Zinwell ZWA-G192-OD User Manual

Wlan outdoor bridge, wireless lan device series
Hide thumbs

Advertisement

Quick Links

Download this manual
Wireless LAN Device Series
WLAN Outdoor Bridge
ZPlus-G192-OD User Manual
Version. 1.2.1 (25.03.2005)

Advertisement

loading
Need help?

Need help?

Do you have a question about the ZWA-G192-OD and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Zinwell ZWA-G192-OD

Summary of Contents for Zinwell ZWA-G192-OD

  • Page 1 Wireless LAN Device Series WLAN Outdoor Bridge ZPlus-G192-OD User Manual Version. 1.2.1 (25.03.2005)

  • Page 2: Table Of Contents

    Preface..........................2 Chapter 1 - ZWA-G192 Installation................4 Packing List ......................4 Hardware Installation.....................5 Chapter 2 - First Time Configuration ................8 Before Start to Configure..................8 Knowing the Network Application ................8 Basic Settings.......................14 Advanced Settings ....................34 Configuring Wireless Security................37 Configuring as WLAN Client Adapter ..............40 Quick start to configure ..................40 Chapter 3 - Configuring WDS ..................43 WDS network topology ..................43...
  • Page 3 ZWA-G192 outdoor product, hereafter referred to as the “device”. To use this guide, you should have experience working with the TCP/IP configuration and be familiar with the concepts and terminology of wireless local area networks.

  • Page 4: Chapter 1 - Zwa-G192 Installation

    Chapter 1 - ZWA-G192 Installation Packing List Before you start to install the ODU, make sure the package contains the following items： Wireless Outdoor Bridge unit * 1 Mounting Kit * 1 Waterproof (IP67) RJ-45 Cable (30M) * 1 Waterproof (IP66) RF Cable (1M) * 1 Power Over Ethernet Kit * 1 Ground Wire * 1 2.5”...

  • Page 5: Hardware Installation

    RJ-45 Cable 6 dBi omni directional antenna 2.5” /4” U bolt and Anchor Hardware Installation Once you check off everything from the package, you can start to install the ODU. You can mount to a pipe, a pole or to the side of a building. The steps are showed in the following：...
  • Page 6 Wall Mounting Figure After checking the ODU is mounted well, you can connect the following two cables: the Waterproof RJ-45 network cable to “P+ DATA OUT” port of ODU and the RF cable to antenna port. Additional waterproof tool, such as waterproof tape, is recommended to use to enhance the waterproof function.
  • Page 7 Caution: DON’T plug the power cord into PoE device before you finish install the antenna and Ground wire to ensure the safety. If the RJ-45 cable’s length is not long enough to connect to your network device for indoor parts installation, you can extend the cable length. However, make sure the maximum length of the RJ-45 cable is shorter than 100M (about 109 yards) for normal operation under IEEE 802.3 standards.

  • Page 8: Chapter 2 - First Time Configuration

    IP address of device is changed and forgot by user. The tool only can discover the device in your local area network. Knowing the Network Application ZWA-G192-OD can act as the following roles, and it supports WDS (Wireless Distribution System) function. Access Point...

  • Page 9: Static Ip

    The device provides 3 different operation modes and the wireless radio of device can act as AP/Client/WDS. The operation mode is about the communication mechanism between the wired Ethernet NIC and wireless NIC, the following is the types of operation mode. Router The wired Ethernet (WAN) port is used to connect with ADSL/Cable modem and the wireless NIC is used for your private WLAN.
  • Page 10 WDS (Wireless Distribution System) This mode serves as a wireless repeater, the device forwards the packets to another AP with WDS function. When this mode is selected, all the wireless clients can’t survey and connect to the device. The device only allows the WDS connection. WDS+AP This mode combines WDS plus AP modes, it not only allows WDS connections but also the wireless clients can survey and connect to the device.

  • Page 11: Pppoe

    Examples of Configuration DEV 1 WDS+AP - Router LAN 192.168.2.254/24 WAN PPPoE connection Wireless Channel / SSID 11 / ZPlus-G192-DEV1 MAC Address of WLAN(BSSID) 000000042728 Internet DHCP Server enabled (IP pool 192.168.2.1~253) ADSL DEV 4 LAN 192.168.3.1/24 WAN Dynamic IP address 192.168.2.x 192.168.2.x DHCP Server enabled (IP pool 192.168.3.2~254)
  • Page 12 Configure DEV1: 1. Connect the ADSL modem to Ethernet port of device using Ethernet cable. 2. Access the web server (http://192.168.2.254) of device from the wireless station. 3. Use Wizard page to setup device. 4. Press “Next>>” button then set the “Operation Mode” to “Router” mode. 5.
  • Page 13 7. Press “Next>>” button then select the “PPPoE” for “WAN Access Type” and fill in the “User Name” and “Password” fields. 8. Press “Next>>” button then select the “AP+WDS” for “mode” and change the SSID to “ZPlus-G192-DEV1”. 9. Press “Next>>” button then select “None” for “Encryption” then press “Finished” button.
  • Page 14 10. Wait for refreshing web page. 11. Use “WDS Settings” page to configure WDS. 12. Enable WDS function and add the BSSID of DEV2 to “Current WDS AP List”.
  • Page 15 13. Since we access the device by wireless connection, it may temporarily disconnect when applying the WDS setting. After re-connecting to the device, use the “Status “ page to check the settings.
  • Page 16 Configure DEV2: 1. Access the web server (http://192.168.2.254) of device from the Ethernet port. Caution If you configure multiple devices in the same PC, since the devices have the same default IP address but different MAC addresses, it may cause you can’t access the web server of device.
  • Page 17 5. Press “Next>>” button then set the IP address of LAN interface. 6. Press “Next>>” button then select the “AP+WDS” for “mode” and change the SSID to “ZPlus-G192-DEV2”. 7. Press “Next>>” button then select “None” for “Encryption” then press “Finished” button.
  • Page 18 8. Wait for refreshing web page. 9. Access the web server by new IP address “192.168.2.202” then use “LAN Interface” page to disable DHCP Server. 10. Wait for refreshing web page. 11. Use “WDS Settings” page to configure WDS.
  • Page 19 12. Enable WDS function and add the BSSID of DEV1 to “Current WDS AP List”. 13. Use the “Status “ page to check the settings.
  • Page 21 Configure DEV3: 1. Access the web server (http://192.168.2.254) of device from the Ethernet port. Caution If you configure multiple devices in the same PC, since the devices have the same default IP address but different MAC addresses, it may cause you can’t access the web server of device.
  • Page 22 5. Use the “Status “ page to check the settings.
  • Page 23 Configure DEV4: 1. Access the web server (http://192.168.2.254) of device from the Ethernet port. Caution If you configure multiple devices in the same PC, since the devices have the same default IP address but different MAC addresses, it may cause you can’t access the web server of device.
  • Page 24 5. Press “Next>>” button then set the IP address of LAN interface. 6. Press “Next>>” button then select the “DHCP Client” for “WAN Access Type”. 7. Press “Next>>” button then select the “Client” for “mode” and change the SSID to “ZPlus-G192-DEV1”.
  • Page 25 9. Wait for refreshing web page. 10. Change the IP address of your PC to 192.168.3.x then access the web server by the new IP address “192.168.3.1” and use “Status” page check the setting. 11. If the “State” of “Wireless Configuration” is not “Connected” or you want to refresh the “RSSI “, please use “Site Survey”...
  • Page 27 Configure DEV5: 1. Access the web server (http://192.168.2.254) of device from the Ethernet port. Caution If you configure multiple devices in the same PC, since the devices have the same default IP address but different MAC addresses, it may cause you can’t access the web server of device.
  • Page 28 5. Press “Next>>” button then set the IP address of LAN interface. 6. Press “Next>>” button then select the “Client” for “mode” and change the SSID to “ZPlus-G192-DEV2”. 7. Press “Next>>” button then select “None” for “Encryption” then press “Finished” button.
  • Page 29 8. Wait for refreshing web page. 9. Access the web server by the new IP address “192.168.2.205” and use “LAN Interface” page to disable DHCP Server. 10. Wait for refreshing webpage. 11. Use “State” page to check setting.
  • Page 30 12. If the “State” of “Wireless Configuration” is not “Connected” or you want to refresh the “RSSI “, please use “Site Survey” page to re-connect a AP.

  • Page 31: Basic Settings

    Basic Settings Disable Wireless LAN Interface Disable the wireless interface of device Band: The device supports 2.4GHz(B), 2.4GHz(G) and 2.4GHz(B+G) mixed modes. Mode: The radio of device supports different modes as following: 1. AP The radio of device acts as an Access Point to serves all wireless clients to join a wireless local network.
