Operating instructions
for a MEIKO – round-belt conveyor system
with vertical conveyor
Type RF with VF – P (platform)
Type RF with VF – G (fork)
TRANSLATION OF "ORIGINAL OPERATING INSTRUCTIONS"
The original operating instructions can be downloaded from: https://partnernet.meiko.de
1/40
9750655
File: BA_RFmitVF_9750655_EN_2017-05.docx
Update: 2018-04-10
Design and const ruction subject to change wit hout prior notice!
MEIKO Maschinenbau GmbH & Co. KG, Englerstraße 3, D-77652 Offenburg, Tel.: +49 (0)781/203-0, Fax: +49 (0)781/203-1174
Advertisement
Table of Contents
Related Manuals for Meiko RF
Summary of Contents for Meiko RF
- Page 1 The original operating instructions can be downloaded from: https://partnernet.meiko.de 1/40 9750655 File: BA_RFmitVF_9750655_EN_2017-05.docx Update: 2018-04-10 Design and const ruction subject to change wit hout prior notice! MEIKO Maschinenbau GmbH & Co. KG, Englerstraße 3, D-77652 Offenburg, Tel.: +49 (0)781/203-0, Fax: +49 (0)781/203-1174...
-
Page 2: Table Of Contents
11.3 Tray infeed station (illustrations of improper loading) ........28 2/40 9750655 File: BA_RFmitVF_9750655_EN_2017-05.docx Update: 2018-04-10 Design and const ruction subject to change wit hout prior notice! MEIKO Maschinenbau GmbH & Co. KG, Englerstraße 3, D-77652 Offenburg, Tel.: +49 (0)781/203-0, Fax: +49 (0)781/203-1174... - Page 3 Additional elements of a round-belt conveying system ........39 3/40 9750655 File: BA_RFmitVF_9750655_EN_2017-05.docx Update: 2018-04-10 Design and const ruction subject to change wit hout prior notice! MEIKO Maschinenbau GmbH & Co. KG, Englerstraße 3, D-77652 Offenburg, Tel.: +49 (0)781/203-0, Fax: +49 (0)781/203-1174...
-
Page 4: Introduction And General Instructions
Dear customer, We are delighted about the confidence you have shown in our products. It is very important to us that you enjoy using MEIKO products and that they are extremely useful to you, making your work easier. If you follow the instructions in this document carefully, your conveying system will always work to your complete satisfaction and have a long service life. -
Page 5: Safe Keeping
This information can be found on the descriptive plaque. 5/40 9750655 File: BA_RFmitVF_9750655_EN_2017-05.docx Update: 2018-04-10 Design and const ruction subject to change wit hout prior notice! MEIKO Maschinenbau GmbH & Co. KG, Englerstraße 3, D-77652 Offenburg, Tel.: +49 (0)781/203-0, Fax: +49 (0)781/203-1174... -
Page 6: Explanation Of The Safety Symbols Used
Do not reach into the machine while it is running! 6/40 9750655 File: BA_RFmitVF_9750655_EN_2017-05.docx Update: 2018-04-10 Design and const ruction subject to change wit hout prior notice! MEIKO Maschinenbau GmbH & Co. KG, Englerstraße 3, D-77652 Offenburg, Tel.: +49 (0)781/203-0, Fax: +49 (0)781/203-1174... -
Page 7: General Description And Intended Use
The operator, not the manufacturer, is responsible for any injury or material damage aris- ing from improper use. 7/40 9750655 File: BA_RFmitVF_9750655_EN_2017-05.docx Update: 2018-04-10 Design and const ruction subject to change wit hout prior notice! MEIKO Maschinenbau GmbH & Co. KG, Englerstraße 3, D-77652 Offenburg, Tel.: +49 (0)781/203-0, Fax: +49 (0)781/203-1174... -
Page 8: Ec Declaration Of Conformity
An EC declaration of conformity is provided with the machine if it is supplied in a fully operational state as a complete machine. 8/40 9750655 File: BA_RFmitVF_9750655_EN_2017-05.docx Update: 2018-04-10 Design and const ruction subject to change wit hout prior notice! MEIKO Maschinenbau GmbH & Co. KG, Englerstraße 3, D-77652 Offenburg, Tel.: +49 (0)781/203-0, Fax: +49 (0)781/203-1174... -
Page 9: Ec Declaration Of Conformity
Director técnico / Technisch directeur / Teknisk direktör 9/40 9750655 File: BA_RFmitVF_9750655_EN_2017-05.docx Update: 2018-04-10 Design and const ruction subject to change wit hout prior notice! MEIKO Maschinenbau GmbH & Co. KG, Englerstraße 3, D-77652 Offenburg, Tel.: +49 (0)781/203-0, Fax: +49 (0)781/203-1174... -
Page 10: Declaration Of Incorporation
överensstämmelse med bestämmelserna i nedan angivna ytterligare EG-direktiv: 2014/30/EU 10/40 9750655 File: BA_RFmitVF_9750655_EN_2017-05.docx Update: 2018-04-10 Design and const ruction subject to change wit hout prior notice! MEIKO Maschinenbau GmbH & Co. KG, Englerstraße 3, D-77652 Offenburg, Tel.: +49 (0)781/203-0, Fax: +49 (0)781/203-1174... - Page 11 Director técnico / Technisch directeur / Teknisk direktör 11/40 9750655 File: BA_RFmitVF_9750655_EN_2017-05.docx Update: 2018-04-10 Design and const ruction subject to change wit hout prior notice! MEIKO Maschinenbau GmbH & Co. KG, Englerstraße 3, D-77652 Offenburg, Tel.: +49 (0)781/203-0, Fax: +49 (0)781/203-1174...
-
Page 12: Technical Specifications
CAUTION! 12/40 9750655 File: BA_RFmitVF_9750655_EN_2017-05.docx Update: 2018-04-10 Design and const ruction subject to change wit hout prior notice! MEIKO Maschinenbau GmbH & Co. KG, Englerstraße 3, D-77652 Offenburg, Tel.: +49 (0)781/203-0, Fax: +49 (0)781/203-1174... - Page 13 (order no.: 9552501) and do not remove it. 13/40 9750655 File: BA_RFmitVF_9750655_EN_2017-05.docx Update: 2018-04-10 Design and const ruction subject to change wit hout prior notice! MEIKO Maschinenbau GmbH & Co. KG, Englerstraße 3, D-77652 Offenburg, Tel.: +49 (0)781/203-0, Fax: +49 (0)781/203-1174...
-
Page 14: Basic Safety Measures
Environmentally hazardous lubricants, coolants or cleaning agents must be disposed of correctly. 14/40 9750655 File: BA_RFmitVF_9750655_EN_2017-05.docx Update: 2018-04-10 Design and const ruction subject to change wit hout prior notice! MEIKO Maschinenbau GmbH & Co. KG, Englerstraße 3, D-77652 Offenburg, Tel.: +49 (0)781/203-0, Fax: +49 (0)781/203-1174... -
Page 15: Instructions - Tray Infeed Station
Instructions – tray infeed station Please observe user instruction plates. 15/40 9750655 File: BA_RFmitVF_9750655_EN_2017-05.docx Update: 2018-04-10 Design and const ruction subject to change wit hout prior notice! MEIKO Maschinenbau GmbH & Co. KG, Englerstraße 3, D-77652 Offenburg, Tel.: +49 (0)781/203-0, Fax: +49 (0)781/203-1174... -
Page 16: Assembly Instructions (For A Partially Completed Machine)
If any further unknown sources of danger that are not described by MEIKO arise due to connecting system parts, you must eliminate them and, in some cases, this may mean that the machine cannot be commissioned. -
Page 17: Delivery, Transport, Installation And Assembly
We do not accept any liability for damage caused by unprofessionally implemented con- nection work. 17/40 9750655 File: BA_RFmitVF_9750655_EN_2017-05.docx Update: 2018-04-10 Design and const ruction subject to change wit hout prior notice! MEIKO Maschinenbau GmbH & Co. KG, Englerstraße 3, D-77652 Offenburg, Tel.: +49 (0)781/203-0, Fax: +49 (0)781/203-1174... -
Page 18: Instructions For The Disposal Of Packing Material
Accident protection system 9750655 18/40 File: BA_RFmitVF_9750655_EN_2017-05.docx Update: 2018-04-10 Design and const ruction subject to change wit hout prior notice! Accident protection MEIKO Maschinenbau GmbH & Co. KG, Englerstraße 3, D-77652 Offenburg, Tel.: +49 (0)781/203-0, Fax: +49 (0)781/203-1174 system... -
Page 19: Accident Protection On The Corners
In order to avoid accident and injury, ensure that the accident protection system is not removed. 19/40 9750655 File: BA_RFmitVF_9750655_EN_2017-05.docx Update: 2018-04-10 Design and const ruction subject to change wit hout prior notice! MEIKO Maschinenbau GmbH & Co. KG, Englerstraße 3, D-77652 Offenburg, Tel.: +49 (0)781/203-0, Fax: +49 (0)781/203-1174... -
Page 20: Product Description
End of belt with pin limit switch Switch cabinet Touch panel 20/40 9750655 File: BA_RFmitVF_9750655_EN_2017-05.docx Update: 2018-04-10 Design and const ruction subject to change wit hout prior notice! MEIKO Maschinenbau GmbH & Co. KG, Englerstraße 3, D-77652 Offenburg, Tel.: +49 (0)781/203-0, Fax: +49 (0)781/203-1174... -
Page 21: Control Elements And Details
In case of dan- ger, activate the EMERGENCY STOP. 21/40 9750655 File: BA_RFmitVF_9750655_EN_2017-05.docx Update: 2018-04-10 Design and const ruction subject to change wit hout prior notice! MEIKO Maschinenbau GmbH & Co. KG, Englerstraße 3, D-77652 Offenburg, Tel.: +49 (0)781/203-0, Fax: +49 (0)781/203-1174... - Page 22 Press the ON key on the control panel to start up the installation. 22/40 9750655 File: BA_RFmitVF_9750655_EN_2017-05.docx Update: 2018-04-10 Design and const ruction subject to change wit hout prior notice! MEIKO Maschinenbau GmbH & Co. KG, Englerstraße 3, D-77652 Offenburg, Tel.: +49 (0)781/203-0, Fax: +49 (0)781/203-1174...
-
Page 23: Check That All Safety Equipment Is Working
Pin limit switch switches Control panel on vertical conveyor 23/40 9750655 File: BA_RFmitVF_9750655_EN_2017-05.docx Update: 2018-04-10 Design and const ruction subject to change wit hout prior notice! MEIKO Maschinenbau GmbH & Co. KG, Englerstraße 3, D-77652 Offenburg, Tel.: +49 (0)781/203-0, Fax: +49 (0)781/203-1174... -
Page 24: Height Limitation, Control Panel With Indicator Light
24/40 9750655 File: BA_RFmitVF_9750655_EN_2017-05.docx Update: 2018-04-10 Design and const ruction subject to change wit hout prior notice! MEIKO Maschinenbau GmbH & Co. KG, Englerstraße 3, D-77652 Offenburg, Tel.: +49 (0)781/203-0, Fax: +49 (0)781/203-1174... - Page 25 The instructions on how to restart after a shut down in chapter 8 Cleaning in chapter 10. 25/40 9750655 File: BA_RFmitVF_9750655_EN_2017-05.docx Update: 2018-04-10 Design and const ruction subject to change wit hout prior notice! MEIKO Maschinenbau GmbH & Co. KG, Englerstraße 3, D-77652 Offenburg, Tel.: +49 (0)781/203-0, Fax: +49 (0)781/203-1174...
-
Page 26: Special Functions: Queuing Function
SECTION I SECTION II 26/40 9750655 File: BA_RFmitVF_9750655_EN_2017-05.docx Update: 2018-04-10 Design and const ruction subject to change wit hout prior notice! MEIKO Maschinenbau GmbH & Co. KG, Englerstraße 3, D-77652 Offenburg, Tel.: +49 (0)781/203-0, Fax: +49 (0)781/203-1174... -
Page 27: Operation
Do not reach under the belts during operation. 27/40 9750655 File: BA_RFmitVF_9750655_EN_2017-05.docx Update: 2018-04-10 Design and const ruction subject to change wit hout prior notice! MEIKO Maschinenbau GmbH & Co. KG, Englerstraße 3, D-77652 Offenburg, Tel.: +49 (0)781/203-0, Fax: +49 (0)781/203-1174... -
Page 28: Tray Infeed Station (Illustrations Of Improper Loading)
Press white push button marked "ON" on the control panel. The round-belt conveyor is on. 28/40 9750655 File: BA_RFmitVF_9750655_EN_2017-05.docx Update: 2018-04-10 Design and const ruction subject to change wit hout prior notice! MEIKO Maschinenbau GmbH & Co. KG, Englerstraße 3, D-77652 Offenburg, Tel.: +49 (0)781/203-0, Fax: +49 (0)781/203-1174... -
Page 29: Shutting Down
Ensure that these traps are emptied daily. Light key 29/40 9750655 File: BA_RFmitVF_9750655_EN_2017-05.docx Update: 2018-04-10 Design and const ruction subject to change wit hout prior notice! MEIKO Maschinenbau GmbH & Co. KG, Englerstraße 3, D-77652 Offenburg, Tel.: +49 (0)781/203-0, Fax: +49 (0)781/203-1174... -
Page 30: Daily Cleaning
"up/down" key is released for manual operation on the vertical conveyor control panel. 30/40 9750655 File: BA_RFmitVF_9750655_EN_2017-05.docx Update: 2018-04-10 Design and const ruction subject to change wit hout prior notice! MEIKO Maschinenbau GmbH & Co. KG, Englerstraße 3, D-77652 Offenburg, Tel.: +49 (0)781/203-0, Fax: +49 (0)781/203-1174... -
Page 31: Care Of Stainless Steel Surfaces
Observe the manufacturers' hazard warnings on the original containers and safety data sheets. 31/40 9750655 File: BA_RFmitVF_9750655_EN_2017-05.docx Update: 2018-04-10 Design and const ruction subject to change wit hout prior notice! MEIKO Maschinenbau GmbH & Co. KG, Englerstraße 3, D-77652 Offenburg, Tel.: +49 (0)781/203-0, Fax: +49 (0)781/203-1174... -
Page 32: Training Of Personnel
Electrical and electronic parts PP and other plastics 32/40 9750655 File: BA_RFmitVF_9750655_EN_2017-05.docx Update: 2018-04-10 Design and const ruction subject to change wit hout prior notice! MEIKO Maschinenbau GmbH & Co. KG, Englerstraße 3, D-77652 Offenburg, Tel.: +49 (0)781/203-0, Fax: +49 (0)781/203-1174... -
Page 33: Maintenance
Check tray guides before, on and after corners 33/40 9750655 File: BA_RFmitVF_9750655_EN_2017-05.docx Update: 2018-04-10 Design and const ruction subject to change wit hout prior notice! MEIKO Maschinenbau GmbH & Co. KG, Englerstraße 3, D-77652 Offenburg, Tel.: +49 (0)781/203-0, Fax: +49 (0)781/203-1174... -
Page 34: Vertical Conveyor
Check light barriers and light switches are working and se- curely fitted 34/40 9750655 File: BA_RFmitVF_9750655_EN_2017-05.docx Update: 2018-04-10 Design and const ruction subject to change wit hout prior notice! MEIKO Maschinenbau GmbH & Co. KG, Englerstraße 3, D-77652 Offenburg, Tel.: +49 (0)781/203-0, Fax: +49 (0)781/203-1174... -
Page 35: Top, Covered Tracks
Check the working of the electrical switches and controls 35/40 9750655 File: BA_RFmitVF_9750655_EN_2017-05.docx Update: 2018-04-10 Design and const ruction subject to change wit hout prior notice! MEIKO Maschinenbau GmbH & Co. KG, Englerstraße 3, D-77652 Offenburg, Tel.: +49 (0)781/203-0, Fax: +49 (0)781/203-1174... -
Page 36: Tray Junction, Tzf
(see "adjustment tray feeding device", TST7 operating instructions) 36/40 9750655 File: BA_RFmitVF_9750655_EN_2017-05.docx Update: 2018-04-10 Design and const ruction subject to change wit hout prior notice! MEIKO Maschinenbau GmbH & Co. KG, Englerstraße 3, D-77652 Offenburg, Tel.: +49 (0)781/203-0, Fax: +49 (0)781/203-1174... -
Page 37: Safety
If this happens, the user becomes liable for any damage. 37/40 9750655 File: BA_RFmitVF_9750655_EN_2017-05.docx Update: 2018-04-10 Design and const ruction subject to change wit hout prior notice! MEIKO Maschinenbau GmbH & Co. KG, Englerstraße 3, D-77652 Offenburg, Tel.: +49 (0)781/203-0, Fax: +49 (0)781/203-1174... -
Page 38: Emergency Exit
In accordance with the 3rd regulation of the German Law on Appliance Safety, noise levels are below 70 dB (A). 38/40 9750655 File: BA_RFmitVF_9750655_EN_2017-05.docx Update: 2018-04-10 Design and const ruction subject to change wit hout prior notice! MEIKO Maschinenbau GmbH & Co. KG, Englerstraße 3, D-77652 Offenburg, Tel.: +49 (0)781/203-0, Fax: +49 (0)781/203-1174... -
Page 39: Additional Elements Of A Round-Belt Conveying System
(Observe the technical documentation for the dishwashing machine.) 39/40 9750655 File: BA_RFmitVF_9750655_EN_2017-05.docx Update: 2018-04-10 Design and const ruction subject to change wit hout prior notice! MEIKO Maschinenbau GmbH & Co. KG, Englerstraße 3, D-77652 Offenburg, Tel.: +49 (0)781/203-0, Fax: +49 (0)781/203-1174...
