Syringe Pump Series
Model '11'
User's Manual
Model '11' Single Syringe
Model '11' Dual Syringe
55-1199
55-4154

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 11 series and is the answer not in the manual?

Questions and answers

Summary of Contents for Harvard Apparatus 11 series

  • Page 1 Model ‘11’ Syringe Pump Series User’s Manual Model ‘11’ Single Syringe 55-1199 Model ‘11’ Dual Syringe 55-4154...
  • Page 2: Table Of Contents

    Table of Contents SUBJECT PAGE NO. Table of Contents ................1 General Information - Warranty and Repairs......2 Introduction ................3 Theory of Operation..............3 Features ................3 New Pump 11, Front and Rear Views ........4 Installation ..................5 Initial Setup & Location Requirements ........5 Loading the Syringe ..............5 Fuse Replacement ..............6 Operation ..................7 Getting Started ..............7...
  • Page 3: General Information - Warranty And Repairs

    Warranty Harvard Apparatus warranties this instrument for a period of one year from date of purchase. At its option, Harvard Apparatus will repair or replace the unit if it is found to be defective as to workmanship or material. This warranty does not extend to damage resulting from misuse, neglect or abuse, normal wear and tear, or accident.
  • Page 4: Introduction

    Introduction Theory of Operation: The new Pump 11 is designed as a low cost, highly precise, single syringe infusion pump capable of low to moderate back pressures. The pump comes in two versions; one to hold one syringe of any make from 0.5 µl to 60ml and a second to hold two syringes of any make from 0.5 µl to 10 ml.
  • Page 5: New Pump 11, Front And Rear Views

    Introduction New Pump ‘11’, Front and Rear Views...
  • Page 6: Installation

    Installation Initial Set-up Read the manual to become familiar with all features and functions of the new Pump 11. Pumps are shipped from the factory with an American line cord with a U.S three wire molded power plug on one end and a IEC 320/C13 connector on the other.
  • Page 7: Fuse Replacement

    Fuse Replacement Fuse Replacement Make sure the power cord is disconnected from the main supply before servicing the fuse. Fuse Replacement Procedure Turn off power, remove power cord from power module. Use straight blade screw driver, pry open access door. Remove fuse holder, remove fuse(s) from holder. Replace fuse(s) and fuse holder.
  • Page 8: Operation

    Operation: Getting Started Getting started 1. Turn Pump ‘ON’ Turn on power using the switch on rear of the pump, the display will light, and indicate POWER FAIL. (this is normal as the pump indicates on the dis- play if power was disrupted since last use.) 2.
  • Page 9: Entering Syringe Size

    Operation: Getting Started 3. Enter Syringe Size Enter the inside diameter (ID) of the syringe you wish to use. Units are in mil- limeters (mm). If you do not know your syringe diameter, refer to appendix B for nominal inside diameters of most popular syringes.
  • Page 10: Advanced Features

    Operation: Advanced Features 1. Volume Mode The Pump 11 can be set to dispense a precise volume and then stop. To activate the volume dispense mode a target volume must be set. To set a target volume, at the RATE VOL CONFIG display, move the underline cursor, using the , to VOL.
  • Page 11: Display Intensity

    Operation: Advanced Features 3. Display Intensity For varying light conditions, four levels of intensity can be set on the vacuum fluorescent display. To set the desired display intensity, at the RATE VOL CONFIG display, move the underline cursor, using the key, to CONFIG.
  • Page 12: Specifications

    Appendix A Pump ‘11’ Specifications Type Microprocessor single or dual syringe, infusion only Syringe/Size for Pump ‘11’ with Holder For: Plastic or glass 1 Syringe From 10 µ l to 50/60 ml 2 Syringe From 0.5 µ l to 10 ml Flow Rate Range: Minimum / Maximum 0.0014 µ...
  • Page 13: Table Of Popular Syringe Diameters

    Appendix B: Syringe Inside Diameter ––––––––––––––––––– ––––––––––––––––––– ––––––––––––––––––– Terumo Stainless Steel Size Diameter Size Diameter Scientific Glass 8 cc 9.525 mm 3 cc 8.95 mm Engineering 20 cc 19.130 13.00 Size Diameter 50 cc 28.600 15.80 25 µl 0.73 mm 100 cc 34.900 20.15...
  • Page 14: Table Of Minimum And Maximum Flow Rates

    Appendix C: Flow Rates nominal nominal µl/hr µl/min ml/hr ml/min syringe diameter size (mm) 0.10 0.0014 22.35 0.0001 0.3725 0.0001 0.0223 0.0001 0.0003 1 µ l 0.15 0.0031 50.29 0.0001 0.8383 0.0001 0.0502 0.0001 0.0008 2 µ l 0.21 0.0061 98.58 0.0002 1.6430...
