EL-CO-H002
ITEM NO.:
The device EL-CO-H002 converts a signal from HDMI to 3G/HD/SD-SDI which providing the highest
quality images for professional audio-visual end users. It is designed for high performance video process
for post-production and broadcast applications.
Features:
Support video signal 480i, 576i, 720p, 1080i, 1080p.
Incoming HDMI signal must be YUV 4:2:2 encoded
Support SDI (SMPTE 259M), HD-SDI (SMPTE 292M), 3G-SDI (SMPTE 424M).
Support audio LPCM 7.1 Channel.
Installation:
Panel View:
EL-CO-H002
Recommend Cable:
Maximun 10 m HDMI input cable is recommended. High Speed cable type is preferred.
High quality 75Ω Coaxial Cable is recommended. Low quality coaxial cable may cause
signal loss and affect transmission distance and reliability.
HDMI to SDI CONVERTER
Elpro Video Labs Ed.1 October 2013
1
Advertisement
Related Manuals for ELPRO EL-CO-H002
Summary of Contents for ELPRO EL-CO-H002
- Page 1 Elpro Video Labs Ed.1 October 2013 EL-CO-H002 ITEM NO.: The device EL-CO-H002 converts a signal from HDMI to 3G/HD/SD-SDI which providing the highest quality images for professional audio-visual end users. It is designed for high performance video process for post-production and broadcast applications.
- Page 2 2. SDI output resolution and frequency is same as HDMI input. If your SDI monitor not support HDMI input resolution and frequency, then it won’t have picture at the monitor. Specification: ITEM NO. EL-CO-H002 SDI Standard / Protocol SDI (SMPTE 259M), HD-SDI (SMPTE 292M), 3G-SDI (SMPTE 424M) NTSC (480i), PAL (576i), 720p@50/59.94/60Hz,...
