- Page 1 RTL8812AE Half Mini-Card User’s Manual Rev. 1.0 29 November 2012 Realtek Semiconductor Corp. No. 2, Innovation Road II, Hsinchu Science Park, Hsinchu 300, Taiwan Tel.: +886-3-578-0211. Fax: +886-3-577-6047 www.realtek.com.tw...
- Page 2 Half Mini-Card User Manual COPYRIGHT © 2012 Realtek Semiconductor Corp. All rights reserved. No part of this document may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any means without the written permission of Realtek Semiconductor Corp.
-
Page 3: Table Of Contents
RTL8812AE Half Mini-Card User Manual Table of Contents GENERAL DESCRIPTION..............................1 FEATURES................................... 1 PRODUCT SPECIFICATIONS............................3 3.1................................3 NVIRONMENTAL 3.1.1. Operating ................................3 3.1.2. Storage..................................3 3.2............................3 UNCTIONAL PECIFICATIONS 3.3..................................5 ARNING 3.3.1 Federal Communication Commission Interference Statement ..................5 3.3.2 Industry Canada Statement ............................ -
Page 4: General Description
At the receiver, extended range and good minimum sensitivity is achieved by having receiver diversity up to 2 antennas. As the recipient, the RTL8812AE also supports explicit sounding packet feedback that helps senders with beamforming capability. With 2 independent RF blocks, the RTL8812AE can perform fast roaming without link interruption. - Page 5 RTL8812AE Half Mini-Card User Manual The RTL8812AE MAC supports 802.11e for multimedia applications, 802.11i and WAPI (Wireless Authentication Privacy Infrastructure) for security, and 802.11n/802.11ac Draft 2.0 for enhanced MAC protocol efficiency. Using packet aggregation techniques such as A-MPDU with BA and A-MSDU, protocol efficiency is significantly improved.
-
Page 6: Features
802.11n data rates Multiple Backward compatible with 802.11a/n devices BSSID feature allows RTL8812AE-CG to assume multiple MAC while operating at 802.11ac data rates. identities when used as a wireless bridge Host Interface Transmit Opportunity... - Page 7 RTL8812AE Half Mini-Card User Manual OFDM with BPSK, QPSK, 16QAM, 64QAM Peripheral Interfaces and 256QAM modulation. Convolutional Up to 12 General Purpose Input/Output pins Coding Rate: 1/2, 2/3, 3/4, and 5/6 Three configurable LED pins (mux with GPIO ...
-
Page 8: Product Specifications
RTL8812AE Half Mini-Card User Manual 3. Product specifications 3.1. Environmental 3.1.1. Operating 0 to 70 C Operating Temperature: Relative Humidity: 5-90% (non-condensing) 3.1.2. Storage -55 to 125 C Temperature: Relevant Humidity: 5-95% (non-condensing) 3.2. Functional Specifications Table 1. Functional Specifications Standards IEEE 802.11a/b/g/n/e/i/h/k/r/draft-ac... - Page 9 RTL8812AE Half Mini-Card User Manual WiFi 2.4GHz: 11: (Ch. 1-11) – United States 13: (Ch. 1-13) – Europe 14: (Ch. 1-14) – Japan WiFi 5GHz: 20MHz band width : Ch 36, 40, 44, 48, Ch 52, 56, 60, 64, Ch 100, 104, 108, 112, 116, 120, 124, 128,132,136, 140, Ch 149,153, 157,161, 165.
-
Page 10: Warning
RTL8812AE Half Mini-Card User Manual 3.3. Warning 3.3.1 Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 11: Industry Canada Statement
This transmitter module is authorized only for use in device where the antenna may be installed such that 20 cm may be maintained between the antenna and users. The final end product must be labeled in a visible area with the following: “Contains FCC ID: TX2-RTL8812AE”. Manual Information To the End User The OEM integrator has to be aware not to provide information to the end user regarding how to install or remove this RF module in the user’s manual of the end product which integrates this module. -
Page 12: Ncc 警語
RTL8812AE Half Mini-Card User Manual As long as conduction above is met, further transmitter test will not be required. However, the OEM integrator is still responsible for testing their end-product for any additional compliance requirements required with this module installed (for example, digital device emissions, PC peripheral requirements, etc.). The antenna must be installed such that 20 cm is maintained between the antenna and users. - Page 13 RTL8812AE Half Mini-Card User Manual Realtek Semiconductor Corp. Headquarters No. 2, Innovation Road II, Hsinchu Science Park, Hsinchu, 300, Taiwan, R.O.C. Tel: 886-3-5780211 Fax: 886-3-5776047 www.realtek.com.tw Rev.1.0...
