Chapter 2 –UFED Configuration:
Ruggedized and Standard Versions
2.5.
Power and Battery Options
The UFED device can be powered by an AC power supply, a car power
supply, or by battery power. (NOTE: car power supply and battery pack
come with the Ruggedized Kit only.)
Battery Power
To run the UFED on battery power, flip the power switch to the right ("BAT")
position. Battery power will take over.
Charging the Battery
To re-charge the battery, connect the device to an AC adapter (supplied with
the kit), and then flip the power switch to the left ("CHG") position.
LED Indicator
The LED indicator provides input regarding the state of the UFED power:
LED Status
Red
Green
No light
Flashing Red
8
Indication
Battery charge in process
Battery fully charged
Sleep mode (no input power source) OR
No battery connected OR
Charge suspended (timer fault or thermal shutdown)
OR Over-voltage fault
Indicates a problem with the battery. Verify that the
battery is connected properly.
UFED System
