Delta OHM HD40.1 Manual

Delta OHM HD40.1 Manual

Portable thermal printer
Hide thumbs Also See for HD40.1:
Table of Contents

Advertisement

Quick Links

Download this manual
Our instruments' quality level is the result of the product continuous development. This may lead to
differences between information written in this manual and the instrument that you have pur-
chased. We cannot entirely exclude errors in the manual, for which we apologize.
Data, figures and descriptions contained in this manual cannot be legally asserted. We reserve the
right to make changes and corrections without prior notice.
Portable thermal printer
HD40.1
HD40.2
ENGLISH
REV. 1.0
th
23
Jan. 2008

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HD40.1 and is the answer not in the manual?

Questions and answers

Related Manuals for Delta OHM HD40.1

Summary of Contents for Delta OHM HD40.1

  • Page 1 REV. 1.0 Jan. 2008 Portable thermal printer HD40.1 HD40.2 ENGLISH Our instruments' quality level is the result of the product continuous development. This may lead to differences between information written in this manual and the instrument that you have pur- chased.
  • Page 2 Portable thermal printer HD40.1 and HD40.2...
  • Page 3 HD40.1 – HD40.2 1. STATUS Led: shows the printer status. 2. MENU key: advances paper by two lines. When you turn on the printer, if you press the Menu key and the ON/OFF key, you activate the printer configuration mode.
  • Page 4 1. INTRODUCTION The HD40.1 and HD40.2 are lightweight, compact, portable thermal printers. The HD40.1 is connected to instruments or PC through the RS232 serial input. The HD40.2 features a dual mode data reception system - RS232 serial and Bluetooth. The Bluetooth wireless connection makes the HD40.2 printer very useful “in the...

  • Page 5: Power Led

    2. KEYBOARD AND LED DESCRIPTION ON/OFF Key Press the ON/OFF key until the Status led starts blinking to turn on the printer, then release the key. Press the ON/OFF key until the Status led remains on to turn off the printer, then re- lease the key.
  • Page 6 To turn off the printer, press the ON/OFF key until the STATUS led stops blinking and remains on: now you can release the key. The printer turns off. The following table shows different POWER and STATUS led combinations. STATUS LED Description Always off.
  • Page 7 3. HOW TO INSTALL AND USE YOUR PRINTER 3.1. ConnECTIONS The printer has one input (1) for the battery charger power supply and one plug (2) for RS232 serial connection. Power supply connector The power supply connector is 5.5mm in outer diameter and 2.1mm in inner diame- ter.

  • Page 8: How To Load Paper

    A null modem cable is necessary to connect the printer to the instrument : use the HD2110CSNM cable for instruments with 8-pole Mini DIN connector (ex. HD21xx and HD34xx.2 series, HD2010, HD2110, etc.). Use the 9CPRS232 cable for instruments with 9-pole connector (ex. HD22xx.2 se- ries, HD25.2, etc.).
  • Page 9 2) Insert the paper roll according to the sense of rotation as shown below.
  • Page 10 3) Pull the paper and close the cover centring the paper roll. 4) Tear off excess paper. The printer is ready.
  • Page 11 When autonomy (both when printing and waiting) is far lower than usual, battery pack needs replacing. • Use only the BAT-40 Delta Ohm battery pack and charge it by using the SWD10 battery charger, or alternatively, one complying with our technical specifications. •...
  • Page 12 3.3.3. How to replace battery pack Follow the steps below to replace the battery pack: • Disconnect the external power supply and turn off the printer. • Unscrew (2) the battery compartment cover located at the bottom of the printer (1).

  • Page 13: How To Configure Your Printer

    3.4. HOW TO CONFIGURE YOUR PRINTER The printer operating parameters are as follows (factory values have been under- lined): 1. Interface selection: only RS232 for the HD40.1, RS232 or Bluetooth for the HD40.2. 2. RS232 serial communication baud rate: 9600, 19200 or 38400.
  • Page 14 3) Automatic switch-off delay When this interval of time has elapsed, the printer turns off automatically if you have neither entered any command nor pressed any key. You can set the following intervals: 0 or 5, 10 or 15 minutes. If you choose 0, the automatic switch off is disabled and the printer turns off only if you press the ON/OFF key.
  • Page 15 PC connection. It is also suitable for other brand instru- ments. • Cod. HD2110CSNM: is a 9 pole – 8 pole MiniDIN cable for Delta Ohm instru- ments equipped with this connector (ex. HD21xx, HD2010, HD2110, HD34xx.2). Printer...

  • Page 16: Bluetooth Interface

    4.2. BLUETOOTH INTERFACE The HD40.2 model has a Bluetooth interface. The printer communicates with Delta Ohm instruments fitted with the HD22BT Blue- tooth module. Besides, it receives print commands from a PC with Bluetooth inter- face or the HD USBKL1 module.

  • Page 17: Printer Storage

    5. PRINTER STORAGE Instrument storage conditions: • Temperature: -25...+70°C. • Humidity: 10...90%RH without condensation. • Make sure you avoid: High humidity. Exposure to direct solar radiation. Exposure to a high temperature source. Strong vibrations. Steam, salt and/or corrosive gas. The instrument enclosure is made of ABS plastic: use only compatible solvents for cleaning.
  • Page 18 The communication interface parameter (RS232 or Bluetooth) will appear. • Press the MENU key to select the RS232 parameter. For the HD40.1 model, you needn’t select this parameter as it is factory set. Press the ON/OFF key to confirm. •...

  • Page 19: Bluetooth Connection

    C) How to configure the instrument In the instrument you must set: • baud rate at 38400 • Printing interval. • Interface on PRINTER (For a few instruments only , ex. sound level meters). Important note: the printer baud rate and that of the instrument must be the same, otherwise the printer doesn’t work.
  • Page 20 • The paper roll advances and the Baud Rate parameter will appear. • This parameter does not affect the Bluetooth interface. Press the ON/OFF key to confirm the value printed. • The roll paper advances and the Automatic switch-off delay parameter will appear. •...
  • Page 21 7. FUNCTIONING AND OPERATING SAFETY Authorized use Please read carefully the specifications listed in the following chapter. You are allowed to use the instrument only in compliance with these instructions. Any other use is not authorized. General safety instructions This instrument is manufactured and tested in compliance with EN 61010-1 safety standards on electronic measuring instruments and it leaves the factory in perfect safety conditions.

  • Page 22: Specifications

    8. SPECIFICATIONS Printing method Thermal Resolution 203 DPI (8 dot/mm) Printing width 48mm centered in the paper roll Paper roll width 57mm ... 58mm Max. paper roll diameter 32mm Number of columns Printing speed Up to 90 mm/sec (depending on battery charge and ambient conditions) Sensors Paper detection...

  • Page 23: Operating Conditions

    Operating conditions Operating temperature 0°C ... 50°C Operating relative humidity 20%RH ... 85%RH not condensing Storage Temperature / Relative hu- -25°C ... +70°C / 10%RH ... 90%RH not con- midity densing Protection degree IP40 Connections Serial interface 9-pole D sub male connector Battery charger power supply (cod.
  • Page 24 8.1. DIMENSIONS The figure below shows printer dimensions.

  • Page 25: Ordering Codes

    9-pole D Sub connectors (Delta Ohm instruments: HD22xx.2 series, HD25.2, etc.). SWD10 100-240Vac/12Vdc-1A Mains battery charger. BAT.40 Spare battery pack for HD40.1 and HD40.2 printers with in-built temperature sensor. The kit includes 4 thermal paper rolls 57mm wide and 32mm in diameter.
  • Page 26 INDEX 1 . INTRODUCTION ..................... 4 2 . KEYBOARD AND LED DESCRIPTION ............... 5 3 . HOW TO INSTALL AND USE YOUR PRINTER ............7 3.1 . ConnECTIONS ....................7 3.2 . HOW TO LOAD PAPER ..................8 3.3 . BatterieS......................11 3.3.1 .
  • Page 27 Tutti i dati di calibrazione della strumentazione di test sono conservati presso la Delta Ohm e possono essere visionati su richiesta. All calibration data for test equipment are retained on Delta Ohm and are available for in- spection upon request.

  • Page 28: Serial Number

    All DELTA OHM instruments have been subjected to strict tests and are guaranteed for 24 months from date of purchase. DELTA OHM will repair or replace free of charge any parts which it considers to be inef- ficient within the guarantee period. Complete replacement is excluded and no request of damages are rec- ognized.
