- Page 1 SOLAR COLLECTORS SOLAR SC-F25/1 INSTALLATION INSTRUCTIONS...
- Page 2 Solar Keymark certification standard. RANGE MODEL CODE SC-F25/1 20014637 Kit of 2 collectors SC-F25/1 20014640 Kit of 5 collectors SC-F25/1 20014641 The following symbols are used in this manual: CAUTION! = Indicates actions that require caution and adequate preparation...
- Page 3 You have purchased a modern product that is easy to install and use, and is designed to give you dependable and safe energy savings for many years to come. You can keep your new solar collector in peak condition by having it serviced regularly by an authorised Beretta Technical Assistance Centre.
-
Page 4: Table Of Contents
CONTENTS 1 GENERAL SAFETY INFORMATION AND PRECAUTIONS ......5 2 DESCRIPTION OF ThE SOLAR COLLECTOR ..........6 Description ............................Identification ............................Design ..............................Technical specifications ........................Accessories ............................Collectors connection ........................... Water circuit ............................10 Location of probes ..........................11 3 FOR ThE INSTALLER.................. -
Page 5: General Safety Information And Precautions
1 GENERAL SAFETY INFORMATION AND PRECAUTIONS As soon as you open the packaging, Before beginning installation work on check immediately that the contents are roofs, install the necessary fall prevention all present and undamaged. Contact the and fall arrest devices and ensure that all reseller from whom you purchased the applicable safety standards are applied. -
Page 6: Description Of The Solar Collector
2 DESCRIPTION OF ThE SOLAR COLLECTOR DESCRIPTION These panel type solar collectors have two second group of 6 pipes to the top manifold water fittings and consist of an aluminium again. This effectively doubles the thermal structure with a single-piece copper absor- length of the collector. -
Page 7: Design
Design Collector Collector outlet return Collector probe socket Direction of flow of heat transfer liquid Glass 3,2 mm Connection ring nut, 1" Connector Ø 22 mm. -
Page 8: Technical Specifications
Technical specifications DESCRIPTION Total area 2,43 Exposed area 2,20 Effective absorption area 2,15 Connections (M) - (F) 1" Ø Empty weight Liquid content Recommended flow rate per m of panel Glass thickness Absorption (α) ~ 95 Emissions (ε) Maximum permitted pressure Maximum temperature °C Maximum number of collectors connectable in series... -
Page 9: Collectors Connection
Collectors connection The diagram below illustrates the connections between solar collectors in lines. The collectors in a line are connected so that the heat transfer fluid goes through them in series. The connection with the heat transfer circuit that goes toward the heat exchanger must be the one near the sensor pocket of the last collector of the line (see the picture above). -
Page 10: Water Circuit
Water circuit The diagram below illustrates the water connections between solar collectors and a storage heater. 1 - Solar collector 2 - Storage heater 3 - Collector probe 4 - Disconnect valves 5 - Non-return valve 6 - Temperature gauge 7 - Vent valve 8 - Safety valve °C... -
Page 11: Location Of Probes
Location of probes The temperature sensor must be installed in the nearest socket to the collector outlet. Make sure that the sensor makes good contact with the socket. Materials (sensor, cables, seals and insulation) used to install the temperature sensor must be able to withstand high temperatures (up to 250°C). SOLAR REGULATOR °C... -
Page 12: For The Installer
3 FOR ThE INSTALLER Unpacking the collector The solar collectors are packed in various ways depending on the number of units supplied: A - Individually packaged collectors or Case A packages of 2 collectors Pallet contents: - collector/s - Documentation envelope containing: - certificate of warranty and label with bar code. -
Page 13: Dimensions And Weight
Dimensions and weight 1221 1186 Net weight handling the collector Once you have removed the outer packag- ing, proceed as follows to unpack and handle the solar collector: - Remove the PVC wrapping to free the solar collector from the pallet. - Tilt the solar collector slightly and grip it at the four points shown (A) to lift it. -
Page 14: Installation
Installation Assembly All pipes in the water circuit must be insu- The solar collector must be fitted by specialist lated in conformity to relevant standards. personnel. Use only the assembly material sup- Lagging and insulation must be protect- plied with the solar collector. The supporting ed against damage by the weather and framework and all masonry or brickwork fixing birds and animals. -
Page 15: Filling The Circuit
Make sure that the collectors are not simeter to check the anti-freeze effect (which hot before you start bleeding the circuit. must have a nominal protection value of approx. Always cover the solar collectors before -30°C). If the protection threshold is higher than bleeding the circuit. -
Page 16: Checks
3 - FILLING Manual 1 - Open the non-return valve (A). bleed valve (accessory) 2 - Open the air vent at the highest point in the Solar collector system (see figure alongside) and keep it open throughout the filling operation. 3 - Open the vent valve (7). - Page 20 Via Risorgimento, 13 - 23900 Lecco (LC) Servizio Clienti 199.13.31.31* Assistenza Tecnica Numero Unico 199.12.12.12* www.berettaclima.it The manufacturer strives to continuously improve all products. Appearance, dimensions, technical specifications, standard equipment and accessories are therefore liable to modification without notice.
