• Support CD • Quick Start Guide System requirements To ensure a successful installation of the Xonar DSX card, your computer must meet the following requirements: • One PCIE 1.0 (or higher) compatible slot for the audio card • Microsoft...
Page 4
Usually connects to the Analog Audio output of TV tuner card or other sound source inside your PC system. (To monitor your TV tuner card’s audio from this Aux-In, you must enable the “monitor” function for Aux-In in the Xonar DSX Audio Center‘s recording mixer.) S/PDIF Out header Connects to the graphics card with HDMI support.
Touch the metal back or side panel of the computer to avoid static electricity. Remove the chassis cover. Remove the metal bracket from an available PCIE slot for the Xonar DSX audio card. Carefully insert the audio card into the PCIE slot. Ensure the audio card sits properly in place.
Page 15
패키지 구성 ASUS Xonar DSX 오디오 카드 패키지가 아래의 구성물을 모두 포함하고 있는지 확 인해 주십시오: • ASUS Xonar DSX PCIE 오디오 카드 • S/PDIF TOSLINK 옵티컬 어댑터 x1 • 로우 프로파일 브래킷 x1 • 지원 CD • 빠른 시작 안내 설명서...
Page 16
S/PDIF 출력 헤더 HDMI 지원이 가능한 그래픽 카드와 연결해 주십시오. 마더보드의 PCI Express 슬롯에 삽입합니다. PCI Express 버스 골 든 핑거 한 한 국 국 어 어 ASUS Xonar DSX 빠른 시작 안내 설명서 A01_Xonar DSX_QSG.indb 1 13.01.2012 :52:44 Uhr...
Page 17
면 금속 부분 또는 측면 부분만을 만져 주 십시오. 케이스 커버를 분리해 주십시오. Xonar DSX 오디오 카드를 설치하기 위해 빈 PCIE Express 슬롯에서 금속 브 래킷을 제거해 주십시오. 오디오 카드를 PCIE Express 슬롯에 조심스럽게 넣은 후에 오디오 카드가 올 바르게 설치되었는지 확인해 주십시오.
Isi kemasan Periksa kemasan kartu audio ASUS Xonar DSX untuk item berikut: • Kartu audio PCIE ASUS Xonar DSX • Adapter optik x1 S/PDIF TOSLINK • 1 Braket Profil Dasar • CD dukungan • Panduan Ringkas Persyaratan sistem Untuk memastikan keberhasilan pemasangan kartu audio Xonar DSX, komputer Anda harus memenuhi persyaratan sebagai berikut: •...
Page 19
PC Anda. (Untuk memantau audio kartu TV tuner Anda dari Aux-In, Anda harus mengaktifkan fungsi “pemantauan” untuk Aux-In di pencampur rekaman Xonar DSX Audio Center.) S/PDIF Out header Untuk menghubungkan ke kartu grafis dengan dukungan HDMI.
Page 20
Lepaskan penutup chassis. Lepaskan braket logam dari slot PCIE yang tersedia untuk kartu audio Xonar DSX. Masukkan kartu audio ke slot PCIE dengan hati-hati. Kencangkan kartu audio dengan sekrup dan braket logam. Pasang kabel daya catu daya ke soket daya pada kartu audio.
Page 21
ASUS Xonar DSX ASUS Xonar DSX Xonar DSX ASUS Xonar DSX A01_Xonar DSX_QSG.indb 21 13.01.2012 :52:53 Uhr...
