 10 through 14, and channels 0 and F represent all channels. Briefly press the Pair
button (5 sec max), the window treatment will jog to indicate the channel has been learned.
Please note that current protocol only supports up to 14 channels.
5. Repeat the steps above for each channel or product to be memorized, up to 14.
6. To test the control operation, simply press the UP, STOP, or DOWN buttons on the front of the
SmartConnect. The window treatment should move appropriately. The LED will flash red to
indicate the radio signal has been transmitted.
B. RS232 Operation
1. The BTX SmartConnect interface uses the following communications settings: 9600 Baud, 8 Data
Bits, 1 Stop Bit, No Parity
2. Set the RF Channel Dial to position 1
3. The basic format for communication is as follows:
[SmartConnect Address] [Motor Channel] [Command] [Transmission Time]
The SmartConnect Address is 01.
The Motor Channel is always a two-digit number; 01 through 14.
Transmission Time is not a required entry.
See the following chart for command detail.
# Commands (low/HIGH case)
1 c/C
2 d/D
3 s/S
4 u/U
5 a/A
6 b/B
7 e/E
8 f/F
9 t/T
10 p/P
11 n/N
12 m/M
13 x/X
*Motor must be in Programming Mode
**Motor must be in Pairing Mode
***Only applies to Tumo Drapery motors. Motor must be in Programming Mode.
BTX Window Automation - 2016 Smar tConnect Instructions
© 2016 BTX Intelligent Fashion, LLC
(800) 422-8839 | www.btxinc.com
Command Description
Travel to CENTER Favorite Position
Travel DOWN or CLOSE
STOP System
Travel Up or OPEN
Travel to A Favorite Position
Travel to B Favorite Position
Erase All (Set motor to Factory Default)*
Unlearn (ERASE) Selected Channel*
CHANGE DIRECTION (mech limit motor) or
ENTER PROGRAMMING MODE (electronic limit motor)
PAIR Motor** or
CHANGE DIRECTION (electronic limit motor)*
Set UPPER LIMIT*
Touch Control ON***
Set LOWER LIMIT*
Touch Control OFF***
Enter to PAIRING MODE
B T X S m a r t C o n n e c t
Open+Close (3-5ceconds)
Button Description
Center
DOWN or Close
Stop
UP or Open
A
B
Close+Stop (3-5ceconds)
Open+Stop (3-5ceconds)
A+B (3-5ceconds)
A+Center (3-5ceconds)
B+Center (3-5ceconds)
Stop (3-5ceconds)
