ASUSTeK COMPUTER Galaxy mini 5 Assembly & Disassembly Instructions

Hide thumbs

Advertisement

Quick Links

Download this manual
Doc. No:
Date: 2008.9.23
ASUSTeK
Galaxy mini 5 Assembly &
Revision:
COMPUTER INC.
Disassembly SOP
Page:
Grade:
Rev. Modification
Modify description
Issue div.
Originator
V101
English
CSC
Galaxy mini 5 Assembly & Disassembly
SOP
Review
Originator
Authorize
by
by
by
Form No : D2-001-11 Rev.01

Advertisement

loading
Need help?

Need help?

Do you have a question about the Galaxy mini 5 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ASUSTeK COMPUTER Galaxy mini 5

Summary of Contents for ASUSTeK COMPUTER Galaxy mini 5

  • Page 1 Doc. No: Date: 2008.9.23 ASUSTeK Galaxy mini 5 Assembly & Revision: COMPUTER INC. Disassembly SOP Page: Grade: Rev. Modification Modify description Issue div. Originator V101 English Galaxy mini 5 Assembly & Disassembly Review Originator Authorize Form No : D2-001-11 Rev.01...

  • Page 2: Disassembly / Assembly Procedure

    Doc. No: ASUSTeK COMPUTER INC. Galaxy mini 5 Assembly & Date: Disassembly SOP Rev.: Page: Disassembly / Assembly Procedure Introduction This section describes how to disassemble PDA GM2. Many of the integrated devices used in this phone are vulnerable to damage. Ensure adequate static protection is in place when handling, shipping, and servicing any internal components.

  • Page 3: Disassembly Procedure

    Doc. No: ASUSTeK COMPUTER INC. Galaxy mini 5 Assembly & Date: Disassembly SOP Rev.: Page: Disassembly procedure The following set of diagrams will demonstrate the correct sequence and action to disassemble P565. Step 1 Take the stylus away from the PDA PHONE.
  • Page 4 Doc. No: ASUSTeK COMPUTER INC. Galaxy mini 5 Assembly & Date: Disassembly SOP Rev.: Page: Step 4 Remove the antenna rubber. And remove 4 screws on the middle case assy. Then remove the middle case assy from the I/O side.
  • Page 5 Doc. No: ASUSTeK COMPUTER INC. Galaxy mini 5 Assembly & Date: Disassembly SOP Rev.: Page: Step 5 Pry the speaker box by a plastic blade and then remove the speaker box. Pay attention to the speaker net and the GSM/GPS antenna on the middle case assy. Do not tear them up when removing the speaker box.
  • Page 6 Doc. No: ASUSTeK COMPUTER INC. Galaxy mini 5 Assembly & Date: Disassembly SOP Rev.: Page: Step 6 Carefully tear off the GSM/GPS antenna on the middle case assy. Step 7 Disconnect the LCD panel FPC and keypad FPC from the main board.
  • Page 7 Doc. No: ASUSTeK COMPUTER INC. Galaxy mini 5 Assembly & Date: Disassembly SOP Rev.: Page: Step 9 Remove 2 screws on the SIM board and then remove the SIM board. Step 10 Separate the CMOS camera module from the SIM board. Then disassemble the camera rubbers.
  • Page 8 Doc. No: ASUSTeK COMPUTER INC. Galaxy mini 5 Assembly & Date: Disassembly SOP Rev.: Page: Step11 Remove the speaker box rubber. Open the VGA camera connector and remove the VGA camera. Then remove the MIC rubber.
  • Page 9 Doc. No: ASUSTeK COMPUTER INC. Galaxy mini 5 Assembly & Date: Disassembly SOP Rev.: Page: Step12 Open the touch lens FPC connector and remove the keypad FPC. Then remove the keypad. Touch Lens FPC Step13 Release the LCD panel from the hooks and then remove the panel from the top case assy. Remove the receiver from the top case assy.
  • Page 10 Doc. No: ASUSTeK COMPUTER INC. Galaxy mini 5 Assembly & Date: Disassembly SOP Rev.: Page:...

  • Page 11: Assembly Procedure

    Doc. No: ASUSTeK COMPUTER INC. Galaxy mini 5 Assembly & Date: Disassembly SOP Rev.: Page: Assembly Procedure It is carried out in the exact reverse sequence as the disassembly. Step 1 Install the receiver on the front cover by a pair of tweezers. Then install the LCD panel.
  • Page 12 Doc. No: ASUSTeK COMPUTER INC. Galaxy mini 5 Assembly & Date: Disassembly SOP Rev.: Page: Touch Lens FPC Step 3 Install the MIC rubber. Assemble the VGA camera and close its connector on the main board. Install the speaker box rubber.
  • Page 13 Doc. No: ASUSTeK COMPUTER INC. Galaxy mini 5 Assembly & Date: Disassembly SOP Rev.: Page: Step 4 Assemble the camera rubbers with the CMOS camera. Then install the CMOS camera on the SIM board. Step 5 Install the SIM board with the main board. Then secure 2 screws on the SIM board.
  • Page 14 Doc. No: ASUSTeK COMPUTER INC. Galaxy mini 5 Assembly & Date: Disassembly SOP Rev.: Page: Step 6 Install the main board and arrange it in the hooks of the top case assy. Hooks Step 7 Connect the LCD FPC and close its connector. Then connect the keypad FPC.
  • Page 15 Doc. No: ASUSTeK COMPUTER INC. Galaxy mini 5 Assembly & Date: Disassembly SOP Rev.: Page: Step 8 Carefully paste the GSM/GPS antenna on the middle case assy and arrange it well. Step 9 Install the speaker box in the middle case assy.
  • Page 16 Doc. No: ASUSTeK COMPUTER INC. Galaxy mini 5 Assembly & Date: Disassembly SOP Rev.: Page: Step 11 Secure 4 screws on the middle case assy and then install the antenna rubber.
