O W N E R ' S M A N U A L
1. Read this manual carefully before starting assembly. Read each step completely
before beginning each step.
2. Some smaller parts may be shipped inside larger parts. Check inside all parts and
cartons before assembling or ordering parts.
3. To make assembly of your basketball system easier, use the Hardware Identifier on
page 3 and 4 to identify and sort all fasteners. Check all cartons for kits. All hardware
is not located in one kit.
4. Do not tighten hardware until instructed to do so. If hardware is tightened too soon,
mounting holes may not align and parts may not easily fit together. Leave locknuts slightly
loose until you are instructed to tighten them.
5.
Save this instruction and your proof of purchase (receipt) in the event that the manufacturer
has to be contacted for replacement parts.
Please Do Not Return This Product to the Store!
Contact Escalade
Phone:
1-888-USA-GOAL
Fax:
1-866-873-3536
E-mail:
basketball@escaladesports.com
Mailing Address:
Escalade Sports
PO Box 889
Evansville, IN 47706
Please visit our World Wide Web site at:
ON-LINE TROUBLE SHOOTING
ON-LINE PARTS REQUESTS
ADDITIONAL ESCALADE® SPORTS PRODUCT INFORMATION
Escalade® Sports products may be manufactured and/or licensed under the following patents.
6419596, 6179733, 5919102, 5071120, 4798381, 4424968, D326128
Additional patents may be pending. One or more of the listed patents and/or pending patents may cover specific product.
® ® ® ® ®
Sports customer service department at:
Toll – Free !
Toll – Free !
www.goalrilla.com
TECHNICAL ASSISTANCE
FREQUENTLY ASKED QUESTIONS
MODEL NO.
B B 3 10 0W
GS-I BASKETBALL SYSTEM
Ó2017 Escalade
2L-7254-03
Ò
Sports
Advertisement
Table of Contents
Related Manuals for GOALRILLA B3100W
Summary of Contents for GOALRILLA B3100W
- Page 1 Toll – Free ! E-mail: basketball@escaladesports.com Mailing Address: Escalade Sports PO Box 889 Evansville, IN 47706 www.goalrilla.com Please visit our World Wide Web site at: ON-LINE TROUBLE SHOOTING TECHNICAL ASSISTANCE ON-LINE PARTS REQUESTS FREQUENTLY ASKED QUESTIONS ADDITIONAL ESCALADE® SPORTS PRODUCT INFORMATION 2L-7254-03 Escalade®...
- Page 3 HARDWARE IDENTIFIER 1/2” X 1-1/4” Dia. Plastic-Washer (4 Pieces) / 1 2” -13 x 1” / 1 2” Flat Washer Hex Bolt (2 Pieces) (2 Pieces) Pull Pin (1 Piece) 1/2” Split Lock Washer (2 Pieces) Hardware located in 4A-7081-00 box 1/2”-13 x 11”...
- Page 4 HARDWARE IDENTIFIER 3/8”-16 Nylon Insert 3/8” X 19mm Flat Washer Locknut (4 pieces) (4 Pieces) Hardware required for rim assembly 3/8”-16 Nylon Insert 1/2”-13 x 12” 1/2”-13 x 12” Locknut 3/8” Flat Washer Hex Bolt Hex Bolt (4 Pieces) (8 Pieces) (2 Pieces) (2 Pieces) 3/8”-16 X 1-1/4”...
- Page 5 Vertical main post assembly is a two part process. PART 1 PART 2 Day 1. Complete Anchor System Installation Instructions. Day 5. Complete Goalrilla assembly instructions. (Requires (Below) four adults) Day 2-4. Allow concrete to cure. ANCHOR SYSTEM INSTALLATION INSTRUCTIONS (Day 1)
- Page 6 5. Attach lower arm (#11) to Pole (#2), as shown in Figure 5, using a bolt (#8), two flat washers (#3), four plastic washers (#5) and hex nut (#4). Note: make sure "Goalrilla" lettering is right side up. DO NOT tighten bolt (#8) at this time. See Figure 5.
- Page 7 Secure Actuator (#16) to Lower Arm (#11) using one bolt (#8), two flat washers (#3), four plastic washers (#5) and one hex nut (#4). See Figure 6. Tighten both bolts (#8) securing Lower Arm (#11). Note: Tighten bolts snug but, do not over tighten. Board Arms must pivot freely.
- Page 8 Locate hardware needed to mount pole to anchor bolts. You will need, eight flat washers (#37), four lock washers (#36), four hex nuts (#35) and four thread protectors (#34). NOTE: Do not remove the nuts #35 you installed in step 2 (pg. 5). PLACING THE POST ON THE ANCHOR SYSTEM REQUIRES AT LEAST FOUR CAPABLE ADULTS.
- Page 9 Slide Actuator Handle (#42) onto shaft on the back of Actuator (#16). Line up hole in shaft with hole in Actuator Handle and insert Pull Pin (#41) to secure. Toaid in the assembly of the backboard lower the lower board arm (#11), by turning the Actuator Crank, until the lower arm makes contact with the Safety Stop.
- Page 10 ATTACHING BACKBOARD TO BOARD ARMS REQUIRES AT LEAST FOUR CAPABLE ADULTS. 15. With at least three capable people, raise the backboard assembly up and have the fourth attach Lower Board Arms to lower mounting holes on backboard using two bolts (#20), two step 3 20 bushings (#22), (shipped already installed), four plastic washers (#5), four flat washers (#3) and two thin...
- Page 11 Two adults are recommended for this step, one to level and one to adjust the bottom #35 nuts. If further leveling is required loosen top #35 nuts but do not loosen past the top of #39 “J” Bolt. DO NOT REMOVE NUTS #35 Place a level on pole and adjust bottom nuts #35 with a 15/16”...
- Page 12 Raise Backboard to 10 FT. regulation playing height. Measure from top of rim straight down to the playing surface. Using tape - mark the side of the steel actuator (#16) just under the plastic actuator sleeve (#15) at this 10 ft rim height. See Figure 13. Lower backboard all the way down.
- Page 13 Subject to proper installation and normal Residential use, Escalade Sports warrants, subject to the limitations below, to the original retail purchaser all structural components of the Goalrilla™ System to be free of defects in material and workmanship for the duration of ownership by the original retail purchaser.
-
Page 14: Care And Maintenance
To ensure ease of operation, lubricate all pivot points at least every 6 months or as needed with a good lubricant such as WD-40. RUST Inspect your pole periodically, if rust should appear , remove loose paint, sand lightly, primer and paint with exterior flat matte finish enamel paint. B3100W PARTS LIST Key# Part # Description Qty. - Page 15 3 20 20 3 2L-7254-03...
- Page 16 2L-7254-03...
