- Page 1 User Manual ISO 9001 Certified Quality Management System...
- Page 2 Revision History Changes to the original manual are listed below Date Description May. 2018 Initial release This device doesn’t violate any of the regulations of use the radio frequency spectrum, and is able to be operated in at least one member of nations. This device complies with Requirements 10.10, Radio Equipment Directive(RED) since It is able to deal with the data by the package.
- Page 3 While reasonable efforts were made to ensure that the information in this document was complete and accurate at the time of printing, DSIC Co., Ltd. can assume to no liability for any errors. Changes and corrections to the information in this document might be incorporated in future release.
- Page 4 Contact DSIC Support DSIC Co., Ltd. provides a technical support customer service for you to report problems or to ask questions about the product. Please contact us through our email: dsic_pda@dsic.co.kr. For additional support, visit the DSIC Web site: http://www.dsic.co.kr/ENG/...
-
Page 5: Table Of Contents
Contents Safety Instruction ..................................7 Chapter 1: Introduction ................................8 Spec Sheet ..................................... 8 Overview of DS6 features .............................. 9 Front view ..................................9 Back view ................................... 10 Chapter 2: Getting Started ..............................11 Installing Micro SD card/ SAM card/ SIM card (optional) ................12 Bumper installation ................................ - Page 6 Lock screen ..................................30 Lock screen actions ................................ 30 Android Beam ................................... 31 NFC (13.56 MHz) ................................32 File Manager ..................................33 Screenshots ..................................34 Chapter 4: Using the keyboard ............................35 Enter & edit text ................................35 Chapter 5: Trying some apps .............................. 38 All Apps ....................................
-
Page 7: Safety Instruction
Safety Instruction Read this instruction carefully to keep yourself safe and to avoid the loss of property. Make sure that battery terminals (metal part) do not come into contact with any conductive materials like a necklace or coin. Also make sure that batteries do not get damaged by teeth or nails. -
Page 8: Chapter 1: Introduction
Chapter 1: Introduction Spec Sheet Characters Descriptions Display 5” inch HD (1280x720) IPS / Capacitive multi touch screen Dimensions (mm) 76 x 154 x 18.7 Weight (g) 250g with Battery Battery Lithium-ion 3.8V 4000mAh Android AOSP 7.1 Nougat Processor Qualcomm ARM Cortex-A53, 2.0Ghz 64-bit Octa-core processor Memory (RAM/ROM) DDR3 2GB/16GB, 4GB/32GB NAND (optional) USB 3.0 (Type-C) -
Page 9: Overview Of Ds6 Features
Chapter 1: Introduction Overview of DS6 features Front view Receiver Indicators Function Scan trigger 5” HD IPS Touch screen Microphone Headset jack Speaker Micro USB (Type-C) port... -
Page 10: Back View
Chapter 1: Introduction Back view Barcode scanner Hand belt hook Power button 16 MP Camera Volume key Battery lock lever Scanner trigger Battery Hand belt hook Hand belt hook Pogo... -
Page 11: Chapter 2: Getting Started
Chapter 2: Getting Started This chapter will describe how to set up DS6 for the first time. To start up the terminal, Installing Micro SD / SAM / SIM card (optional) Bumper Installation Installing DS6 Battery Cradle Adjustment ... -
Page 12: Installing Micro Sd Card/ Sam Card/ Sim Card (Optional)
Chapter 2: Getting Started Installing Micro SD card/ SAM card/ SIM card (optional) Important : Turn your device off before installing or removing a card. Be careful not to bend or scratch the card and avoid exposing it to static electricity, water, or dirt. Keep cards out of the reach of small children. Insert the card carefully as the shown below. -
Page 13: Bumper Installation
Chapter 2: Getting Started Bumper installation Install bumper to the terminal as shown below. Installing DS6 Battery Align the bottom of the battery and press down the top. Then, lock the battery by sliding the lever from left to right. -
Page 14: Battery Power Source
Batteries that is no longer suitable for use can be directly returned at: DSIC Co., Ltd. PDA Dept. DSIC Bldg. 205-28, Gasan digital 1-ro, Guemchun-gu, Seoul, Korea Tel: +82-2-2107-5178 Fax: +82-2-2107-5178 Email: dsic_pda@dsic.co.kr... -
Page 15: Cradle Adjustment
Chapter 2: Getting Started Cradle Adjustment Cradle comes with a spare piece for a device without bumper. In that case, Install the piece manually into the Cradle. Install a spare piece for bumper removed Remove a spare piece for bumper installed Tighten 2 screws into the two marked points After removing 2 screws as above, lift up the after mounting the spare piece... -
Page 16: Connecting Power Source
output voltage is DC 5V, 3A Your DS6 can be charged via the USB port on a computer only when DS6 is in sleep mode (screen off) or turned off. Charging through the USB port will take longer than charging with the USB charging unit. -
Page 17: To Use Cradle
Chapter 2: Getting Started To use Cradle Plug the AC power connector into the cradle and plug the other end into a power outlet. Cradle front view Slide switch: Turn the switch to choose charge or data sync mode. Pogo interface Blade connector (Male) Power indicator... -
Page 18: Cradle Back View
Chapter 2: Getting Started Cradle back view AC Adapter: Charging DS6 and spare battery simultaneously Micro USB: PC sync and charging DS6 only. It is not able to charge spare battery. Spare battery charging slot RS232 Ethernet Micro USB port... -
Page 19: Connecting Cradles For Multi-Slot Charging
Chapter 2: Getting Started Connecting cradles for multi-slot charging You can connect cradles for using them as a multi-slot cradle. (up to 4 cradles) <Connecting 2 cradles> <4 Connected Cradles>... -
Page 20: Operating Power Of The Terminal
Chapter 2: Getting Started Operating power of the terminal Power On Press and hold Power button at the upper-right side of the terminal to turn on. Suspend and Resume Press Power button shortly to enter Suspend, Resume the terminal. Reset To reboot the terminal press power button approximately for 10 seconds. -
Page 21: Power Options
Chapter 2: Getting Started Power options Make a long press the Power button to see the power options. Icon Description Power Off To Power off the device, make a long press Power button and select Power off. Reboot Make a long press Power button. Select Reboot. -
Page 22: Home Screen
At the bottom of every Home Screen There is Favorites tray: another quick way to get to your apps. Here’s what it looks like on a DS6. To open an app, touch it. To drag an app in or out of the Favorites tray or anywhere else... - Page 23 Chapter 2: Getting Started DS6 navigation keys DS6 has a navigation bar with these three buttons on the screen: Icon Description Back Opens the previous screen you were working in, even if it was in a different app. Once you back up to the Home screen, you can’t go back any further.
-
Page 24: Organize Your Home Screen
Chapter 2: Getting Started Organize your Home screen Touch and hold anywhere on the Home screen until the menu appears. Icon Description Wallpapers Touch Wallpapers to select a photo from Gallery or pre-installed photos. Widgets Touch Widgets to place stand-alone applications that run on the Home screen. Settings Go to Settings to enable Home Screen rotation. - Page 25 4. Touch & hold the app until the Home screen appears, slide it into place, and lift your finger. To add a widget to the Home screen on a DS6, swiping right through the All Apps screens to find the widget you want.
-
Page 26: Touch & Type
Chapter 2: Getting Started Touch & type To select or activate something, touch it. To type something, such as a name, password, or search terms, just touch where you want to type. A keyboard pops up that lets you type into the field. Other common gestures include: Touch &... -
Page 27: Android Version & Updates
Chapter 2: Getting Started Android version & updates To check your version number or get the latest system update for a DS6, first go to Settings > System > About table or phone. Then look for these labels: Android version. Look partway down the list for this heading and the number just below ... -
Page 28: Chapter 3: Essentials
Chapter 3: Essentials Notifications & settings Notifications alert you to the arrival of new messages, calendar events, and alarms, as well as ongoing events. When a notification arrives, its icon appears at the top of the screen. Icons for pending notifications appear on the left, and system icons showing things like Wi-Fi signal, mobile carrier signal, or battery strength on the right: TIP: Wi-Fi and mobile signal strength are indicated at the top of the screen by white bars. - Page 29 Chapter 3: Getting Started Certain notifications can be expanded to show more information; such as email preview. The one at the top is always expanded when possible. To expand a notification, position one finger inside it and swipe down slowly. To open the related app, touch the notification icon on the left.
-
Page 30: Quick Settings
Chapter 3: Essentials Quick Settings Use Quick Setting to easily access Wi-Fi settings, manage display brightness, open the Main Settings menu, and more. To open Quick Settings, swipe down from the top of the screen with two fingers Lock screen If a lock is set for your screen, the screen goes dark and locks when the display goes to sleep or if you press the Power button. -
Page 31: Android Beam
Chapter 3: Essentials Android Beam You can beam a web page, a video, or other content from your screen to another device by bringing the devices together (typically back to back). Before you begin: Make sure both devices are unlocked, support Near Field Communication (NFC), and have both NFC and Android Beam turned on. -
Page 32: Nfc (13.56 Mhz)
Chapter 3: Essentials NFC (13.56 MHz) Reading NFC Cards To read NFC card, move it close to back of DS6 until it detects the card. (Reading only) -
Page 33: File Manager
Hangout message, and so on. You can also use stored images as your Home screen wallpaper. To browse the folders in DS6, touch File Manager A set of Icons appears. To view more choices, touch the... -
Page 34: Screenshots
Chapter 3: Essentials Screenshots To take a screenshot from DS6: 1. Make sure the image you want to capture is displayed on the screen. 2. Press the Power and Volume down buttons simultaneously. The screenshot is automatically saved in your Gallery. -
Page 35: Chapter 4: Using The Keyboard
Chapter 4: Using the keyboard Enter & edit text Use the onscreen keyboard to enter text. Here’s what it looks like on a DS6 device: Touch & Hold Touch a to type this Suggestion to type it character Search Season Touch &... - Page 36 Chapter 4: Using the keyboard Basic editing Emoji Android 7.1 vastly expands the variety of emoji available at your fingertips. Touch and hold the Return key to display Emoji. You‘ll see a panel like this. To move between categories, swipe left or right or touch the symbols in the top row. To type an emoji, touch it Use next-word suggestions 1.
- Page 37 To change your keyboard and input methods, go to Settings > Personal > Language & input. To turn next-word suggestion on or off, go to Setting > Personal > Language & input methods > Android keyboard. Touch the Setting icon, then check the box next to Next-word suggestions.
-
Page 38: Chapter 5: Trying Some Apps
Chapter 5: Trying some apps All Apps To see all your apps, touch the All Apps icon in the Favorites tray on any Home screen. This is where you can see all your apps. You can move app icons to any of your Home screens. -
Page 39: Phone
Chapter 5: Trying some apps Phone Using a DS6, you can place calls from the Phone app, the People app, or other apps or widgets that display contact information. Wherever you see a phone number, you can usually touch it to dial. -
Page 40: Camera
Chapter 5: Trying some apps Camera The Camera app lets you take photos, panoramic photos, videos, and immersive 360- degree photo sphere shots, including what’s above and below you. To open Camera: From the lock screen, swipe the Camera icon. ... -
Page 41: Gallery
Chapter 5: Trying some apps Gallery The Gallery app gives you an easy way to browse pictures and videos you’ve taken with Camera. It also displays screenshots and auto backups from other devices. To open Gallery from the: Camera app. Swipe from right to left. ... -
Page 42: People
Chapter 5: Trying some apps People The People app gives you quick access to everyone you want to reach. To open it, touch the People icon on a Home or All Apps screen. If you use Exchange, you can also sync that contact information with People. When you open the People app, you can: View All contacts, favorites, or groups. -
Page 43: Chapter 6: Settings
The fastest way to adjust system settings that you access frequently, such as Wi-Fi or brightness, is through Quick Settings. Here are the Quick Settings for a DS6 phone: To open Quick Settings, swipe down from the top of the screen the Settings icon. -
Page 44: Chapter 7: Accessibility
Chapter 7: Accessibility To use the accessibility options, open Settings > System > Accessibility. Accessibility settings let you modify your device’s display and sound options, such as increasing the text size, changing the speed at which text is spoken, and more. You can also try magnification gestures which allow you to zoom in and out, as well as temporarily magnify what’s under your finger. -
Page 45: Chapter 8: Application Guide
Chapter 8: Application Guide Barcode Tray To activate Barcode Tray program, touch barcode tray icon at your screen. Scan Test Text view the scanned barcode Barcode Module Setting Setting to enable, or disable barcode types Scan Setting Setting scanning feature, such as time out, prefix and suffix, scanner key setting, notification options and etc. -
Page 46: Key Mapping
Chapter 8: Application Guide Setting On-screen Scan Button go to Scan setting and enable On-screen Scan Button, Then, touch the scanner button on your screen. Key Mapping It is enabling you to create a shortcut for repeating a sequence of keys or commands. Settings >... - Page 47 Chapter 8: Application Guide 1) Select one of key in PROGRAMMABLE KEY 2) You can select an application to short cut for execution 3) Or, swipe the screen to left to set sequence. 4) To reset the function key, press the icon. When you select No use, then the key has no Then you can reset the configuration.
- Page 48 Chapter 8: Application Guide 5) Press Menu icon to import, export, Key Position remove, or reset your key mapping You can set your key mapping with graphic configuration interface as below.
-
Page 49: Ota Update
Chapter 8: Application Guide OTA Update Go to Settings > About phone > OTA Update Start > OTA Start Check your available latest OS update at Select Version Then touch Start Update button if you have available OS update. After new OS download, your device will be restarted Examples OS update by your own URL Select Menu icon... -
Page 50: Chapter 9: Developer's Guide
USB Driver If you are Android developer, please download from below link and install on your PC before you connect DS6 to your PC. This is shell for ADB synchronization between your PC and DS6. ADB: Android Development Bridge This driver is useful when you have “Unknown device” message at your PC while you are connecting DS6 to your PC. - Page 51 Chapter 9: Developer’s Guide Image Instruction Press the Power key and Long press the Left Scan key simultaneously Enter OS update screen When the display shows ”SUCCESS!” on the screen, the device got updated completely. When OS update is complete, press the power key for approximately 8’s to turn the device off.
-
Page 52: Kiosk Mode
Chapter 9: Developer’s Guide KIOSK MODE KIOSK MODE is to prevent misuse of the device such as Browsing a web page, watching YouTube, or playing games during the work shift. Admin can allow the users to use allowed applications such as RDP, GMS, or any other assigned Applications. -
Page 53: Password Change
Chapter 9: Developer’s Guide Password change Go to Admin Setting > Change password Input the current password first (Default: “0000”), and set a new password more than 4 characters Notification clear Click the menu tap on the Kiosk mode, and touch “Clear Notification”... -
Page 54: Setting Background
Select Admin Setting to export KIOSK setting information of the device by email, or xml file, such as allowed APP List, KIOSK On, KISOK Off and new password. If you want to assign special email account, then select Receive Email. To check the exported file, go File Manager > DSIC > kiosk >... -
Page 55: Kiosk And Ezgo
Chapter 9: Developer’s Guide KIOSK and eZGo Export your KIOSK setting information of the device and transfer by email, or xml file to generate with QR code. Activate eZGo application, and scan the QR code to simply set another device’s KIOSK MODE. -
Page 56: Ezgo
Chapter 9: Developer’s Guide eZGo The eZGo is a utility to make enrollment quickly and easily with simple scanning QR code. You can create a configuration profile containing various settings into your barcode, then simply scan it with your device and deploy the profiles, such as; Set Wi-Fi configuration and connect to your network Download files from HTTP servers Admin settings of KIOSK MODE... - Page 57 SSID: dsic Password: dsic1234 {won;apc:dsic,dsic1234} - Example 2) if your APK files are in www.dsic.co.kr, and you want to download them and install on your device using above Wi-Fi connection, {udl:http://www.dsic.co.kr} - Example 3) Enabling EAN 13, and EAN 8 barcode decoding only. And ITF barcode disabling {bes:ean13,true;bes:ean8,true,bes:itf,false}...
-
Page 58: Device Administration
Chapter 9: Developer’s Guide Device Administration Go Settings > Security > Device administrators > XXXXX (Your application) > Activate You use the Device Administration API to write device admin applications that users install on their devices. The device admin application enforces the desired policies. Here's how it works: A system administrator writes a device admin application that enforces remote/local device security policies.
