- Page 1 English Coatlift 717 Doc. No: M717 Edition: 1 Date: 2009-04-02 INSTRUCTION MANUAL Wardrobe lift 717 Granberg Interior AB Box 6112 SE-600 06 Norrköping SWEDEN...
- Page 2 For more information, see: www.granberg.se...
-
Page 3: Table Of Contents
Content Section: Headline: Page: Introduction ..............................4 Declaration of Conformity ........................4 Intended use - Technical data .........................4 Installation instructions: Mechanical construction ...........................5 Delivery modules ............................5 Location of electric connections ......................5 Installation of the lifting mechanism ....................... 6 Location of push button unit ........................9 Operational test ............................9 Operator’s information: Safe use ................................. -
Page 4: Introduction
Introduction We have the pleasure to deliver a Granberg Interior Wardrobe lift 717, an electrically operated lifting and lowering system for installation in new or existing wardrobes. The Wardrobe lift has got a clothes-rail, where clothes can be hung. With the push button box the motorized clothes-rail is lowered to a convenient height for handling the clothes. -
Page 5: Mechanical Construction
Mechanical construction Picture 1 The Wardrobe lift 717 comprises two lift mechanisms, to be placed on the left and right side in the wardrobe. The rail tube connects the mechanisms together. See picture 1. The curved lifting and lowering motion is achieved by an electrically powered screw jack with a control unit, containing a contactor and the control voltage transformer for 24 V DC control voltage. -
Page 6: Installation Of The Lifting Mechanism
Installation of the lift mechanism and guide arm To consider before installation: The dimensions of the wardrobe must be suitable for the size of the Wardrobe lift as well as for the space required for the clothes. A standard wardrobe with inside height 1918 mm and depth minimum 565 mm is suitable. The location of the lift is adapted for the wardrobe size, the clothes and the desired height when lowered. - Page 7 ..3 .. Operate the lift arms to the shown position acc. to picture below. Operate the lift arms to the shown position acc. to picture below.
- Page 8 .. Measure and mark the location on the left and right hand inside of Measure and mark the location on the left and right hand inside of the cabinet where the lift mechanisms shall be fixed The A-measure must not be less than 465 mm. The A-measure must not be less than 465 mm.
-
Page 9: Location Of Push Button Unit
..11 Location of the cable hand control: Location of the cable hand control: A handheld cable hand control is delivered as standard, and this shall be placed in the wardrobe, or on the inside of the ward- robe door. Thereby it is prevented that the Wardrobe lift is operated before the door has been opened. Check the position of the cable carefully, so that it cannot be jammed. -
Page 10: Safe Use
During inspections, service and repair work there shall be no clothes on the lift. • Competent persons only must carry out installation, service and repair works. • Only Granberg original spare parts shall be used when replacing any parts. Our warranty commitment can otherwise be invalidated. -
Page 11: Load Distribution And Side Forces
Further to the incorporated safety arrangements additional can safety actions may be required on or at the Wardrobe lift. Discuss suitable actions with your Granberg representative or with the health and safety inspection. We recommend that a Risk assessment in accordance with the Machinery Directive shall be made for the actual working conditions. -
Page 12: Cleaning
When the Wardrobe lift shall be re-used shall it must be cleaned, inspected and go through a full operation test before it is installed on the new site. We recommend the machine to be sent to Granberg or to the Granberg distributor to get this done. The machine is manufactured from re-usable materials or from materials that can be recycled. -
Page 13: Decals
Damages caused by misuse or incorrect operation of the equipment means that the warranty would expire. Before any warranty work is commenced by a customer Granberg must be contacted for analysis and approval. We do not ac- cept to carry any warranty costs if the repair work has started without an agreement by us. -
Page 14: Faultfinding
Return of spare parts: Contact Granberg prior to any return of parts. Do not return any parts that have been worn out during normal operation or accidentally damaged. Only return worn or damaged parts if it is considered that the fault is covered by our warranty conditions. -
Page 15: Electric Circuit Diagram
Electric circuit diagram CE-Declaration of conformity (According Machinery Directive 98/37/EC, Annexe 2A) Manufacturer: Granberg Interior AB Tel. +46-11-19 77 50 Box 6112, Fax +46-11-12 76 76 SE-600 06 NORRKÖPING, Sweden declares under sole responsibility that the product: Space for machine plate... - Page 16 Box 6112 SE-600 06, Norrköping Sweden Tel: +46 (0)11-19 77 50 Fax: +46 (0)11-12 76 76 E-mail: info@granberg.se - Internet: www.granberg.se...
