Package content

Accessories Quantity
EMK3102 1
SATA 7 pin data cable
1
1
SATA 15 pin to 4 + 4 pin Power Cable 4
4
Screws
1
Key
1
IInsulating pad
1
User manual

Parts

Unock
Lock
Front panel Back panel
1. Key lock (A:Lock B:Unock) 1. SATA power connector (15P)
2. Easy latch door 2. SATA data connector (7P)
3. HDD LED indicator 3. LED access port (4P)

Installation

1.
Remove the cover of an empty drive bay.
2.
Insert EMK3102 into the bay and align the screw holes.
3.
Screw the EMK3102 with 2 screws of each side to securely hold the device.
