CITATION TOWER
OWNER'S
MANUAL

Advertisement

Table of Contents
loading

Related Manuals for Harman Kardon CITATION TOWER

Summary of Contents for Harman Kardon CITATION TOWER

  • Page 1 CITATION TOWER OWNER’S MANUAL...

  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS Do Not Use Extension Cords To avoid safety hazards, use only the power cord supplied with this product. We do not recommend that extension cords be used with this product. As with all electrical devices, do not run power cords under rugs or carpets, or place heavy objects on them.

  • Page 3: Table Of Contents

    IMPORTANT SAFETY INSTRUCTIONS ..........2 INTRODUCTION ..................4 WHAT’S IN THE BOX ................5 PRODUCT OVERVIEW ................6 PLACEMENT ....................8 POWER ON ....................10 SPEAKER SETUP ..................11 USING YOUR CITATION TOWER ............14 SETTINGS....................16 SPECIFICATIONS ..................18 TROUBLESHOOTING ................19 TRADEMARKS ...................21...

  • Page 4: Introduction

    INTRODUCTION This manual includes information on CITATION TOWER (primary and secondary speakers). We encourage you to take a few minutes to read this manual, which describes the products and includes step-by-step instructions to help you set up and get started. Read and understand all the safety instructions before using your product.

  • Page 5: What's In The Box

    WHAT’S IN THE BOX Carefully unpack the box and check if the following parts are included. If any part is damaged, do not use it, contact your Harman Kardon retailer or customer service. 1. Main unit (Secondary speaker) 2. Main unit (Primary speaker) 3.

  • Page 6: Product Overview

    PRODUCT OVERVIEW Top Panel and Front Side Secondary Primary 1. Touch screen (Swipe up / down / left / right to find out more) • Wi-Fi signal indicator. • Press to enter Bluetooth pairing mode. • Press and hold more than 3 seconds to disable Bluetooth.
  • Page 7 mm 24.013 Bottom Side Secondary Primary SERVICE RESET POWER SERVICE 1 RESET SERVICE 2 POWER 1. RESET • Press and hold for 5 seconds to restore the factory settings. 2. SERVICE • For service only. 3. POWER • Connect to the power supply.

  • Page 8: Placement

    PLACEMENT Place your CITATION TOWER on any flat and stable surface near a live AC (mains) outlet. 1) To achieve the best and most accurate stereo soundstage, place the speakers 6-10 feet (1.8-3 meters) apart, keep an angle of 40-60 degrees between your listening position and both speakers. 2) Bass output will increase as the speaker is moved closer to a wall or a corner.
  • Page 9 * To avoid any interference, keep a minimum distance of 16.4 feet (5 meters) between the speakers and your Wi-Fi router. >5m...

  • Page 10: Power On

    POWER ON NOTES: • Use the provided power cord only. • When you disconnect the power cord, always pull the plug, never the cable. 1) Plug one end of the AC power cord into the POWER connector on the bottom of each speaker, then plug the other end to a live AC (mains) outlet.

  • Page 11: Speaker Setup

    Wi-Fi setup. Operate as Satellite Speakers You can operate your CITATION TOWER as a pair of satellite speaker with CITATION BAR (sold separately) to set up a 3.0 channel surround sound system.
  • Page 12 Citation Tower and your Citation Sub. • If CITATION TOWER is powered off, the subwoofer will enter standby mode. • If you use a device near your CITATION TOWER and both use the same frequency (2.4GHz or 5GHz), interference may cause some sound interruption. • The maximum transmission distance of the wireless signal between CITATION TOWER and the subwoofer may vary depending on your operating environment.
  • Page 13 Æ You will hear a pairing chime once successfully connected and “Subwoofer connected” will be displayed on the touch screen. LED Indicator (CITATION SUB) • Pairing White (Flashing) • Out of range / Lost wireless connection White (Constant for 10 • Wirelessly connected with CITATION TOWER seconds and then light off)

  • Page 14: Using Your Citation Tower

    4) Now you can play music and the music can be streamed to the Citation speaker. Play Music through Bluetooth You can use your CITATION TOWER as a speaker for your Bluetooth enabled smartphone or tablet. 1) Press on the remote control or press (Bluetooth) on the touch screen to enter Bluetooth pairing mode.
  • Page 15 NOTES: • To exit the Bluetooth mode, choose other sources. • To disconnect and pair another device, press on the remote control or on the touch screen. • The soundbar automatically turns off after 20 minutes of inactivity. • Bluetooth performance can be affected by the distance between this product and your Bluetooth device and the environment of operation.

  • Page 16: Settings

    SETTINGS Volume You have three ways to adjust the volume level while playing music. • Press - / + button on the top panel to decrease or increase the volume. • Softly drag the volume bar on the touch screen of the primary speaker.
  • Page 17 System Information Press “System info” on the touch screen to view the system information: • Country or region: Country and language. • Network: Network SSID, signal strength and Wi-Fi address. • About: Model and name. • Software version: Software version and date of last update.

  • Page 18: Specifications

    SPECIFICATIONS • Transducer: 1 x 25mm tweeter, 2 x 4” woofer, 1 x 8” subwoofer per speaker • Output power: 2x200W RMS • Signal-to-noise ratio: >80dB • Power Supply: 100-240V – 50/60Hz • Power consumption in sleep mode: <2.0 Watts •...

  • Page 19: Troubleshooting

    TROUBLESHOOTING Sound No sound from the speaker. • Make sure that the speaker is not muted. No sound from CITATION SUB. • Check if the subwoofer LED is in solid white color. Blinking LED means a disconnection. Manually pair them. Bluetooth A device cannot connect with the speaker.
  • Page 20 The HK Citation / Surround app cannot find the device. • Make sure that your CITATION speaker is powered on. • Make sure that your network is working properly. • Make sure that your router or modem is powered on and within the range.

  • Page 21: Trademarks

    TRADEMARKS The Bluetooth® word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc. and any use of such marks by HARMAN International Industries, Incorporated is under license. Other trademarks and trade names are those of their respective owners. T he Wi-Fi CERTIFIED Logo is a certification mark of the Wi-Fi Alliance.
