Summary of Contents for Panduit PViQ PU 1

  • Page 1 MN023 Version 1.0...
  • Page 2 Networked POU Copyright © 2010 PANDUIT Corp. All rights reserved. No part of this book shall be reproduced, stored in a retrieval system, or transmitted by any means, electronic, mechanical, photocopying, recording or otherwise, without written permission from PANDUIT. No patent liability is assumed with respect to the use of the information contained herein.
  • Page 3: Table Of Contents

    Networked POU Contents SPECIFICATIONS ..........................4 Overview ............................4 Environmental ..........................4 Temperature .........................4 Humidity ..........................4 Elevation ..........................4 Electrical.............................4 Receptacle Ratings ........................4 Networking ..........................4 Protocols ..........................4 Ethernet Link Speed ......................4 Data Formats ..........................5 EMC Verification ........................5 INSTALLATION ..........................6 Instructions ..........................6 Guidelines ..........................6 MOUNTING .............................7 "L"...
  • Page 4: Specifications

    Networked POU Specifications Overview The POUs are designed to be powered by either a single phase or a three phase AC input circuit. Three phase units are available for either a Delta or WYE input connection. Environmental Temperature Operating: 10°C (50°F) min 45°C (113°F) max Storage: -25°C (-13°F) min...
  • Page 5: Data Formats

    Networked POU Data Formats HTML, SNMP, XML EMC Verification This Class A device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 6: Installation

    1. Using appropriate hardware, mount POU to rack. 2. Plug POU into de-energized receptacle 3. Connect devices into POU’s output receptacles. Panduit recommends that the devices are turned off until all devices are connected to POU. 4. Turn on branch circuit to energize POU.
  • Page 7: Mounting

    Networked POU Mounting "L" Bracket Affix Power Strip Mounting mounting brackets using #12-24 screws provided into tapped holes in the front or the sides of the post. Power Strip Mounting Brackets can also be mounted to the rear equipment rails. To center the 66.25”...
  • Page 8: Toolless Mounting Hardware

    Networked POU Toolless Mounting Hardware Use toolless buttons with key-holed slots built into cabinet or with optional key-holed brackets. Version 1.0...
  • Page 9 Networked POU Panduit Cabinet CS3 Version 1.0...
  • Page 10: Networked Monitoring

    Connections.” 3. Right Click on “Local Area Connection” and select “Properties.” Actual configuration of circuits measured by the PViQ Monitor is POU model specific. Please contact Panduit Technical Support with questions on measurement configuration of PViQ Monitoring Meters. Version 1.0...
  • Page 11 Networked POU 4. Select the option to “Use the following IP address” and enter: IP address: 192.168.123.1 Subnet mask: 255.255.255.0 Default gateway: 192.168.123.1 Click “OK” twice. You can now access the unit using your web browser at the permanent IP address of 192.168.123.1. Typical Network Card Settings for PC or Laptop to connect to default IP address In some configurations, leaving the gateway field blank may resolve connectivity issues.
  • Page 12: Accessing The Pou Web Gui

    Networked POU Accessing the POU Web GUI Once you have properly set the IP Address for a unit, you can connect to the unit through a Web GUI. The Panduit POU Web GUI consists of five tabs: • Current Monitoring •...
  • Page 13: Display Tab

    Networked POU Display tab The Display tab allows you to enter user friendly names for the POU, the Unit Location, and an Admin Contact. You can also enter individual names for each circuit. A sample of the Display tab screen is shown below. Display tab using the Web GUI Version 1.0...
  • Page 14: Alarms Tab

    Networked POU Alarms tab The Alarms tab provides a current count of the number of warnings and alarms generated for the unit. Individual warning and alarm counts are displayed for each circuit. A sample of the Alarms tab screen is shown below. Alarms tab using the Web GUI Version 1.0...
  • Page 15: Configuration Tab

    Networked POU Configuration tab The Configuration tab provides access to various Network and SNMP settings for the unit. A sample of the Configuration tab is shown below. Configuration tab using a web browser Version 1.0...
  • Page 16: Led Display

    Networked POU LED Display Each POU has a built-in 4-digit LED display mounted midway down the chassis. The display scrolls through the most recent current measurement (in amps) for each circuit, one at a time. It displays a circuit name, pauses, and then displays the measurement. Momentarily press the “Pause Scroll/IP Address Reset”...
  • Page 17: Rebooting The Meter

    Networked POU Scroll/IP Address Reset” has been released. Once the IP address has been reset, the Setting an IP Address instructions should be followed to access the unit. Rebooting the Meter Should an Current Monitoring Meter with firmware version 1.36 or higher installed stop responding to network traffic, it is possible to restore functionality by rebooting the meter without removing power from the POU it is enclosed in.
  • Page 18: Sample Usage

    Networked POU Sample Usage The simplest way to get data from a Current Monitoring Meter into a script is via the XML page. Simply performing an HTTP GET (as a web browser does) on http://<IP address of meter>/data.xml will download the XML file. The following examples assume that the meter’s IP address is 192.168.123.123. Perl Example: using LWP::UserAgent;...
  • Page 19: Service And Technical Support

    No serviceable parts inside. Panduit recommends that power be removed from the unit before installing or removing any equipment. Technical Support For Technical Support on the PViQ POU please contact Panduit Technical Support using one of the following methods: •...
