- Page 1 User’s Manual SENAO WIRELESS SOLUTIONS PROVIDER SI-7800H WiFi Phone Version 1.1 May 18, 2004...
-
Page 2: Table Of Contents
1.2 Removing and Installing the Battery ......7 1.3 Charging the SI-7800H ..........8 1.3.1 Charging the SI-7800H by using the Travel Charger..8 1.3.2 Charging the SI-7800H by using the Desktop Charger 8 1.4 Powering the SI-7800H On and Off ......9 1.5 Main Screen ............... 9 1.6 Entering and Editing text .......... - Page 3 SENAO SI-7800H User’s Manual 6.2 SIP User Name ............21 6.3 Realm name............. 21 6.4 Authentication Name..........21 6.5 Password ..............21 6.6 Registrar..............21 6.7 Registrar Status ............21 6.8 Registration Time (sec) ..........21 6.9 Proxy ................ 22 6.10 Proxy Status............
- Page 4 SENAO SI-7800H User’s Manual 9.2.1 Time Zone Setting............29 9.2.2 SNTP Status..............29 9.2.3 Polling Time..............29 9.2.4 SNTP Server 1 to 4 .............29 Chapter 10 Information ........... 30 10.1 SIP Information ............30 10.2 Network Information ..........31 10.3 System Information ..........31 Chapter 11 Profile ............
-
Page 5: Chapter 1 Overview Of The Si-7800H
Senao WiFi phones (SI-7800H) are compliant to IEEE 802.11b standard and IETF Session Initiation Protocol (SIP). As long as users are in the coverage of APs (Access Point), they can use SI-7800H to make VoIP phone calls over WLAN. The SI-7800Hs enhance productivity and bring mobility to people at home, in hot spots, offices, hospitals, warehouses, retail stores, universities, hotels, resorts and other environments. - Page 6 SENAO SI-7800H User’s Manual LED Indicator: ON – When the SI-7800H is in wake up mode, WLAN packets can be transmitted or received by the SI-7800H. OFF – When the SI-7800H is in sleep mode, no WLAN packets can be transmitted or received by the SI-7800H.
-
Page 7: Removing And Installing The Battery
SENAO SI-7800H User’s Manual 1.2 Removing and Installing the Battery To remove the battery: Turn the handset face down and locate the battery release button at the middle of the handset. Push the release button and lift the battery up to remove it. -
Page 8: Charging The Si-7800H
SENAO SI-7800H User’s Manual 1.3 Charging the SI-7800H Before the first time use of the SI-7800H, please charge it for at least six hours. The battery icon on the LCD display will show the charging status. Please refer to figure 1.3.1. -
Page 9: Powering The Si-7800H On And Off
SENAO SI-7800H User’s Manual (2) Plug the power adapter to a wall outlet. (3) Put the SI-7800H on the desktop charger to start charging. Please refer to Figure 1.3.2.1. Figure 1.3.2.1 SI-7800H on the desktop charger 1.4 Powering the SI-7800H On and Off Press and hold the Power On/Off key for approximately 2.5 seconds to... -
Page 10: Entering And Editing Text
7 Registration status indicator: when SIP registration is enabled, the capital R indicates SI-7800H has registered to the SIP Registrar successfully. If SI-7800H fails to register to the SIP Registrar, a capital U will appear. A cross sign (X) means the user name or password is incorrect. -
Page 11: Redial A Number
SENAO SI-7800H User’s Manual 1.7.4 Redial a number At the standby mode, press ▼. The list of placed calls is displayed. The latest dialed number is highlighted, so you can redial this number directly by pressing the left soft key. -
Page 12: Chapter 2 Menu Architecture
SENAO SI-7800H User’s Manual Chapter 2 Menu Architecture In the standby mode, you can press the right soft key to select the Phonebook menu or press the left soft key to select the main Menu. 08:55 user WLAN Ready Main Menu... - Page 13 SENAO SI-7800H User’s Manual 1. Call History 2. Phone Settings 3. SIP Settings Select Back Figure 2.0.3 Main Menu SENAO INTERNATIONAL CO., LTD.
-
Page 14: Chapter 3 Phonebook
SENAO SI-7800H User’s Manual Chapter 3 Phonebook This chapter provides information about accessing the Phonebook menu and using its features. Figure 3.0.1 shows the architecture of the Phonebook menu. Phonebook Browse View Edit Delete User Name Create SIP URL Apply Review Figure 3.0.1 Phonebook menu architecture... -
Page 15: Create A New Record
SENAO SI-7800H User’s Manual to select it. 2. Press ▲ or ▼ to scroll to the name you want to browse. Then press to select it. 3. Now you can view, edit or delete this record. 4. When viewing one record, you can recall the phone number/SIP URL of that record by pressing the left soft key and then make a call. -
Page 16: Chapter 4 Call History
SENAO SI-7800H User’s Manual Chapter 4 Call History This chapter provides information about accessing the Call History menu and using its features. Figure 4.0.1 shows the architecture of the Call History menu. Call History Outgoing Incoming Missed Calls Erase Record Figure 4.0.1 Call History menu architecture... -
Page 17: Incoming Calls
SENAO SI-7800H User’s Manual You can press ▲ or ▼ to scroll through the last 10 phone numbers dialed, and press to make a call of that number. 4.2 Incoming Calls In the Call History menu, select Incoming Calls. The Incoming Calls menu is displayed, as shown in Figure 4.2.1. -
Page 18: Chapter 5 Phone Settings
SENAO SI-7800H User’s Manual Chapter 5 Phone Settings This chapter provides information about accessing the Phone Settings menu and using its features. Figure 5.0.1 shows the architecture of the Phone Settings menu. Phone Settings Ringer Melody Off/on Melody Select Melody 1 to 11... -
Page 19: Ringer Melody
SENAO SI-7800H User’s Manual 5.1 Ringer Melody The ringer can be turned on or off for incoming calls. 5.2 Melody Select You can select ringer melody from Melody 1 to Melody 11. Then you can play the melody and set it active. -
Page 20: Chapter 6 Sip Settings
SENAO SI-7800H User’s Manual Chapter 6 SIP Settings This chapter provides information about accessing the SIP Settings menu and using its features. Figure 6.0.1 shows the architecture of the SIP Settings menu. SIP Settings Display Name SIP User Name Realmname Auth. -
Page 21: Display Name
Enter the Registrar’s IP address and port number here. For example, 160.23.12.5:5060 6.7 Registrar Status You can enable or disable the SI-7800H to register to a registrar. 6.8 Registration Time (sec) Enter the registration time here. The SI-7800H will re-start registering to a registrar at the period of the registration time. -
Page 22: Proxy
Enter the SIP proxy server’s IP address and port number here. For example, 160.23.12.5:5060 6.10 Proxy Status You can enable or disable the SI-7800H to use the SIP proxy server. 6.11 Outbound Proxy The outbound proxy is used to do NAT/Firewall traversal for users sitting behind NAT/Firewall equipments. -
Page 23: Chapter 7 Ip Settings
SENAO SI-7800H User’s Manual Chapter 7 IP Settings This chapter provides information about accessing the IP Settings menu and using its features. Figure 7.0.1 shows the architecture of the IP Settings menu. Disable/Enable IP Settings DHCP System Name Static IP Address... -
Page 24: Dhcp
Note 1: After any modification of settings in this IP settings menu, you need to reboot the WiFi Phone to make the new settings effective. Note 2: Please don’t use the following subnets on the SI-7800H- 192.168.1.x and 192.168.99.x. 7.1 DHCP You can get the dynamic IP address, default gateway and DNS server IP address from a DHCP server if you enable the DHCP function. -
Page 25: Chapter 8 Wlan Settings
SENAO SI-7800H User’s Manual Chapter 8 WLAN Settings This chapter provides information about accessing the WLAN Settings menu and using its features. Figure 8.0.1 shows the architecture of the WLAN Settings menu. WLAN Settings SSID Channel Tx Rate 1/2/5.5/11Mbps/Auto Mode... -
Page 26: Ssid
8.4 Mode Only infrastructure mode is available. 8.5 Site Survey This SI-7800H can do WLAN site survey. You can browse the AP list of all APs found by SI-7800H and choose to join an AP in the list. 8.6 Roaming Setup You can disable or enable the roaming function. -
Page 27: Authentication Type
SENAO SI-7800H User’s Manual 8.7.1 Authentication Type You can choose open system or shared key as the authentication type. 8.7.2 Encryption You can disable it or you can enable it with 64 or 128 bit key. 8.7.3 Used Key You can choose any key from key 1 to key 4 for WEP encryption. -
Page 28: Chapter 9 System Time
SENAO SI-7800H User’s Manual Chapter 9 System Time This chapter provides information about accessing the System Time menu and using its features. Figure 9.0.1 shows the architecture of the System Time menu. System Time Time Setting Clock Settings Date Settings... -
Page 29: Sntp Setting
You can disable or enable the function of synchronizing SI-7800H’s time to SNTP servers. 9.2.3 Polling Time You can set the polling time of the SI-7800H for how often to get time information from SNTP servers. 9.2.4 SNTP Server 1 to 4 You can set the IP addresses of SNTP server 1 to server 4 here. -
Page 30: Chapter 10 Information
SENAO SI-7800H User’s Manual Chapter 10 Information This chapter provides information about accessing the Information menu and using its features. Figure 10.0.1 shows the architecture of the Information menu. Information Registrar Status Proxy Status Current IP Addr WLAN Status Current SSID... -
Page 31: Network Information
SENAO SI-7800H User’s Manual 10.2 Network Information Network and WLAN status can be shown here. 10.3 System Information You can get information about the Firmware Version, Serial Number and Hardware Version here. SENAO INTERNATIONAL CO., LTD. -
Page 32: Chapter 11 Profile
SENAO SI-7800H User’s Manual Chapter 11 Profile This chapter provides information about accessing the Profile menu and using its features. In standby mode, you can press the hot key ‘ ’ to access the Profile menu. Figure 11.0.1 shows the architecture of the Profile menu. -
Page 33: Speed Dial
SENAO SI-7800H User’s Manual WiFi Phone Unlock Figure 11.1.1 Key-locked screen You can unlock it by pressing twice. The phone will go to standby mode. 11.2 Speed Dial The Speed Dial menu allows users to dial a number from the list of placed calls. -
Page 34: Chapter 12 Web-Based Management Interface
Start the IE (or other browsers) to navigate SI-7800H web management interface by entering the IP address (192.168.3.20 in the below example) of the SI-7800H in the browser’s URL field. The LOGIN window will display Username and Password as shown in Figure 12.1.1. The default Username is “admin”... -
Page 35: System Setting
SENAO SI-7800H User’s Manual are six configuration items: System, LAN, Wireless, SIP, Phone Settings and Phonebook. All of these configuration items will be described in the following sections. Figure 12.2.1 Main Page of the Management Interface 12.3 System Setting Clicking the System item on the left side of the main page will bring you to the System Setting page as shown in Figure 12.3.0.1. -
Page 36: System Date & Time
SENAO SI-7800H User’s Manual Figure 12.3.0.1 System Setting Page 12.3.1 System Date & Time Clicking the System Date & Time option will bring you to the System Date & Time page. You can set date, time, time zone, enable or disable daylight saving function and using SNTP servers to get time information. -
Page 37: Firmware Upgrade
After the firmware is upgraded successfully, the Login page will appear. You need t o turn the SI-7800H off and then turn it on to make the new firmware effective. Figure 12.3.3.1 Firmware Upgrade page... -
Page 38: Configuration Tools
Figure 12.3.3.3 Warning Window 12.3.4 Configuration Tools Clicking the Configuration Tools option will bring you to the Configuration Tools page. You can set SI-7800H back to its factory default settings in this option. 12.3.5 Status Clicking the Status option will bring you to the Status page. This page shows current status of the SI-7800H. -
Page 39: Dynamic Ip
SENAO SI-7800H User’s Manual Figure 12.4.0.1 LAN Setting page 12.4.1 Dynamic IP Clicking the Dynamic IP option will bring you to the Dynamic IP page. This option allows you to enable the DHCP client function of the SI-7800H. 12.4.2 Static IP Clicking the Static IP option will bring you to the Static IP page. -
Page 40: Setting
Clicking the Setting option will bring you to the Wireless Settings page. This option allows you to set all the WLAN related settings, including General, Advanced Settings, Authentication and 802.1x, of the SI-7800H. 12.6 SIP Setting Clicking the SIP item on the left side of the main page will bring you to the SIP Setting page as shown in Figure 12.6.0.1. -
Page 41: Setting
SENAO SI-7800H User’s Manual Figure 12.6.0.1 SIP Setting page 12.6.1 Setting Clicking the Setting option will bring you to the SIP Settings page. This option allows you to set all the SIP related settings, including User Information, Proxy Server, Outbound Proxy, Registrar and codec used by the SI-7800H. -
Page 42: Phone Settings
SENAO SI-7800H User’s Manual Figure 12.7.0.1 Phone Settings page 12.7.1 Phone Settings Clicking the Phone Setting option will bring you to the Phone Settings page. This option allows you to set all the phone related settings, including Ringer Melody, Melody Select, Key Tone, Vibrator and Speaker Volume. -
Page 43: Phone Book Edit
SENAO SI-7800H User’s Manual Figure 12.8.0.1 Phone Book page 12.8.1 Phone Book Edit Clicking the Phbook Edit option will bring you to the Phone Book Edit page. This option allows you to create, delete and browse items in the phone book. - Page 44 SENAO SI-7800H User’s Manual Federal Communication Commission Interference Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 45 SENAO SI-7800H User’s Manual Wireless Solution Provider Contact us: E-mail: sales@senao.com.tw http://www.senao.com SENAO INTERNATIONAL CO., LTD.
