- Page 1 C Prox Ltd (inc Quantek) 59 Sheffield Road, Dronfield, S18 2GF +44(0)1246 417113 sales@cproxltd.com www.quantek.co.uk Standalone Keypad Access Control DPS-T User Manual Please read the manual carefully before installing this unit...
-
Page 2: Packing List
1. Packing list Name Quantity Remarks Keypad User manual Φ20mm×60mm, special for keypad Screw driver Φ6mm×30 mm, used for fixing Rubber plug Φ4mm×28 mm, used for fixing Self tapping screws Star screws Φ3mm×6mm, used for fixing Please ensure that all the above contents are correct. If any are missing please notify us immediately 2. -
Page 3: Specification
4. Features Strong zinc alloy electroplated anti-vandal case Adjustable door output, alarm and door open times • • Full programming from the keypad Very low power consumption (30mA) • • 2000 users, supports card, PIN, or card + PIN Fast operating speed, <20ms with 2000 users •... - Page 4 7. Wiring Colour Function Description Green WG output D0 White WG output D1 Grey ALARM Alarm negative (alarm positive connected to 12/24V+) Yellow OPEN Exit button one end (the other end connected to GND) Brown D_IN Magnetic switch one end (the other end connected to GND) 12/24V + 12/24V + DC regulated power input Black...
- Page 5 8. To reset to factory default a. Disconnect power from the unit. b. Press and hold the # key whilst powering the unit back up. c. On hearing the two “Di” sounds, release the # key, system is now back to factory settings. Please note only installer data is restored, user data will not be affected.
- Page 6 To add a user in either card or PIN mode, i.e. in the .3. .2. .#. mode. (Default setting). To add a PIN user .User ID number. .#. .PIN. .#. The ID number is any number between 1 & 2000. The PIN is any four digits between 0000 &...
- Page 7 To change a PIN in card and PIN mode .Read card. .Old PIN. .#. .New PIN. .#. .New PIN. .#. (method 1) Change using card. Note that this is done outside of programming mode so the user can undertake this themselves. To change a PIN in card and PIN mode number.
- Page 8 Alarm output time To set the alarm output time (0-3 .0 – 3. .#. minutes). Factory default 1 minute Keypad lockout & alarm output options If there are 10 invalid cards or 10 incorrect PIN’s entered in a 10 minute period, either the keypad will lockout for 10 minutes or both the alarm and inside buzzer will operate for 10 minutes, depending on the option selected below.
- Page 9 Issue record Site: Door location: User ID No User name Card number Issue date 0001...
