Doc. No:
Date: 2007.06.26
ASUSTeK
M530w Assembly & Disassembly
Revision:
COMPUTER INC.
SOP
Page:
Grade:
Rev. Modification
Modify description
Issue div.
Originator
V101
English
CSC
M530w Assembly & Disassembly
SOP
Review
Originator
Authorize
by
by
by
Form No : D2-001-11 Rev.01

Advertisement

loading
Need help?

Need help?

Do you have a question about the M530w and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for ASUSTeK COMPUTER M530w

  • Page 1 Doc. No: Date: 2007.06.26 ASUSTeK M530w Assembly & Disassembly Revision: COMPUTER INC. Page: Grade: Rev. Modification Modify description Issue div. Originator V101 English M530w Assembly & Disassembly Review Originator Authorize Form No : D2-001-11 Rev.01...
  • Page 2: Disassembly / Assembly Procedure

    Disassembly / Assembly procedure Introduction This section describes how to disassemble M530W telephone. Many of the integrated devices used in this phone are vulnerable to damage. Ensure adequate static protection is in place when handling, shipping, and servicing any internal components.
  • Page 3 Date: Rev.: Page: Disassembly procedure The following set of diagrams will demonstrate the correct sequence and action to disassemble M530w. Step 1 Place M530w on the workbench and power it off. Step 2 Remove the battery cover and take out the battery and SIM card. To remove the battery cover, press on the battery cover on the bottom of the phone.
  • Page 4 Doc. No: ASUSTeK COMPUTER INC. M530w Assembly & Disassembly Date: Rev.: Page: Step 3 Remove M530w RF Cover ASSY by Plastic blade. Step 4 Remove 4*Screw M1.6*4L T5 by Screw Driver.
  • Page 5 Doc. No: ASUSTeK COMPUTER INC. M530w Assembly & Disassembly Date: Rev.: Page: Remove the Front Case and Bottom Case ASSY by Plastic blade. Step 5 Remove receiver, Vibrator and Antenna Rubber from Bottom Case by Tweezers.
  • Page 6 Doc. No: ASUSTeK COMPUTER INC. M530w Assembly & Disassembly Date: Rev.: Page: Step 6 Remove 2*Screw M1.7*3.3L T5 by Screw Driver from Main Board. Remove 2*Screw M1.6*4L T5 by Screw Driver from WIFI Board and release the WIFI Coaxial Cable.
  • Page 7: Remove The Vga Cmos Camera Module

    Doc. No: ASUSTeK COMPUTER INC. M530w Assembly & Disassembly Date: Rev.: Page: Step 7 Remove the VGA CMOS CAMERA MODULE. Remove the 2.0M AM CAMERA. Step 8 Remove the LCM FPC Hard Mylar and release the connector of LCM by tweezers.
  • Page 8 Doc. No: ASUSTeK COMPUTER INC. M530w Assembly & Disassembly Date: Rev.: Page: Step 10 Remove Keypad FPC ASSY by Tweezers. Step11 Remove M530w EN QWERTY KEY. Step12 Remove LCM module from Case1.
  • Page 9 Rev.: Page: Assembly procedure It is carried out in the exact reverse sequence as the disassembly. Step1 Assemble the LCM module from Case1. Step2 Assemble M530w EN QWERTY KEY and Keypad FPC ASSY. Step 3 Assemble the receiver by tweezers.
  • Page 10 Doc. No: ASUSTeK COMPUTER INC. M530w Assembly & Disassembly Date: Rev.: Page: Step 4 Assemble the 2.0M AM CAMERA and the VGA CMOS CAMERA MODULE. Step 5 Connect the WIFI Coaxial Cable and Assemble WIFI Board with 2*Screw M1.6*4L T5 by Screw Driver.
  • Page 11 Doc. No: ASUSTeK COMPUTER INC. M530w Assembly & Disassembly Date: Rev.: Page: Step 6 Put on WIFI Board with 2*Screw M1.7*3.3L T5 by Screw Driver in the Main Board. Step 7 Put on receiver, Vibrator and Antenna Rubber from Bottom Case by Tweezers.
  • Page 12 Doc. No: ASUSTeK COMPUTER INC. M530w Assembly & Disassembly Date: Rev.: Page: Step 9 Assemble the M530w RF Cover ASSY. Step 10 Put the battery and Battery cover in the bottom of the phone.
