- Page 1 RTL8191SU PCI-Express miniCard User’s Manual Rev. 1.0 11 Sep 2009 Realtek Semiconductor Corp. No. 2, Innovation Road II, Hsinchu Science Park, Hsinchu 300, Taiwan Tel.: +886-3-578-0211. Fax: +886-3-577-6047 www.realtek.com.tw...
- Page 2 User’s Manual COPYRIGHT ©2009 Realtek Semiconductor Corp. All rights reserved. No part of this document may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any means without the written permission of Realtek Semiconductor Corp.
-
Page 3: Table Of Contents
4.5.1 Federal Communication Commission Interference Statement ..................9 4.5.2 INDUSTRY CANADA STATEMENT ................12 4.5.3 NCC 警語 ................................13 List of Tables 1. M PCI E ..........................8 ABLE XPRESS SSIGNMENT 2. F ............................9 ABLE UNCTIONAL PECIFICATIONS List of Figures 2. RTL8191SU ....................9 IGURE MINI ECHANICAL PECIFICATION Rev.1.0... -
Page 4: General Description
User’s Manual 1. General Description The Realtek RTL8191SU is a highly integrated single-chip MIMO wireless LAN (WLAN) solution for the wireless high throughput 802.11n draft specification. It combines a MAC, a 1T2R capable baseband, and RF in a single chip. The RTL8191SU provides complete solution for a high throughput performance wireless client. -
Page 5: General Features
• MIMO power saving mechanism • Channel management and co-existence • Multiple BSSID feature allowing RTL8191SU to assume multiple MAC identity when used as wireless bridge • Supports Wake-On-WLAN via Magic Packet and wake-up frame • TXOP SIFS bursting guarantees multimedia bandwidth... - Page 6 RTL8191SU User’s Manual Peripheral Interface • General Purpose Input/Output (8 pins) • 4-wire EEPROM control interface (93C46) • Configurable LED pins (2) • Configurable Bluetooth Coexistence Interface Rev.1.0...
- Page 7 RTL8191SU User’s Manual PHY Features IEEE 802.11n draft 2.0 MIMO OFDM 1 transmit and 2 receive paths (1T2R). 20MHz and 40MHz bandwidth transmission. Short Guard Interval (400ns). DSSS with DBPSK and DQPSK, CCK modulations with long and short preamble. OFDM with BPSK, QPSK, 16QAM, and 64QAM modulations. Convolutional coding rate: 1/2, 2/3, 3/4, and 5/6.
-
Page 8: Product Specifications
RTL8191SU User’s Manual 3. Product specifications 3.1. Mini PCI Express Pin Assignment Table 1. Mini PCI Express Pin Assignment PIN# Pin Name PIN# Pin Name WAKE# +3.3Vaux COEX1 COEX2 +1.5V CLKREQ# UIM_PWR UIM_DATA UIM_CLK REFCLK- UIM_RESET REFCLK+ UIM_VPP RESERVED RESERVED... -
Page 9: Mechanical
RTL8191SU User’s Manual 3.2. Mechanical Figure 1. RTL8191SU miniCard Mechanical Specification 3.3. Environmental 3.3.1. Operating 0 to 70 °C Operating Temperature: Relative Humidity: 5-90% (non-condensing) 3.3.2. Storage -20 to 85 °C Temperature: Relevant Humidity: 5-95% (non-condensing) 3.4. Functional Specifications Table 2. Functional Specifications IEEE802.11b;... -
Page 10: Warning
RTL8191SU User’s Manual 802.11g: 64 QAM, 16 QAM, QPSK, BPSK 802.11n: BPSK, QPSK, 16-QAM, 64-QAM Ad-hoc mode (Peer-to-Peer ) Network architecture Infrastructure mode Operating Channel 2.4GHz 11: (Ch. 1-11) – United States 13: (Ch. 1-13) – Europe 14: (Ch. 1-14) – Japan (Ch14 optional) Frequency Range 2.400GHz ~ 2.4835 GHz... - Page 11 This transmitter module is authorized only for use in device where the antenna may be installed such that 20 cm may be maintained between the antenna and users. The final end product must be labeled in a visible area with the following: “Contains FCC ID: TX2-RTL8191SU”. Manual Information To the End User The OEM integrator has to be aware not to provide information to the end user regarding how to install or remove this RF module in the user’s manual of the end product which integrates this module.
-
Page 12: Industry Canada Statement
RTL8191SU User’s Manual 2) this device must accept any interference, including interference that may cause undesired operation of the device This device has been designed to operate with an antenna having a maximum gain of 3.95 dBi. Antenna having a higher gain is strictly prohibited per regulations of Industry Canada. The required antenna impedance is 50 ohms. -
Page 13: Ncc 警語
RTL8191SU User’s Manual As long as conduction above is met, further transmitter test will not be required. However, the OEM integrator is still responsible for testing their end-product for any additional compliance requirements required with this module installed (for example, digital device emissions, PC peripheral requirements, etc.). - Page 14 RTL8191SU User’s Manual Realtek Semiconductor Corp. Headquarters No. 2, Innovation Road II, Hsinchu Science Park, Hsinchu, 300, Taiwan, R.O.C. Tel: 886-3-5780211 Fax: 886-3-5776047 www.realtek.com.tw Rev.1.0...
