- Page 1 Wireless LAN Device Series WLAN Outdoor Bridge ZPlus-B191-OD User’s Manual Version. 1.02 (06.01.2004)
- Page 2 Notice “This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions： (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Warning：...
- Page 3 This EUT is incompliance with SAR for general population /uncontrolled exposure limits in ANSI/IEEE C95.1-1999 and had been tested in accordance with the measurement methods and procedures specified in OET Bulletin 65 Supplement C This device and its antenna(s) must not be co-located or operating in conjunction with any other antenna or transmitter CAUTION：...
-
Page 4: Table Of Contents
Contents INTRODUCTION..............................6 HARDWARE INSTALLATION ..........................7 ..............................7 ACKING ..........................8 ARDWARE NSTALLATION SOFTWARE CONFIGURATION........................12 ......................... 12 NTER WEB CONFIGURATION PAGE WLAN A ........................12 CCESS OINT TATUS LAN S ..........................14 IRELESS ETTING 3.3.1 Basic settings ............................14 3.3.2 Wireless Advanced Settings........................ - Page 5 5.3.5 WDS (Wireless Distribution System)......................39 5.3.6 Wireless Bridge ............................40 ........................41 ELECTING AN APPROPRIATE SITE ..........................41 OWER OVER THERNET...
-
Page 6: Introduction
Our Outdoor Bridge is a flexible and cost-effective product which allows you to connect LANs located in far distant buildings with data rate up to 11Mbps, ZPlus-B191-OD is an idea device to replace the expensive lease lines, such as T1 line or fiber optics. -
Page 7: Hardware Installation
2 Hardware Installation This Chapter helps you to quickly and easily install the hardware. 2.1 Packing List Before you start install the Wireless Outdoor Bridge, you should check the following packages you must have： Wireless Outdoor Bridge * 1 Mounting Kits * 1 Waterproof RJ-45 Cable (30M) * 1 Waterproof RF Cable (1M) * 1 Power Over Ethernet Kits * 1... -
Page 8: Hardware Installation
2. You can use the 2” inch or 4” inch U bolts to mount on the pipe. The two U bolts must tightly mount and take care not to over-tighten 3. After check the ZPlus-B191-OD is mount well, you can connect two cables, Waterproof RJ-45 network cable and RF cable, and the grounding wire. - Page 9 ZPlus-B191-OD grounding wire connection Note: DON’T plug the power cord into PoE device to power on the system before you finish install the antenna and grounding wire to ensure the safety. You can follow the figure to mount the ZPlus-B191-OD quickly.
- Page 10 You can also mount the ZPlus-B191-OD on the wall to fit in your environment. In the ZPlus-B191-OD indoor part installation, if the RJ-45 cable’s length is not enough for you to link to your network device, you can extend the cable length, but you need to careful the maximum length of the RJ-45 cable is 100M.
- Page 11 The simple composed figure shows in below for your reference. Antenna ZPlus-B191-OD Waterproof RF cable Waterproof RJ-45 cable Grounding wire RJ-45 cable Power injector Power supply Power cord HUB / SWITCH...
-
Page 12: Software Configuration
3 Software Configuration 3.1 Enter web configuration page The default IP Address of ZPlus-B191-OD is 192.168.2.254 and Subnet Mask is 255.255.255.0. You need to configure your PC’s TCP/IP setting on the same segment to access the AP. For example： • IP address 192.168.2.X (X must between 1 and 253 that is not used by another device) •... -
Page 14: Wireless Lan Setting
2. You can disable the wireless LAN interface by choosing this function. 3. ZPlus-B191-OD can support AP and Client modes; you can use the “AP” mode for normal function and “Client” mode to connect to another AP, like a standard wireless client. - Page 15 7. In the “Associated Client”, you also can click the “Show Active Client” to see which client had connected to this AP. When you using the Client mode of the AP, you must connect by wired RJ-45 cable and can’t use the AP mode’s functions.
- Page 16 Each time you change the default setting successful, the page will show the successful message.
-
Page 17: Wireless Advanced Settings
3.3.2 Wireless Advanced Settings In this wireless advanced settings page, you must configure it very carefully, because the default setting is almost optimized for the entire wireless LAN environment. Note ： Any unreasonable value change will reduce the throughput of the AP. 1. - Page 18 3. RTS Threshold： This function is to prevent the low throughput from the hidden node of WLAN device. The default setting is disable(set the value to the maximum) 4. Beacon Interval： The interval time to send the beacon. The default value is 100ms. 5.
-
Page 19: Wireless Security Setup
3.3.3 Wireless Security setup The default security setting is disable the encryption function, you can choice which the security you want. 3.3.3.1 WEP Encryption Setting When you use the WEP encryption, you can choice just set the WEP key or use the 802.1x Authentication. - Page 20 When you decide to use the WEP encryption to secure your WLAN, the following explain the setting of the WEP encryption： 64-bit WEP Encryption： 64-bit WEP key are the same with the encryption method of 40-bit WEP, you can input 10 hexadecimal digits {0~9},{a~f},{A~F} 128-bit WEP Encryption ：...
-
Page 22: Wep Encryption With 802.1X Setting
3.3.3.2 WEP Encryption with 802.1x Setting When you use the WEP encryption, you can also use the RADIUS server to check the admission of the users. Then you can choice WEP 64 or 128 bit encryption to fit in with your network environment, the default Port is 1812, and in IP address field you need to specify the RADIUS server’s IP and the Password’s length is depend on your choice of WEP key’s bits. -
Page 23: Wpa Encryption Setting
3.3.3.3 WPA Encryption Setting When you choice the WPA encryption, you can use the WPA-RADIUS or Pre-shared Key to enhance your security setting. You also can enable or disable the TKIP. And the Pre-shared Key format has two choices, one is passphrase and other is Hex (64 characters). When you choice the WPA encryption, you can use the WPA-RADIUS or Pre-shared Key to The default Port for enhance your security setting. -
Page 24: Wireless Access Control
3.3.4 Wireless Access Control In this page you can have a simple firewall to prevent the unauthenticated customer to connect to our AP. 1. If you add the filtering MAC address to allow the connection, you must carefully do with the “Wireless Access Control”, when you enable the access control, you need to add the MAC address that be allowed to connect to the AP. -
Page 26: Wireless Site Survey
3.3.5 Wireless Site Survey When you enable the Client mode, you can use this page to discover the AP and connect to it by this function. -
Page 27: Wds Settings
WDS devices to connect, you can enable the “Access control” function and don’t add any MAC address to the list. Then the system will automatic only allow the WDS device to connect. 4. The following figure is the example for your reference. ZPlus-B191-OD: ZPlus-B191-OD: SSID: C1 SSID: C2... -
Page 28: Lan Interface Setup
And you also can do the Clone MAC address to simulate other network device’s MAC address. 3.4.1 Using the Fixed IP When you use the fixed IP for ZPlus-B191-OD, you must fill up the IP address and Subnet Mask and Default Gateway (if you need to have.) -
Page 29: Using Dhcp Client
You also can use the DHCP client mode to get the IP and other setting, but you must carefully to use this function. You need to know what IP that ZPlus-B191-OD will get or you can’t connect to the ZPlus-B191-OD’s web page. -
Page 30: Enable Dhcp Server
1. DHCP Client range: 192.168.2.X (X:1~253) 2. DNS Server: to identify what DNS is usefully to you. When you finish the default setting, if you change the ZPlus-B191-OD’s IP, you have to re-connect the Web Server with the new address. -
Page 31: Wlan Ap Statistics
When you enable the DHCP server, you can see which client had been assigned the IP address. 3.5 WLAN AP Statistics This page shows the wireless statistics, the packet counters for transmission and reception regarding to wireless and Ethernet networks. -
Page 32: Upgrade Firmware
Please use the wired connection to upgrade the firmware! 3.7 Save/Reload Settings You can save the setting for backup or other the same device, and you can reload the file that saving your configuration. There is a soft reset bottom to reset the ZPlus-B191-OD to factory default. -
Page 33: Password Setup
3.8 Password Setup To protect your configuration and system, you can set an administrator to authorize login. When you set an administrator to control the web page, each time people want to login the system web page, they need to be verified. -
Page 34: Technical Specification
4 Technical Specification General Data Transfer Rate 11, 5.5, 2 and 1 Mbps, Auto Fall-Back Humidity (non-condensing) 5%～95% typical Temperature Range -20°C to 50°C - Operating -20°C to 65°C - Storage Regulation Certifications FCC Part 15, ETSI 300/328/CE Frequency Band 2.400～2.497 GHz Radio Type Direct Sequence Spread Spectrum (DSSS) - Page 35 WEB UI management DNS relay Electrical Antenna Connector N-N Type Length ： 1M Ethernet Interface Waterproof Shielded Cat5 10 Base-T (RJ-45) Length ： 30M (Max. 100M) Power Supply Active Ethernet (Power over Ethernet) –48 V DC/0.7A...
-
Page 36: Wireless Connection Architecture
5 Wireless Connection Architecture IEEE 802.11 defines two types of network service： Infrastructure and ad-Hoc mode. You can select either one to fit your network environment. 5.1 Infrastructure mode ALL PCs, with wireless LAN card, connect to the AP that has been linking to the LAN and all the resource can be integrated or shared. -
Page 37: Wireless Ap Functions
5.3 Wireless AP Functions Access Point can have different functions to make your network more effectively. 5.3.1 Access Point Mode In the Access Point function, you can connect the AP to the LAN with RJ-45 cable and PC can use the wireless LAN adapter to connect to this AP to share the resource and join to the network environment. -
Page 38: Access Point Client Mode (Ad-Hoc)
5.3.2 Access Point Client Mode (ad-Hoc) Using the Access Point Client function, you can have both the AP function and Client function. You can use the wire line connect to the LAN and use the wireless client “ad-Hoc” function to join to each other. 5.3.3 Access Point Client Mode (Infrastructure) Using the Access Point Client function in Infrastructure mode, you can connect to the LAN with wire line and can setup a Basic service set to let other client including the PC client and... -
Page 39: Wireless Repeater
5.3.4 Wireless Repeater Wireless Repeater can extend the range of the wireless radio, and you can add the long range of the wireless group. 5.3.5 WDS (Wireless Distribution System) You can use the WDS function to connect to both of the AP and wireless LAN client. -
Page 40: Wireless Bridge
5.3.6 Wireless Bridge You can use this function to connect two or more location (Point-to-Point, Point to multi-Point). -
Page 41: Selecting An Appropriate Site
5.4 Selecting an appropriate site Selecting an appropriate site for your Wireless Outdoor Bridge will ensure the best performance. Avoid locating the Wireless Outdoor Bridge near metal objects such as appliances like refrigerators, ovens, and washer/dryers. Keep in mind that your appliances may be on the other side of the wall in the area that you may be considering to locate the Wireless Outdoor Bridge.
