- Page 1 Installation and Operation Guide Installation and Operation Guide DMR Repeater SBR8040/SCR8040/SER8040...
-
Page 2: Table Of Contents
Duplexer specifications ............13 Original Instructions: ENGLISH All rights reserved. This document is intended for the use of Sepura plc’s customers and/or other parties only for the purposes of the agreement or arrangement under which this document is submitted, and no part of it may be reproduced or transmitted... -
Page 3: Safety
RF wireless devices. Safety Accessories Sepura products have been tested to meet strict guidelines for Read these safety instructions carefully. personal safety and operational conditions. Only accessories Attention! approved by Sepura are recommended for use with this product. - Page 4 Installation and Operation Guide environment. The antenna should be installed and operated Le présent appareil est conforme aux CNR d'Industrie Canada with minimum distance 1.0m from human body. applicables aux appareils radio exempts de licence. This transmitter must not be co-located or operating in L'exploitation est autorisée aux deux conditions suivantes: conjunction with any other antenna or transmitter.
-
Page 5: Regulatory
Please dispose of your waste product according to your national and local regulations. Contact Sepura or your Service Provider for information about disposing of this product in your region of the world. -
Page 6: Technical Specification
Installation and Operation Guide Technical specification Frequency Range ........... 400-470 MHz Dimensions (WxDxH) ....482.5 x 338.5 x 132.5 mm (3U) Weight ................12.5 Kg Power Supply AC ....... 100-120V@2.5A 50/60 Hz 200-240V@1.5A 50/60 Hz Power Supply DC ........... 10.8 – 15.6V@15A DC Fuse ............... - Page 7 DMR Repeater SBR8000, SCR8000, SER8000 Front Panel Rear Panel...
-
Page 8: Controls, Connectors And Components
Installation and Operation Guide Controls, connectors and Status indicators components The Repeater has a series of LEDs on the front panel that indicate various operational states. Refer to the illustration for the location of the following controls, connectors and buttons. (1) Handles (2) Status indicators (3) Power switch... -
Page 9: Unpacking
DMR Repeater SBR8000, SCR8000, SER8000 Unpacking Accessory information Sepura supply a range of accessories for this product. Contact your Service Provider or visit our website for a full list of accessories. Accessory Part No. Wall mount bracket 300-01071 AC Power cable (UK) -
Page 10: Installation
Installation and Operation Guide Installation Wall-mount bracket installation Guidelines and recommendations It is important that the repeater does not exceed the working limits detailed in the technical specification section of this guide. When rack mounting the repeater, ensure sufficient air flow to prevent overheating and secure the unit within the rack system. -
Page 11: Attaching The Desk Mount Feet
DMR Repeater SBR8000, SCR8000, SER8000 Hold the bracket securely, keeping it level. Secure into Attaching the desk mount feet position using the ST6 x 35 expansion screws. Ensure that the bracket is secure and level. If the repeater is installed onto a desk or bench, the four screw type desk mount feet, supplied with the product, should be Remove the desk mount feet (if fitted) from the repeater. -
Page 12: Connections
Installation and Operation Guide must be positioned close to the DC power source positive Connections terminal. All connectors are located on the back panel of the repeater. CAUTION! Failure to connect the wires to the correct terminal of the battery or power supply may damage the product and void Ensure that the cables are routed so that they are kept well clear any warranty. -
Page 13: Basic Operation
DMR Repeater SBR8000, SCR8000, SER8000 Basic operation Alarm mode The Alarm indicator on the front panel illuminates when certain Power on/off operational states warrant. When the repeater is in start-up To switch the repeater on, operate the Power on/off switch. The mode, the LED remains illuminated for the duration of the start- Power on/off status indicator illuminates and the repeater runs a up routine (approx. -
Page 14: Caring For Your Product
Installation and Operation Guide Caring for your product Duplexer specifications The product does not require regular servicing. Caring for your An optional duplexer can be used with the repeater. The product as described in this guide will help maintain the product duplexer allows the repeater’s receiver and transmitter to in good operational condition. - Page 15 Sepura plc Radio House St Andrew’s Road Cambridge CB4 1GR Tel: +44 (0)1223 876000 Fax: +44 (0)1223 879000 Sepura.com...
