- Page 1 Installation Guide for: Scotsman DXN Ice & Water Dispenser Installation Guide for Scotsman DXN Dispenser...
- Page 2 Counter top location for DXN Dispenser to have service hole cut at rear of unit location to allow Water, Waste and Electric services to be fed down into connection points underneath (* See Next Page) Installation Guide for Scotsman DXN Dispenser...
- Page 3 PLAN VIEW OF THE ‘DXN’ UNIT AND THE SUGGESTED POSITION FOR THE ‘CUTOUT’ THROUGH THE COUNTERTOP THE UNIT STANDS ON: HOLE POSITION & SIZE SUGGESTED: 150mm X 75mm R E A R of U N I T 427mm 545mm F R O N T...
- Page 4 Example of under-counter DXN service arrangement Electric – 13 Amp Twin Socket or Suitable 20 Amp Double pole fused isolator. Waste – Minimum 38mm Trapped & Vented Drain, with ‘Air Gap’ Fitting mounted on entry Water – 15mm Potable Water...
- Page 5 Connect drain hose to main waste drain provided by inserting hose into upstand (similar to domestic washing machine). Note: To prevent drainage problems caused by loops in the hose, reduce hose length as far as reasonably practicable. Installation Guide for Scotsman DXN Dispenser...
- Page 6 Start Up Procedure for DXN (TFREE) Models A. Open the water supply shutoff valve and turn unit on by the ON/OFF green push button, the machine will enter into a 10 minutes delay time with two complete purge and refill of the water reservoir, dØ1 (purge time) and dØ2 (refill time) code monitor this condition on...
