Summary of Contents for Allied Vision Technologies Prosilica GT1290
- Page 1 AVT Prosilica GT Technical Manual AVT GigE Vision Cameras V2.0.8 05 July 2013 Allied Vision Technologies GmbH Taschenweg 2a D-07646 Stadtroda, Germany...
- Page 2 Allied Vision Technologies customers using or selling these products for use in such applications do so at their own risk and agree to fully indemnify Allied Vision Technologies for any damages resulting from such improper use or sale.
-
Page 3: Table Of Contents
................45 Filters ........................46 Camera dimensions ..................47 Prosilica GT1290, GT1380, GT1600, GT2000, GT2050, GT2450 ..........47 Prosilica GT1660, GT1910, GT1920, GT2300, GT2750, GT3400 ..........48 Prosilica GT3300 ......................49 Prosilica GT4100, GT4905, GT4907, GT6600 ................ 50 Tripod adapter ......................51 Adjustment of C/CS-Mount ..................... 52 Camera interfaces .....................53... - Page 4 Output: Opto-isolated internal circuit................63 Trigger timing diagram....................64 Firmware update ....................66 Resolution and ROI frame rates ...............67 Prosilica GT1290 ......................67 Prosilica GT1380 ......................68 Prosilica GT1600 ......................68 Prosilica GT1660 ......................69 Prosilica GT1910 ......................69 Prosilica GT1920 ......................70 Prosilica GT2000 ......................
-
Page 5: Contacting Allied Vision Technologies
38 Washington Street Newburyport, MA 01950, USA Toll Free number +1 877-USA-1394 Tel: +1 978-225-2030 Fax: +1 978-225-2029 e-mail: info@alliedvisiontec.com Allied Vision Technologies Asia Pte. Ltd. 82 Playfair Road #07-02 D’Lithium, Singapore 368001 Tel: +65 6634-9027 Fax: +65 6634-9029 e-mail: info@alliedvisiontec.com Allied Vision Technologies (Shanghai) Co. -
Page 6: Introduction
Introduction Introduction This AVT Prosilica GT Technical Manual describes in depth the technical speci- fications of this camera family including dimensions, feature overview, I/O defi- nition, trigger timing waveforms, and frame rate performance. For information on software installation read the AVT GigE Installation Man- ual. -
Page 7: Conventions Used In This Manual
Gigabit Ethernet port section V2.0.8 2013-Jul-05 • Added contact information for Allied Vision Technologies (Shanghai) Co. Ltd. • Updated spectral plots for GT1910 on page 21 • Updated the links to AVT GigE Installation Manual • Added links to AVT GigE Camera and Driver Features docu-... -
Page 8: Precautions
Introduction Symbols Note This symbol highlights important information. Caution This symbol highlights important instructions. You have to fol- low these instructions to avoid malfunctions. This symbol highlights URLs for further information. The URL itself is shown in blue. ... -
Page 9: Cleaning Optics
Introduction Caution Do not exceed environmental specifications. See environmental specifications limits in the Specifications section of this document. Special care must be taken to main- tain a reasonable operating temperature. If the camera is oper- ated in temperatures higher than the specified range, the camera should be mounted on a heat sink. - Page 10 Introduction Note • A pin spanner wrench (AVT P/N: E9020001) suitable for IR filter removal is available for purchase from AVT for all GT cameras except GT4100, GT4905, GT4907, and GT6600. • DO NOT attempt to remove the camera IR filter for GT4100, GT4905, GT4907, and GT6600.
-
Page 11: Conformity
Conformity Conformity Allied Vision Technologies declares under its sole responsibility that all stan- dard cameras of the AVT Prosilica GT family to which this declaration relates are in conformity with the following standard(s) or other normative document(s): • CE, following the provisions of 2004/108/EG directive (Prosilica GT board level cameras do not have CE) •... -
Page 12: Specifications
86 x 53.3 x 33 mm including connectors, w/o tripod and lens Mass 211 g Hardware interface standard PoE, IEEE 802.3af 1000BASE-T, 100BASE-TX Software interface standard GigE Vision Standard 1.2 Regulatory CE, FCC Class A, RoHS (2011/65/EU) Table 3: Prosilica GT1290/1290C camera specifications AVT Prosilica GT Technical Manual V2.0.8... - Page 13 Specifications 1000 Wavelength [nm] Figure 1: Prosilica GT1290 monochrome spectral response Green Blue Wavelength [nm] Figure 2: Prosilica GT1290C color spectral response AVT Prosilica GT Technical Manual V2.0.8...
-
Page 14: Prosilica Gt1380/1380C
Specifications Prosilica GT1380/1380C Feature Specification Resolution 1360 x 1024 Sensor Sony ICX285AL, ICX285AQ for color Type CCD Progressive Sensor size Type 2/3 Cell size 6.45 μm Lens mount C (adjustable) Max frame rate at full resolution 30.5 fps 14 bit On-board FIFO 128 MB Bit depth... - Page 15 Specifications 1000 Wavelength [nm] Figure 3: Prosilica GT1380 monochrome spectral response Green Blue Wavelength [nm] Figure 4: Prosilica GT1380C color spectral response AVT Prosilica GT Technical Manual V2.0.8...
-
Page 16: Prosilica Gt1600/1600C
Specifications Prosilica GT1600/1600C Feature Specification Resolution 1620 x 1220 Sensor Sony ICX274AL, ICX274AQ for color Type CCD Progressive Sensor size Type 1/1.8 Cell size 4.4 μm Lens mount C (adjustable), CS Max frame rate at full resolution 25.8 fps 14 bit On-board FIFO 128 MB, 33 frames at full resolution Bit depth... - Page 17 Specifications 1000 Wavelength [nm] Figure 5: Prosilica GT1600 monochrome spectral response Green Blue Wavelength [nm] Figure 6: Prosilica GT1600C color spectral response AVT Prosilica GT Technical Manual V2.0.8...
-
Page 18: Prosilica Gt1660/1660C
Specifications Prosilica GT1660/1660C Feature Specification Resolution 1600 x 1200 Sensor Truesense KAI-02050 Type CCD Progressive Sensor size Type 2/3 Cell size 5.5 μm Lens mount C (adjustable) Max frame rate at full resolution 62 fps 14 bit On-board FIFO 128 MB, 68 frames at full resolution Bit depth Monochrome cameras: 14 bit Color cameras: 12 bit... - Page 19 Specifications Measured with AR coated cover glass 1050 1150 Wavelength [nm] Figure 7: Prosilica GT1660 monochrome spectral response Green Blue Measured with AR 0.45 coated cover glass 0.35 0.25 0.15 0.05 1000 1100 Wavelength [nm] Figure 8: Prosilica GT1660C color spectral response AVT Prosilica GT Technical Manual V2.0.8...
-
Page 20: Prosilica Gt1910/1910C
Specifications Prosilica GT1910/1910C Feature Specification Resolution 1920 x 1080 Sensor Truesense KAI-02150 Type CCD Progressive Sensor size Type 2/3 Cell size 5.5 μm Lens mount C (adjustable) Max frame rate at full resolution 57.5 fps 14 bit On-board FIFO 128 MB, 63 frames at full resolution Bit depth Monochrome cameras: 14 bit Color cameras: 12 bit... - Page 21 Specifications Measured with AR coated cover glass 1050 Wavelength [nm] Figure 9: Prosilica GT1910 monochrome spectral response Green Blue Measured with clear cover glass 1075 Wavelength [nm] Figure 10: Prosilica GT1910C color spectral response AVT Prosilica GT Technical Manual V2.0.8...
-
Page 22: Prosilica Gt1920/1920C
Specifications Prosilica GT1920/1920C Feature Specification Resolution 1936 x 1456 Sensor Sony ICX674 Type CCD Progressive Sensor size Type 2/3 Cell size 4.54 μm Lens mount C (adjustable) Max frame rate at full resolution 40.7 fps 14 bit On-board FIFO 128 MB Bit depth Monochrome cameras: 14 bit Color cameras: 12 bit... - Page 23 Specifications 1000 Wavelength [nm] Figure 11: Prosilica GT1920 monochrome spectral response Green Blue Wavelength [nm] Figure 12: Prosilica GT1920C color spectral response AVT Prosilica GT Technical Manual V2.0.8...
-
Page 24: Prosilica Gt2000 / 2000C / 2000 Nir
Specifications Prosilica GT2000 / 2000C / 2000 NIR Feature Specification Resolution 2048 x 1088 Sensor CMOSIS CMV2000 Type CMOS Sensor size Type 2/3 Cell size 5.5 μm Lens mount C (adjustable) Max frame rate at full resolution 53.7 fps @ 124 MB/s; 56.7 burst mode* 12 bit On-board FIFO 128 MB, 29 frames at full resolution... - Page 25 Specifications GT2000 GT2000 NIR 1000 1100 Wavelength [nm] Figure 13: Prosilica GT2000 / 2000 NIR monochrome spectral response Green Blue 1000 1100 Wavelength [nm] Figure 14: Prosilica GT2000C color spectral response AVT Prosilica GT Technical Manual V2.0.8...
-
Page 26: Prosilica Gt2050 / 2050C / 2050 Nir
Specifications Prosilica GT2050 / 2050C / 2050 NIR Feature Specification Resolution 2048 x 2048 Sensor CMOSIS CMV4000 Type CMOS Sensor size Type 1 Cell size 5.5 μm Lens mount C (adjustable) Max frame rate at full resolution 28.6 fps @ 124 MB/s; 30.1 burst mode* 12 bit On-board FIFO 128 MB, 15 frames at full resolution... - Page 27 Specifications GT2050 GT2050 NIR 1000 1100 Wavelength [nm] Figure 15: Prosilica GT2050 / 2050 NIR monochrome spectral response Green Blue 1000 1100 Wavelength [nm] Figure 16: Prosilica GT2050C color spectral response AVT Prosilica GT Technical Manual V2.0.8...
-
Page 28: Prosilica Gt2300/2300C
Specifications Prosilica GT2300/2300C Feature Specification Resolution 2336 x 1752 Sensor Truesense KAI-04050 Type CCD Progressive Sensor size Type 1 Cell size 5.5 μm Lens mount C (adjustable) Max frame rate at full resolution 29.3 fps 14 bit On-board FIFO 128 MB Bit depth Monochrome cameras: 14 bit Color cameras: 12 bit... - Page 29 Specifications Measured with AR coated cover glass 1100 Wavelength [nm] Figure 17: Prosilica GT2300 monochrome spectral response Green Blue Measured with AR 0.45 coated cover glass 0.35 0.25 0.15 0.05 1000 1100 Wavelength [nm] Figure 18: Prosilica GT2300C color spectral response AVT Prosilica GT Technical Manual V2.0.8...
-
Page 30: Prosilica Gt2450/2450C
Specifications Prosilica GT2450/2450C Feature Specification Resolution 2448 x 2050 Sensor Sony ICX625ALA. Sony ICX625AQA for color Type CCD Progressive Sensor size Type 2/3 Cell size 3.45 μm Lens mount C (adjustable) Max frame rate at full resolution 15 fps 14 bit On-board FIFO 128 MB, 13 frames at full resolution Bit depth... - Page 31 Specifications 1000 Wavelength [nm] Figure 19: Prosilica GT2450 monochrome spectral response Green Blue Wavelength [nm] Figure 20: Prosilica GT2450C color spectral response AVT Prosilica GT Technical Manual V2.0.8...
-
Page 32: Prosilica Gt2750/2750C
Specifications Prosilica GT2750/2750C Feature Specification Resolution 2750 x 2200 Sensor Sony ICX694 ALG. Sony ICX694 AQG for color Type CCD Progressive Sensor size Type 1 Cell size 4.54 μm Lens mount C (adjustable) Max frame rate at full resolution 19.8 fps 14 bit On-board FIFO 128 MB, 21 frames at full resolution... - Page 33 Specifications 1000 Wavelength [nm] Figure 21: Prosilica GT2750 monochrome spectral response Green Blue Wavelength [nm] Figure 22: Prosilica GT2750C color spectral response AVT Prosilica GT Technical Manual V2.0.8...
-
Page 34: Prosilica Gt3300/3300C
Specifications Prosilica GT3300/3300C Feature Specification Resolution 3296 x 2472 Sensor Truesense KAI-8050 Type CCD Progressive Sensor size Type 4/3 Cell size 5.5 μm Lens mount Max frame rate at full resolution 14.7 fps 14 bit On-board FIFO 128 MB, 16 frames at full resolution Bit depth Monochrome cameras: 14 bit Color cameras: 12 bit... - Page 35 Specifications Measured with AR coated cover glass 1100 Wavelength [nm] Figure 23: Prosilica GT3300 monochrome spectral response Green Blue Measured with AR 0.45 coated cover glass 0.35 0.25 0.15 0.05 1000 1100 Wavelength [nm] Figure 24: Prosilica GT3300C color spectral response AVT Prosilica GT Technical Manual V2.0.8...
-
Page 36: Prosilica Gt3400/3400C
Specifications Prosilica GT3400/3400C Feature Specification Resolution 3384 x 2704 Sensor Sony ICX814 Type CCD Progressive Sensor size Type 1 Cell size 3.69 μm Lens mount C (adjustable) Max frame rate at full resolution 12.7 fps @ 124 MB/s; 14 burst mode* 14 bit On-board FIFO 128 MB... - Page 37 Specifications 1000 Wavelength [nm] Figure 25: Prosilica GT3400 monochrome spectral response Green Blue Wavelength [nm] Figure 26: Prosilica GT3400C color spectral response AVT Prosilica GT Technical Manual V2.0.8...
-
Page 38: Prosilica Gt4100/4100C - Preliminary
Specifications Prosilica GT4100/4100C - Preliminary Feature Specification Resolution 4096 x 3072 Sensor CMOSIS CMV12000 Type CMOS Sensor size APS-C (28 mm diagonal) Cell size 5.5 μm Lens mount F (M58 optional) Max frame rate at full resolution 4 fps 12 bit On-board FIFO 128 MB Bit depth... -
Page 39: Prosilica Gt4905/4905C
Specifications Prosilica GT4905/4905C Feature Specification Resolution 4896 x 3264 Sensor Truesense KAI-16050 Type CCD Progressive Sensor size APS-H (32.36 mm diagonal) Cell size 5.5 μm Lens mount F (M58 optional) Max frame rate at full resolution 7.5 fps @ 124 MB/s; 8.5 burst mode* 14 bit On-board FIFO 128 MB... - Page 40 Specifications Measured with AR 0.45 coated cover glass 0.35 0.25 0.15 0.05 1100 Wavelength [nm] Figure 27: Prosilica GT4905 monochrome spectral response Green Blue Measured with AR 0.45 coated cover glass 0.35 0.25 0.15 0.05 1000 1100 Wavelength [nm] Figure 28: Prosilica GT4905C color spectral response AVT Prosilica GT Technical Manual V2.0.8...
-
Page 41: Prosilica Gt4907/4907C
Specifications Prosilica GT4907/4907C Feature Specification Resolution 4864 x 3232 Sensor Truesense KAI-16070 Type CCD Progressive Sensor size 35 mm Cell size 7.4 μm Lens mount F (M58 optional) Max frame rate at full resolution 7.6 fps 14 bit On-board FIFO 128 MB Bit depth Monochrome cameras: 14 bit... - Page 42 Specifications Measured with AR coated cover glass 1100 Wavelength [nm] Figure 29: Prosilica GT4907 monochrome spectral response Green Blue Measured with AR 0.45 coated cover glass 0.35 0.25 0.15 0.05 1000 1100 Wavelength [nm] Figure 30: Prosilica GT4907C color spectral response AVT Prosilica GT Technical Manual V2.0.8...
-
Page 43: Prosilica Gt6600/6600C
Specifications Prosilica GT6600/6600C Feature Specification Resolution 6576 x 4384 Sensor Truesense KAI-29050 Type CCD Progressive Sensor size Type 4/3 Cell size 35 mm Lens mount F (M58 optional) Max frame rate at full resolution 4 fps 14 bit On-board FIFO 128 MB Bit depth Monochrome cameras: 14 bit... - Page 44 Specifications Measured with AR coated cover glass 1100 Wavelength [nm] Figure 31: Prosilica GT6600 monochrome spectral response Green Blue Measured with AR 0.45 coated cover glass 0.35 0.25 0.15 0.05 1000 1100 Wavelength [nm] Figure 32: Prosilica GT6600C color spectral response AVT Prosilica GT Technical Manual V2.0.8...
-
Page 45: Camera Attribute Highlights
Camera attribute highlights Camera attribute highlights AVT cameras support a number of standard and extended features. The table below identifies a selection of interesting capabilities of the Prosilica GT camera family. A complete listing of camera controls, including control defini- tions can be found online: ... -
Page 46: Filters
Filters Filters All Prosilica GT color models are equipped with an infrared block filter (IR fil- ter). This filter is employed to prevent infrared wavelength photons from pass- ing to the sensor. In the absence of IR filter, images are dominated by red and incapable of being properly color balanced. -
Page 47: Camera Dimensions
The Prosilica GT family supports a range of sensor configurations. To support this sensor variety while maintaining the smallest package size, a slightly lon- ger housing is used for quad tap sensor models. Prosilica GT1290, GT1380, GT1600, GT2000, GT2050, GT2450 M3x4 (4x) 65.2... -
Page 48: Prosilica Gt1660, Gt1910, Gt1920, Gt2300, Gt2750, Gt3400
Camera dimensions Prosilica GT1660, GT1910, GT1920, GT2300, GT2750, GT3400 M3x4 (4x) 70.9 Adjustable 29.9 31.6 C-Mount 11.4 M2x3 (4x) 26.7 16 26 33 20.6 19.1 76.2 M3x4 (8x) 53.3 12 Nominal M3x4 (4x) Precise dimension 70.9 is sensor dependent Figure 35: Mechanical dimensions for C-Mount GT1660, GT1910, GT1920, GT2300, GT2750, and GT3400 AVT Prosilica GT Technical Manual V2.0.8... -
Page 49: Prosilica Gt3300
Camera dimensions Prosilica GT3300 M3x4 (4x) 70.9 Adjustable Nikon F-Mount 29.9 59.7 11.4 M2x3 (4x) 20.6 19.1 76.2 28.5* *Nominal Precise dimension is sensor dependent 53.3 M3x4 (4x) 70.9 Figure 36: Mechanical dimensions for F-Mount GT3300 AVT Prosilica GT Technical Manual V2.0.8... -
Page 50: Prosilica Gt4100, Gt4905, Gt4907, Gt6600
Camera dimensions Prosilica GT4100, GT4905, GT4907, GT6600 1/4-20 27.9 M3x4 (4x) 2 sides Tripod Mount 2 sides 48.3 59.9 M3x4 (4x) 2 sides M3x4 (8x) 12.7 52.8 48.3 11.4 53.3 40.1 47.2 13.5 53.3 26.8* Adjustable M2x3 (2x) 59.7 Nikon F-Mount *Nominal Precise dimension is sensor dependent 6 (2x) 2 sides 27.9... -
Page 51: Tripod Adapter
Camera dimensions Tripod adapter A Prosilica GT camera can be mounted on a camera tripod by using mounting plate P/N 02-5036A. The same mounting plate can be used for all models within the GT camera family, except the GT6600 which has a tripod mount integrated into the camera body. -
Page 52: Adjustment Of C/Cs-Mount
Camera dimensions Adjustment of C/CS-Mount Prosilica GT cameras are shipped with adjustable C-Mount. The camera can also be built with a CS-Mount on request. See AVT Modular Concept for more information: http://www.alliedvisiontec.com/us/support/downloads/ product-literature/avt-modular-concept.html The C-Mount or CS-Mount is adjusted at the factory and should not require adjusting. -
Page 53: Camera Interfaces
Camera interfaces Camera interfaces This chapter provides information on Gigabit Ethernet port, inputs and outputs, and trigger features. For more information on GigE accessories: http://www.alliedvisiontec.com/emea/products/ accessories/gige-accessories.html I/O PORT: CAMERA POWER EXTERNAL SYNC IO RS-232 TX/RX LED1 LED2 GIGABIT ETHERNET PORT UTO IIS PORT Figure 40: Prosilica GT connection ports Status LEDs... -
Page 54: Gigabit Ethernet Port
Camera interfaces Gigabit Ethernet port The Prosilica GT is powered through the 12-pin Hirose Camera I/O port, or the Gigabit Ethernet port by using any standard Power over Ethernet (PoE) sup- ported network card, switch, or injector. AVT recommends using Category 6 or higher compatible cabling for best performance. -
Page 55: Camera I/O Connector Pin Assignment
Camera interfaces Camera I/O connector pin assignment Pin Signal Direction Level Description Camera GND GND for RS232 and Ground for camera power ext. power supply, and RS-232 11 12 Camera Power In 7–25 VDC Camera power supply Out 4 Open emitter max. Output 4 20 mA opto-isolated (SyncOut4) -
Page 56: I/O Definition
Camera interfaces I/O definition Camera Power The Prosilica GT camera can be powered through the Hirose I/O port, via Pin 1 Camera GND and Pin 2 Camera Power, or through the Gigabit Ethernet port if using a power over Ethernet (PoE) supported network card, switch, or injector. Cameras powered by both the Hirose I/O port and the Gigabit Ethernet port will use the power provided by Hirose I/O port only. - Page 57 Camera interfaces Input triggers Input triggers allow the camera to be synchronized to an external event. The camera can be programmed to trigger on the rising edge, falling edge, both edges, or level of the signal. The camera can also be programmed to capture an image at some programmable delay time after the trigger event.
- Page 58 Camera interfaces Out 1 and 2 – non-isolated Out 1 and Out 2 signals are not electrically isolated and can be used when envi- ronmental electrical noise is inconsequential and faster trigger response is required. Tie signal ground to Camera GND to complete the external circuit. The output signal is a low voltage TTL, maximum 3.3 V.
-
Page 59: Lens Control Port
Camera interfaces Lens control port Prosilica GT cameras can be used with C-/CS-Mount auto iris lenses of DC type, and P-Iris type. Both DC and P-Iris lens types use the same standard connector, located on the side of the camera. Lens type is automatically determined by the camera on power-up. - Page 60 Camera interfaces DC-Iris lenses The Prosilica GT operates with any standard DC-type auto iris lens. AVT tested lenses include Fujinon DV10x8SA-SA1L, Computar HG2Z0414FC-MP, and Pentax C61227DCPS. DC-type auto iris lenses are continuously driven by a voltage (0–3.3 V) from the camera lens control port.
- Page 61 Camera interfaces IrisVideoLevel attribute. PirisManual allows manual control of LensPIris- Position. The control attributes for P-Iris controls are described further in the following documents: PvAPI users: AVT GigE Camera and Driver Attributes document VIMBA users: AVT GigE Camera and Driver Features document For a list of P-Iris supported lenses, along with their LensPIris- Frequency and LensPIrisNumSteps specifications:...
-
Page 62: Camera Trigger
Camera trigger Camera trigger Input: Non-isolated and opto-isolated internal circuit CAMERA INTERNAL EXTERNAL 180 R TO CAMERA LOGIC 1/10 W IN 1 5.1 V, 150 mW CAMERA GND SN74LVC2G34DCKR 3.3 V CAMERA INTERNAL EXTERNAL 3.3 V 180 R 1/10 W 4.75 K IN 2 50 V, 1 A... -
Page 63: Output: Non-Isolated Internal Circuit
Camera trigger Output: Non-isolated internal circuit CAMERA INTERNAL EXTERNAL 3.3 V 3.3 V 4.75 K OUT 1 3.3 V CAMERA LOGIC DMN3404L-7 Figure 45: Prosilica GT internal circuit diagram for non-isolated output trigger Output: Opto-isolated internal circuit CAMERA INTERNAL EXTERNAL ISOLATED OUT POWER 3.3 V CAMERA LOGIC SIGNAL... -
Page 64: Trigger Timing Diagram
Camera trigger Trigger timing diagram Readout time Trigger latency Exposure Registered exposure start delay User trigger time Note: Jitter at the Logic trigger beginning of an exposure has no effect on the length of exposure. Exposure N+ 1 Trigger jitter Readout N+ 1 Interline time... - Page 65 Camera trigger Term Definition Trigger ready Indicates to the user that the camera will accept the next trigger Registered exposure time Exposure time value currently stored in the camera memory Exposure start delay Registered exposure time subtracted from the readout time and indicates when the next exposure cycle can begin such that the exposure will end after the current readout Interline time...
-
Page 66: Firmware Update
Firmware update Firmware update Firmware updates are carried out via the GigE connection. AVT provides an application for all Prosilica GT cameras that loads firmware to the camera using a simple interface. New feature introductions and product improvements moti- vate new firmware releases. All users are encouraged to use the newest firm- ware available and complete the firmware update if necessary. -
Page 67: Resolution And Roi Frame Rates
The frame rate for an ROI at the same effective height as binning will be slower because the CCD still needs to read out the “fast readout rows” in ROI mode. Prosilica GT1290 900 1000 Height [pixels] Figure 48: Frame rate vs. height for GT1290... -
Page 68: Prosilica Gt1380
Resolution and ROI frame rates Prosilica GT1380 1050 Height [pixels] Figure 49: Frame rate vs. height for GT1380 Prosilica GT1600 1120 1260 Height [pixels] Figure 50: Frame rate vs. height for GT1600 AVT Prosilica GT Technical Manual V2.0.8... -
Page 69: Prosilica Gt1660
Resolution and ROI frame rates Prosilica GT1660 1000 1200 Height [pixels] Figure 51: Frame rate vs. height for GT1660 Prosilica GT1910 100 200 300 400 500 600 700 800 900 1000 1100 Height [pixels] Figure 52: Frame rate vs. height for GT1910 AVT Prosilica GT Technical Manual V2.0.8... -
Page 70: Prosilica Gt1920
Resolution and ROI frame rates Prosilica GT1920 1000 1250 1500 Height [pixels] Figure 53: Frame rate vs. height for GT1920 Prosilica GT2000 5000 100 200 300 400 500 600 700 800 900 1000 1100 Height [pixels] Figure 54: Frame rate vs. height for GT2000 AVT Prosilica GT Technical Manual V2.0.8... -
Page 71: Prosilica Gt2050
Resolution and ROI frame rates Prosilica GT2050 5000 1200 1500 1800 2100 Height [pixels] Figure 55: Frame rate vs. height for GT2050 Prosilica GT2300 1200 1500 1800 Height [pixels] Figure 56: Frame rate vs. height for GT2300 AVT Prosilica GT Technical Manual V2.0.8... -
Page 72: Prosilica Gt2450
Resolution and ROI frame rates Prosilica GT2450 1200 1500 1800 2100 Height [pixels] Figure 57: Frame rate vs. height for GT2450 Prosilica GT2750 800 1000 1200 1400 1600 1800 2000 2200 Height [pixels] Figure 58: Frame rate vs. height for GT2750 AVT Prosilica GT Technical Manual V2.0.8... -
Page 73: Prosilica Gt3300
Resolution and ROI frame rates Prosilica GT3300 1000 1500 2000 2500 Height [pixels] Figure 59: Frame rate vs. height for GT3300 Prosilica GT3400 750 1000 1250 1500 1750 2000 2250 2500 2750 Height [pixels] Figure 60: Frame rate vs. height for GT3400 AVT Prosilica GT Technical Manual V2.0.8... -
Page 74: Prosilica Gt4905
Resolution and ROI frame rates Prosilica GT4905 900 1200 1500 1800 2100 2400 2700 3000 3300 Height [pixels] Figure 61: Frame rate vs. height for GT4905 Prosilica GT4907 1300 1950 2600 3250 Height [pixels] Figure 62: Frame rate vs. height for GT4907 AVT Prosilica GT Technical Manual V2.0.8... -
Page 75: Prosilica Gt6600
Resolution and ROI frame rates Prosilica GT6600 400 800 1200 1600 2000 2400 2800 3200 3600 4000 4400 Height [pixels] Figure 63: Frame rate vs. height for GT6600 AVT Prosilica GT Technical Manual V2.0.8... -
Page 76: Prosilica Gt Model Comparison
Resolution and ROI frame rates Prosilica GT model comparison GT1290 GT1380 GT1600 GT1660 GT1910 GT2300 GT2450 GT2750 GT3300 GT3400 GT4905 GT4907 GT6600 1000 1500 2000 2500 3000 3500 4000 4500 Height [pixels] Figure 64: Frame rate vs. height model comparison. GT2000, GT2050 not included for scale reasons AVT Prosilica GT Technical Manual V2.0.8... -
Page 77: Additional References
Additional references Additional references Prosilica GT webpage http://www.alliedvisiontec.com/us/products/cameras/gigabit-ethernet/pro- silica-GT.html Prosilica GT Documentation http://www.alliedvisiontec.com/us/support/downloads/product-literature/ prosilica-GT.html AVT VIMBA SDK http://www.alliedvisiontec.com/us/products/software/vimba-sdk.html AVT GigE PvAPI SDK http://www.alliedvisiontec.com/us/products/software/avt-pvapi-sdk.html AVT Knowledge Base http://www.alliedvisiontec.com/us/support/knowledge-base.html AVT Case Studies http://www.alliedvisiontec.com/emea/products/application-markets/ industrial-inspection.html Prosilica GT Firmware http://www.alliedvisiontec.com/us/support/downloads/firmware.html AVT Prosilica GT Technical Manual V2.0.8... -
Page 78: Index
Idle (signal) ..........65 Specifications .......... 12 Imaging (signal) ........65 Spectral sensitivity In 1 ..........55 Prosilica GT1290-Color ......13 In 2 ..........55 Prosilica GT1290-Monochrome....13 Integrating light (trigger) ..... 57 Prosilica GT1380-Color ......15 interline boundary........65 Prosilica GT1380-Monochrome.... - Page 79 Index Prosilica GT1920-Monochrome....23 Prosilica GT2000 / 2000 NIR-Monochrome 25 Prosilica GT2000-Color ......25 Prosilica GT2050 / 2050 NIR Monochrome 27 Prosilica GT2050-Color ......27 Prosilica GT2300-Color ......29 Prosilica GT2300-Monochrome....29 Prosilica GT2450-Color ......31 Prosilica GT2450-Monochrome....31 Prosilica GT2750-Color ......33 Prosilica GT2750-Monochrome....
