Summary of Contents for Slick MP517TM-2
- Page 1 ” Color Display User Guide MP517TM-2...
- Page 2 MP3 Music & Video Player USB 2.0 Cable Quick Start and Media Transfer (for battery charging *FULL USER GUIDE PROVIDED ON THE CD and high speed data transfer) 2 GB MP517TM-2 MP3 Music and Video Player Stereo Headphones Quick Start Guide...
-
Page 3: Fcc Information
FCC INFORMATION FCC Part 15 This equipment has been tested and found to comply with the requirements for a Class B digital device under Part 15 of the Federal Communications Commission (FCC) rules. These requirements are intended to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. -
Page 4: Copyright Information
INTRODUCTION Congratulations on purchasing the Slick MP3 Music & Video Player. This manual contains important safety information and correct operation instructions. Before using the player, read this manual thoroughly and keep it for future reference. Copyright Information Trademarks and trade names used in this instruction manual are owned by their respective companies or organizations. -
Page 5: Important Safety Precautions
IMPORTANT SAFETY PRECAUTIONS Always follow these basic safety precautions when using your player. This will reduce the risk of product damage and personal injury. Do not disassemble, repair or modify the player by yourself. Refer servicing to qualified personnel. This device contains a built- in battery, do not dispose of in fire. In the event that the battery is leaking, do not handle the device with your bare hands. - Page 6 FEATURES 1.5” color display 2 GB internal memory Built-in stereo speaker USB 2.0 high speed connection Stores and plays music, video, and pictures Text reading (txt format) Digital voice recording (built-in microphone) Folder navigation ...
-
Page 7: Location Of Controls
LOCATION OF CONTROLS 1. Earphone jack 2. USB cable connection port 3. Display screen 4. Hold switch 5. [ ] Previous, Fast Rewind 6. Microphone 7. [ ] Volume down ▬ 8. [ ] Enter main menu, Play/Pause, Confirm 9. -
Page 8: Connecting To A Computer
PC connection In order to enjoy the multimedia capabilities of your MP3 Player, you have to first copy your favorite files from your PC to it’s internal memory. Connect your MP3 Player to the computer using the included USB 2.0 cable. The device will be detected automatically without installing any driver. -
Page 9: Disconnecting The Usb Cable
Disconnecting the USB cable After completing the file transfer, please disconnect the USB cable the following way: 1. Double click the green arrow “Safely Remove Hardware” in the task bar on the bottom right of the window. 2. Select “USB Device” and click “Stop”. 3. -
Page 10: Charging The Battery
CHARGING THE BATTERY Your MP3 Player has an integrated rechargeable Li-ion battery. It is recommended to fully charge the player before using it for the first time Recharge the battery by connecting the player to a computer using the included USB 2.0 cable. -
Page 11: Basic Operation
This feature prevents you from accidentally pressing the buttons while using the player on the move. ● To lock all buttons of the MP3 player, slide the [HOLD] switch in the direction of the arrow. To deactivate the lock function, slide back the [HOLD] switch. -
Page 12: Transferring Media To The Player
1. Connect the MP3 player to the USB port of your computer. 2. Open “Windows Explorer” or “My Computer”, and locate “Slick MP3”. 3. Select the files on your computer, and simply move it into “Slick MP3” in the usual way (drag-and-drop, copy-and-paste). After copying is completed, the data will be available on the MP3 player. - Page 13 MAIN MENU To access the main menu, press and HOLD the [ selection. All available options are listed in the main menu table below. Music Music playback Photo Photo playback Movie deo playback Voice playback Mic. Record Voice recording E-BOOK Text view Settings Language...
-
Page 14: Playing Music
MUSIC Playing music Store and playback your favorite music on the MP3 Player. See “TRANSFERRING MEDIA FILES TO THE PLAYER” (page 11), to transfer music to your MP3 Player. 1. Select “Music” from the main menu, and press the [ 2. -
Page 15: Pausing Playback
Pausing playback While a song is playing, press the [ ] button to pause the playback. To resume the playback, press the [ Skipping tracks ● Press the [ ] button to skip to the previous track. ● Press the [ ] button to skip to the next track. -
Page 16: Using The Music Menu
USING THE MUSIC MENU The music menu allows you to manage all factors of listening, such as repeating tracks, selecting equalizers, and so on. 1. Press the [ ] button while in the music mode to enter the music menu. ... - Page 17 Equalizer The equalizer setting enables you to select from six preset settings, or choose “Custom” to adjust manually. 1. Press the [ ] button while listening to music to access the music menu. ] button to select “Equalizer”, and press the [ 2.
-
Page 18: Play Rate
3D Effect 1. Press the [ ] button while listening to music to access the music menu. 2. Use the [ ] or [ ] button to select “3D”, and press the [ ] button to select “On” or “Off”, and press the [ 3. - Page 19 PHOTO The MP3 Player is capable of storing your favorite pictures. See “TRANSFER- RING MEDIA FILES TO THE PLAYER” (page 11) to transfer pictures to the player and follow the steps bellow: 1. Select “Photo” from the main menu, and press the [ 2.
-
Page 20: Playing Videos
MOVIE / VIDEOS Store and playback your favorite videos to watch and enjoy anywhere! NOTE: You must convert a video to the correct format before transferring it to the player. See “Creating MTV videos” (page 21). Playing videos 1. Select “Movie” from the main menu, and press the [ ] button. -
Page 21: Setting Video Repeat Mode
Setting video repeat mode 1. Press the [ ] button while in the main video screen. 2. Press the [ ] button to select “Repeat”. 3. Use the [] or [] button to select one of the options below , and press the [ ●... - Page 22 Before transferring video files to the MP3 Player, you must convert them to the correct format. With the MTV Converter software tool you can easily convert most videos to the MTV format, so you can enjoy them on your MP3 Player.
-
Page 23: Converting Videos
Converting videos 1. Connect the MP3 Player to the USB port of your computer (optional). 2. Click on “Video Converter” from the “Start” menu, or the icon on your desktop. 3. Click on “Input Video” to search for and select videos on your computer. - Page 24 Converting videos 6. Click on “Output Video” to select the destination for the converted video. You can send it directly to your player by selecting “Slick MP3”, and clicking “OK”, or if you would like to save the converted video to your computer, we recommend sending it to your “Desktop” where you can easily find the video and transfer it to the player.
- Page 25 Converting videos 7. Click on “Start Conversion”. 8. When the conversion is complete, click on “OK”. 9. Copy the new MTV file to your player . See “TRANSFERRING MEDIA FILES TO THE PLAYER” (page 11) Converted video Click on “Start Conversion” Click “OK”...
- Page 26 2. To pause or resume recording, press the [ 3. To save the recording press the [ The recorded files are saved in the MICIN.DIR folder of the MP3 player as WAV files (format: MIC0000X.WAV) and can be listened to in the VOICE PLAYBACK mode.
-
Page 27: Moving To Previous/Next Page
E-BOOK View and enjoy your electronic books on the MP3 Player. NOTE: This player only supports the playback of files in TXT format, other formats must be saved as TXT format before transfer. 1. Select “E-BOOK” from the main menu, and press the [ ... -
Page 28: Navigating The Settings Menu
SETTINGS The player’s settings can be customized by accessing “Settings” in the main menu. The “Settings” menu consists of several options where various functions can be selected concerning language, play mode, recording, contrast, time off , storage, reset, etc. Navigating the settings menu This section describes how to access and change various features through the “Settings”... -
Page 29: Record Settings
Record Settings Set the microphone recording quality. NOTE: A higher frequency means higher quality recordings, however the recordable time will shorten. Contrast Adjust the contrast of the screen display. Timer Off ● Stop Off: Set the shutdown time. The player will turn off automatically if not used during the set time. ●... -
Page 30: Deleting Files
You can easily delete music, picture, or video files by connecting your MP3 Player to the computer and selecting “Slick MP3” from Windows Explorer or “My Computer”, or click on “Open Folder” to view files from the “Auto- Play” option window. Simply select the file and delete it as you would delete any other file from your computer. -
Page 31: Troubleshooting
My computer is not detecting the MP3 Player ● Try disconnecting and then re-connecting the MP3 Player to your computer ● There is a USB mass storage devices recognition issue with Windows Vista acknowledged by Microsoft. A solution is available in the Service Pack 1 which may be downloaded from Microsoft’s website... -
Page 32: Specifications
SPECIFICATIONS Audio Format MP3/WMA Photo Format JPEG/BMP Video Format MP3 bit Rate 32Kbps–320Kbps S/N rate ≥ 80dB Distortion <0.2% Power out 2 x 1mW(16 ohm load) Battery 350mAh Normal//Rock/Pop/Classic/Jazz/Ultra bass/Custom EQ Size 74.5 x 41 x 14 mm weight < 40g (without accessories) Frequency response 20Hz~20KHz Dynamic current... -
Page 33: Limited Warranty
LIMITED WARRANTY In the unlikely event that this product is defective, or does not perform properly, you may within ninety (90) days from your original date of purchase return it to the authorized service center for repair or exchange. TO OBTAIN WARRANTY SERVICE: - Provide proof of the date of purchase within the package (Dated bill of sale) - Prepay all shipping costs to the authorized service center, and remember to insure your return. - Page 34 To obtain service after the warranty period, please e-mail cs@southerntelecom.com with product information, date of purchase and nature of the problem. Customer service will reply to the e-mail with service instructions. Warranty service not provided: This warranty does not cover damage resulting from accident, misuse, abuse, improper installation or operation, lack of reasonable care, and unauthorized modification.
- Page 35 Manufactured by Southern Telecom Inc. Brooklyn, NY 11232 Slick is a registered trademark of Southern Telecom Inc. Brooklyn, NY USA © 2009 Southern Telecom Inc. All rights reserved. Microsoft, the Windows logo, and Windows Media are either registered trademarks or...
