User's Manual
SUN-GE8100 Network Management System
English
Table: SUN-UM-FTTH-OLT001
Version: A/0
All the trademarks mentioned in this manual are registered property of SUN Telecom.
The right to interpret this manual is reserved by SUN Telecom.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SUN-GE8100 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sun Microsystems SUN-GE8100

Summary of Contents for Sun Microsystems SUN-GE8100

  • Page 1 User’s Manual SUN-GE8100 Network Management System English Table: SUN-UM-FTTH-OLT001 Version: A/0 All the trademarks mentioned in this manual are registered property of SUN Telecom. The right to interpret this manual is reserved by SUN Telecom.
  • Page 2 Statement Shanghai SUN Telecommunication CO., Ltd., all rights reserved. Without the written permission of the copyright owner, any unit or individual shall not, in anyway, excerpt copy or translate this manual. Due to the constant renewal of products and technologies, the contents of the information may not completely match the actual product, please understand.
  • Page 3 Introduction Manual Instruction This is <SUN Telecom EPON Network Management System Operation User‘s Manual>, this manual is applicable to the EPON equipment with the SUN Telecom Network Management System. This manual is used for equipment setting instruction. Please read me before operation. Conventions 1.
  • Page 4 The simple operation procedure is linked with―→‖, such as → ―OLT→essentiainformation→enable‖, it means select OLT menu first, then the essential information, and the click the enable button in essential information. 3．Content Introduction Chapter Content EPON product interview 、features and introduction of network Chapter 1 Product introduction management.

  • Page 5: Table Of Contents

    Catalogue Chapter 1 Product Introduction ....................1 1.1 Product Interview ............................1 1.2 Interface and Indicator Light ........................1 1.3 Management Card Cable Connection ....................2 2.1 Config Preparation ............................3 2.2 Login Network Management Card Config .....................3 2.2.1 Telnet Login Network Management .....................3 2.2.2 Login network management by Console interface ..............4 2.3 Config the System Parameter of Management Card ................5 2.3.1 Command Format ..........................5...

  • Page 6: Chapter 1 Product Introduction

    F i b e r O p t i c S o l u t i o n s P r o v i d e r 1/31 Chapter 1 Product Introduction 1.1 Product Interview iCoreView is a Sun TELECOM‘s independent R&D EPON Network Management System based on SNMP V2c protocol, and it‘s compatible with SNMP V1.

  • Page 7: Management Card Cable Connection

    F i b e r O p t i c S o l u t i o n s P r o v i d e r 2/31 The left power fan stops The right power supply is normal PWRA The right power supply is off The left power supply is normal PWRB...

  • Page 8: Config Preparation

    F i b e r O p t i c S o l u t i o n s P r o v i d e r 3/31 Chapter 2 Config the system parameter of the management card 2.1 Config Preparation Supposed the user has inserted the management card in the right place of the chassis, and has finished the cable connection.

  • Page 9: Login Network Management By Console Interface

    F i b e r O p t i c S o l u t i o n s P r o v i d e r 4/31 (for first login, input default username: root, password: snmpman), then push the enter button, enter the telnet command line config interface, then see the command prompt , indicates successful login.

  • Page 10: Config The System Parameter Of Management Card

    F i b e r O p t i c S o l u t i o n s P r o v i d e r 5/31 2.3 Config the System Parameter of Management Card 2.3.1 Command Format Use sysconf to show the system basic information; use sysconf ? to see the help information as below: The primary command format of management card is shown as Table 2-1: Command format Description...
  • Page 11 F i b e r O p t i c S o l u t i o n s P r o v i d e r 6/31 Trap config  In config windows: Input sysconf trap and push enter ...

  • Page 12: Installation

    F i b e r O p t i c S o l u t i o n s P r o v i d e r 7/31 Chapter 3 EPON Network Management Software 3.1 Installation The EPON management software is a compressed file. 1.

  • Page 13: Enable Epon Network Management Software

    F i b e r O p t i c S o l u t i o n s P r o v i d e r 8/31  Alarm query: set the agent card TrapLInk pointing to server IP address, all the login server client can get the current alarm information, and check the history information.

  • Page 14: Close Epon Management Software

    F i b e r O p t i c S o l u t i o n s P r o v i d e r 9/31 3.3 Close EPON Management Software at the right Conner of the PC, choose ―Stop Service‖ Left click the icon , then you will see the below interface:...

  • Page 15: Chapter 4 Epon Network Management Software Config

    Chapter 4 EPON Network Management Software Config Users can use EPON SNMP software to manage and maintenance the devices directly; install and enable the device please refer to the Chapter 3. Before config any items, please make sure the connection between the PC and the agent is correct, and configure the agent IP address and alarm address (there is default IP existed) correctly through Telnet or Console port.

  • Page 16: Change User Password

    F i b e r O p t i c S o l u t i o n s P r o v i d e r 2/31 Figure 4-2 First Login 4.1.3 Change User Password Enter the configuration page, left click the main menu 【System】 --> 【ChangePassword】 as Figure 4-3, to change password.

  • Page 17: Basic Configurations

    F i b e r O p t i c S o l u t i o n s P r o v i d e r 3/31 resource, details refer to the main menu【Help】‖chapter 8‖ 4.2 Basic Configurations 4.2.1 Add device After enter the Figure 4-2 interface, need to add a device node, follow as below: In the topology browser, or choose a subnet in the topological view, right click the mouse, choose ―Add Device‖, see as Figure 4-4.
  • Page 18 Icon: necessary. The icon the node uses. Click the EPON Device icon, There are the manageable devices list supplied by SUN Telecom, then click the related EPON device. Here taken SUN-GE8100 as an example. Click ―Next‖, enter next property editing page. As Figure 4-5. Figure 4-6 This page includes below properties: Device type: necessary.
  • Page 19 F i b e r O p t i c S o l u t i o n s P r o v i d e r 5/31  Some properties in this page (SNMP version, SNMP port, read community, write community), we have config default value.
  • Page 20 F i b e r O p t i c S o l u t i o n s P r o v i d e r 6/31 Figure 4-8 This page includes below properties: Purpose: necessary. Identify the device is access layer device or integrated layer device; Integrator: optional.
  • Page 21 F i b e r O p t i c S o l u t i o n s P r o v i d e r 7/31 Figure 4-9 Please don‘t revise the property of this page, keep the default ones. After configuration, click the ―Finish‖...

  • Page 22: Two Ways To Check

    F i b e r O p t i c S o l u t i o n s P r o v i d e r 8/31 Figure 4-10 The configuration property wizard comes up. This wizard is the same with the former adding device wizard.

  • Page 23: Update Topology

    F i b e r O p t i c S o l u t i o n s P r o v i d e r 9/31 and choose 【 Open Subgraph】 , check the device topological view as 2.

  • Page 24: Check The Device Rack

    F i b e r O p t i c S o l u t i o n s P r o v i d e r 10/31 synchronization refer to: The status of the managed devices, cards, ports (these called resource) in the software be synchronized with the real devices status.

  • Page 25: Description Of The Device Icon

    F i b e r O p t i c S o l u t i o n s P r o v i d e r 11/31 Figure 4-15 4.2.5 Description of the Device Icon If there is no mark on the icon like , it resents the devices work normal, OLT and ONU are online.

  • Page 26: Olt Configuration Management

    F i b e r O p t i c S o l u t i o n s P r o v i d e r 12/31 Minor Alarm (Minor) ：Alarm event occurs but do not affect the operation of the service. Marked in yellow: Warn Alarm (Warn) ：The service is operating in order.
  • Page 27 F i b e r O p t i c S o l u t i o n s P r o v i d e r 13/31 Figure 4-17 Click the 【Bridge Parameter】 again, the right list will display the OLT bridge parameters, as Figure 4-18.To revise the bridge parameter, needs to click the row firstly, then click【Modify】, revise the parameters in the popup dialog box, after revise, click apply.
  • Page 28 F i b e r O p t i c S o l u t i o n s P r o v i d e r 14/31 Figure 4-19 OLT basic function information description, as table 4-1. Menu Function Description 【class Info】...
  • Page 29 F i b e r O p t i c S o l u t i o n s P r o v i d e r 15/31 one is accession. There are three operations under the three modes: Undefined, Allow and Deny, these can manage the ONU access.

  • Page 30: Olt Config

    F i b e r O p t i c S o l u t i o n s P r o v i d e r 16/31 Figure 4-21 Right click ONU, choose 【Deactive ONU】, the access mode changes to Deny, communication between ONU and OLT break off.
  • Page 31 F i b e r O p t i c S o l u t i o n s P r o v i d e r 17/31 as Table 4-2. Figure 4-23 Menu Function Description 【Network Params】 Revise the VLAN Ethernet type passing through OLT (suggest use the default value 8100), add tags to uplink and downlink (suggest not config this) 【Broadcast SLA】...

  • Page 32: Olt Uplink Port Config

    F i b e r O p t i c S o l u t i o n s P r o v i d e r 18/31 Menu Function Description 【Maximum Bandwidth】 Maximum data transmission rate 【Minimum Bandwidth】 Minimum data transmission rate Sensitive: distribute a fixed bandwidth to the link, let the link data queue empty Tolerant: only when the link data queue is empty, the bandwidth allocated to the 【Mode】...

  • Page 33: Olt Bridge Parameter Config

    F i b e r O p t i c S o l u t i o n s P r o v i d e r 19/31 Figure 4-24 Port speed: set port speed Duplex Mode: set port working mode to full duplex or half duplex Flow Control: enable or close 802.1x flow control Port Adaptive Management: choose port adaptive mode, default is enable Discard Packets with Length Errors: such as small data packet...

  • Page 34: Olt Senior Management Config

    F i b e r O p t i c S o l u t i o n s P r o v i d e r 20/31 AGE Limit: set OLT aging time, default is no configuration Downstream Frame ResetAging: Reset aging to downstream frame, this configuration effects to all the MAC table entries.

  • Page 35: Onu Hardware Config

    F i b e r O p t i c S o l u t i o n s P r o v i d e r 21/31 4.4.2 ONU Hardware Config As Figure 4-26. Figure 4-26 【ONU Config】-->【Hardware】, details as Figure 4-5 Menu Function Description 【Device Information】...
  • Page 36 F i b e r O p t i c S o l u t i o n s P r o v i d e r 22/31 【Port UpStream Statistics】 Port upstream statistics Table 4-5 【Bridge Config】 as Figure 4-27. Figure 4-27 ONU Learn MAC Entries Limit: limit the MAC address number of devices connected to the ONU, if not limit, config 0.
  • Page 37 F i b e r O p t i c S o l u t i o n s P r o v i d e r 23/31 Figure 4-28 Port speed: config port speed Duplex Mode: set port working mode full duplex or half duplex Flow Control: enable or close 802.1x flow control Port Adaptive Management: default is enable Discard Packets with Length Errors: such as small data packets...

  • Page 38: Onu Config

    F i b e r O p t i c S o l u t i o n s P r o v i d e r 24/31 Figure 4-29 Auto Learn MAC Entries Limit: maximum 64, if not limit, config it to 0. Age: config the MAC aging time, maximum 32768;...
  • Page 39 F i b e r O p t i c S o l u t i o n s P r o v i d e r 25/31 Menu Function Description 【Port VLAN】 Config ONU port VLAN 【RSTP Settings】 RSTP Setting 【RSTP State】...
  • Page 40 F i b e r O p t i c S o l u t i o n s P r o v i d e r 26/31 discard No VLAN VID Add default VID (VLAN Tag) and forward Downstream With VLAN VID If the original VID is the same with forward VID (in tag), divest the VID, add new tag (In Tag) and forward;...
  • Page 41 F i b e r O p t i c S o l u t i o n s P r o v i d e r 27/31 Figure 4--32 Note: if VLAN mode can‘t switch directly between TAG mode and Translated mode, must config VLAN mode to Transparent mode and then config new mode;...
  • Page 42 F i b e r O p t i c S o l u t i o n s P r o v i d e r 28/31 Config 4-33 ONU will add VID 100 tag to the data packet without VID, and discard the data packet with VID. 【RSTP Settings】...
  • Page 43 F i b e r O p t i c S o l u t i o n s P r o v i d e r 29/31 Figure 4-44 ONU supports RSTP (Rapid Spanning Tree Protocol) function. It is simple to config RSTP function. Under default mode, choose Enable in the Mode options under config panel.
  • Page 44 F i b e r O p t i c S o l u t i o n s P r o v i d e r 30/31 Maximum Age: config the aging time. If this value is too small, the spanning tree counts frequently, this will covers much resource;...

  • Page 45: Onu 802.1X Management

    F i b e r O p t i c S o l u t i o n s P r o v i d e r 31/31 【RSTP State】 Enable RSTP, the whole spanning tree status can check in the【State】table, as Figure 4-45. Figure 4-45 4.4.4 ONU 802.1x Management 【ONU Config】-->【802.1x】, not available at present.
