5-light 30" Studio
Makeup Station
Contents
Important User Information . . . . . . . . . . . . . . . . . . . . . . . . . . .2
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Manufacturer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Intended Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Required Tools. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Fasteners - Not Supplied . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Note: Please read and understand these instructions before assembling.
Note: If you need additional information, contact Wenger Corporation using the information below.
©Wenger Corporation 2018
Wenger Corporation, 555 Park Drive, P.O. Box 448, Owatonna, Minnesota 55060-0448
Questions? Call.....USA: (800) 4WENGER (493-6437) • Worldwide: +1(507) 455-4100 • www.wengercorp.com
8-light 30" Studio
Makeup Station
Before Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Printed in USA 2018-03
Installation Instructions
Studio
Makeup Station
®
6-light 36" Studio
9-light 36" Studio Makeup
Makeup Station
Before Starting Assembly . . . . . . . . . . . . . . . . . . . . . . . .5
Lighting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Layout the Space . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Install Mounting Bracket . . . . . . . . . . . . . . . . . . . . . . . . .8
Install First Makeup Station . . . . . . . . . . . . . . . . . . . . . . .10
Install Additional Makeup Stations . . . . . . . . . . . . . . . . .14
Complete The Installation . . . . . . . . . . . . . . . . . . . . . . . .14
Attach The Mirror . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Attach The Counter . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Connect The Electrical Source . . . . . . . . . . . . . . . . . . . .16
Tackboard Installation . . . . . . . . . . . . . . . . . . . . . . . . . . .16
30" and 36" Models
Station
Part #187A200-06
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Wenger 9-light 36" Studio Makeup Station
Summary of Contents for Wenger 9-light 36" Studio Makeup Station
-
Page 1: Table Of Contents
Tackboard Installation ......16 Note: Please read and understand these instructions before assembling. Note: If you need additional information, contact Wenger Corporation using the information below. ©Wenger Corporation 2018... -
Page 2: Important User Information
Wenger Corporation. Wenger Corporation does not assume any responsibility for any errors that may appear in this manual. In no event will Wenger Corporation be liable for technical or editorial omissions made herein, nor for direct, indirect, special, incidental, or consequential damages resulting from the use or defect of this manual. -
Page 3: Safety Precautions
Safety Precautions Throughout this manual you may find cautions and warnings which are defined as follows: • WARNING means that failure to follow the instruction may result in serious injury or death. • CAUTION means that failure to follow the instruction may result in serious injury or damage to property. -
Page 4: Parts List
Parts List The Makeup Station is shipped with all components in a single box, the main assembly, a corrugated sleeve containing the Mirror, a hardware bag, the Counter under the main assembly, the Tackboard Assembly (36" Model only) in a corrugated sleeve, and the Wall Mounting Bracket. (1) Self-drill Screw, (3) Phillips Head (2) Hex Flange Nut, 3/8-16... -
Page 5: Before Installation
Before Installation Before Starting Assembly Before installing the Studio Makeup Station, do the following. 1. Read and understand this installation instruction completely. 2. Open all cartons and make sure each includes a Studio Makeup Station, a hardware bag, the Wall Mounting Bracket, a Tackboard (36" Model only), a Mirror (packaged in a corrugated sleeve) and a Counter. -
Page 6: Lighting
Lighting The Studio Makeup Station is shipped without light bulbs. Wenger recommends the use of 40-watt or 60-watt incandescent bulbs or 15 watt full-spectrum swirl fluorescent bulbs. Ambient lighting conditions may influence the choice of bulb type and power rating. - Page 7 Before Installation (continued) Layout the Space (continued) * 17-1/2" (445 mm) for 30" Model ** 30" (762 mm) for 30" Model Corner 20-1/2" (521 mm) Minimum Distance to a Wall* Top Edge of 36"** Mounting Bracket (914 mm) Top Surface 36"** of Shelf (914 mm)
-
Page 8: Installation
Installation Install Mounting Bracket 1. Remove the Mounting Bracket from the shipping box. 2. Locate the Hardware Bag and set it aside. 3. Align the Mounting Bracket to the wall with the top edge of the Mounting Bracket on the Horizontal LIne and the centerline of the Mounting Bracket (user must mark the Bracket centerline with chalk) aligned to the Station Centerline on the wall as shown below. - Page 9 Installation (continued) Install Mounting Bracket (continued) 5. For walls with metal stud construction do as follows. a. Hold the Mounting Bracket in place and note the position of the studs. Note: the mounting bracket must cross at least one stud. b.
-
Page 10: Install First Makeup Station
Installation (continued) Install First Makeup Station 1. Remove the four Flange Nuts, 3/8-16, from the hardware bag. 2. Screw (clockwise) a Flange Nut, 3/8-16, onto each each of the two Mounting Bracket Studs with the Flanges facing upward as shown below. Position the Flange Nuts so that the flange of the nut is one-half inch from the top edge of the Mounting Bracket. - Page 11 Installation (continued) Install First Makeup Station (continued) 6. With two people working together, tilt the Makeup Station into an upright position. a. Only handle the Makeup Station by grasping the Steel Frame — do not lift or handle the Makeup Station by grasping the Light Cages or the Shelf. Note: Always start a row with a 6-light unit or a 5-light unit on the left end.
- Page 12 Installation (continued) Install First Makeup Station (continued) 7. Attach the 6-light or 5-light Makeup Station to the left-hand Mounting Bracket as follows. a. With two people working together, grasp the Makeup Station Frame and lift the Station upward. b. Place the Frame onto the Mounting Bracket Studs by engaging the Studs with the Frame Upper Bracket Slots.
- Page 13 Installation (continued) Install First Makeup Station (continued) 8. Level the Makeup Station as follows. a. Place a 48” Box Level across the two Counter Mounting Brackets. b. To move the left side upward, use a 9/16” open end wrench and turn the Left Lower Flange Nut counterclockwise and the Right Lower Flange Nut clockwise.
-
Page 14: Install Additional Makeup Stations
Installation (continued) Install Additional Makeup Stations Note: Always start a row with a 6-light or 5-light unit on the left end. Add additional 6-light units to the right and finish the row with a 9-light unit or a 8-light unit on the right end. 1. -
Page 15: Attach The Mirror
Installation (continued) Attach the Mirror Slide the Mirror upward 1. Remove the Mirror from the shipping carton and inspect the until the top clips engage the flange on the Frame. Mirror for damage. 2. With two people working together, place the Mirror against the Frame about an inch from the top with Mirror Flange at the bottom. -
Page 16: Connect The Electrical Source
Installation (continued) Connect the Electrical Source WARNING A licensed electrician must perform the electrical installation. The electrical source must be permanently wired and comply with local electrical codes. To reduce the risk of burns, fire, electric shock or injury to persons, observe the following: •...
