Dinex IRAC12 Series Operating & Maintenance Manual

Air curtain refrigerator

Advertisement

Air curtain refrigerator
Operating & Maintenance Manual
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Operating Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Unit Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Wiring Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Replacement Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Dinex® Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
!
4711 E . Hefner Rd . (73131) • PO Box 53006 • Oklahoma City, OK 73152-3006
(800) 654-8210 • Fax (800) 872-4701 • www .dinex .com
Model: IRAC12XX
For Service Information call 1 .888 .673 .4639
Please provide following information:
Model Number
Serial Number
Please check the following before calling service:
Is the unit plugged-in?
Is the power switch on?
Is set temp at 34°F (3°C)
Is condenser clean?
Has the unit been
defrosted?
DO NOT DISCARD
Manual No . IRAC12_1019_A
IRAC12 41018_B

Advertisement

loading
Need help?

Need help?

Do you have a question about the IRAC12 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Dinex IRAC12 Series

  • Page 1: Table Of Contents

    Has the unit been defrosted? 4711 E . Hefner Rd . (73131) • PO Box 53006 • Oklahoma City, OK 73152-3006 Manual No . IRAC12_1019_A IRAC12 41018_B (800) 654-8210 • Fax (800) 872-4701 • www .dinex .com DO NOT DISCARD...
  • Page 2: Introduction

    Congratulations! You have just purchased one of the finest pieces of equipment on the market today . Before install- ing or operating our new Dinex® Products equipment you WARNING: Installation of this equipment should be should read through this material . This manual should be...
  • Page 3 AIR CURTAIN REFRIGERATOR | 3 OPERATIONAL INSTRUCTIONS 7 . In cases where the air curtain will not be filled to capacity, evenly space the trays from top to bottom . Proper trays sizes (14 x 18 or 18 x 26) must be used . If 14 x 18 trays are used, insert 2 trays per slide .
  • Page 4 AIR CURTAIN REFRIGERATOR | 4 OPERATIONAL INSTRUCTIONS CONTROLLER OPERATION The air curtain refrigerator is equipped with an energy 1 . Removed the pan/tray slides by lifting the inner management system with dual compressors to operate Side panels up and out . Wash tray slides with Non- efficiently .
  • Page 5: Maintenance

    AIR CURTAIN REFRIGERATOR | 5 PROCEDURE FOR REVERSING THE AIR MAINTENANCE CURTAIN DOOR SWING The Air Screen Refrigerator was designed to operate at a 1 . Remove door . (See Fig . 1) range of 34 F (1 .11 C) to 40 F (4 .44 C) . The pull down time (time required to go from room temperature to 36 F) is NOTE: Remove only the 6 bolts (3 per hinge) that hold approximately 40 minutes .
  • Page 6 AIR CURTAIN REFRIGERATOR | 6 4 . Remove the door latch . (See Fig . 3) Turn it over to accommodate the new orientation and mount to the opposite side of the door . Upon reorientation, make sure that the handle will be in the down position when the door is reinstalled .
  • Page 7: Unit Specifications

    AIR CURTAIN REFRIGERATOR | 7 Unit Diagram PLUG CONFIGURATION NEMA 5-20P Items and Dimensions ELECTRICAL CASTERS ITEM SHIP SHIP SPECIFICATIONS LENGTH DEPTH HEIGHT NUMBER WEIGHT CUBE TYPE DIAMETER AMPS VOLTS 31 .5" 43 .5" 80" 4 Swivel 6" 598lb DXIRAC12RS 12 .3 63 .4 (80 .0 cm)
  • Page 8: Wiring Diagram

    AIR CURTAIN REFRIGERATOR | 8 8(3)A 8(3)A Page 8...
  • Page 9 Page 9...
  • Page 10: Replacement Parts

    AIR CURTAIN REFRIGERATOR | 10 Replacement Parts Part Number Description DX186140051 Accumulator 5/8 Suct. DX160025190 Push handle assembly DX186140245 Blade, fan evaporator DX186020031 Boot, toggle switch DX290340050 Breaker strip, grey DXTSBP6F Fixed 6" Performa DX183016218 Swivel 6" Performa with *side* brake DX186140276 Evaporator coil, #5598 DX186140403 Evaporator coil, #6759 DX186125050 Condensing unit R134a 1/2 HP...
  • Page 11: Dinex Warranty

    Warranty service will be performed without charge from 8:00 a .m . to 5:00 • Plate Heater Products p .m . CST, Monday - Friday, excluding Dinex holidays, and outside those • Base Heater Products hours at Dinex’s then prevailing service rates and subject to the availability •...
  • Page 12 Dinex or recommended in writing by Dinex; (v) the use of the Warranted Product in a manner or environment, or for any purpose, for which Dinex did not design or license it, or inconsistent with Dinex’s recommendations or instructions...
  • Page 13 AIR CURTAIN REFRIGERATOR | 13...
  • Page 14 Please confirm that you have the most current specification sheet by visiting www .carlislefsp .com . Dinex reserves the right to change specifications and product design without notice . Such revisions do not entitle the buyer to corresponding changes, improvements, additions or replacements for previously purchased equipment .
