LR-500-072/216 Quick Reference Card
Power/Charging Por
Channel Select Buttons
Channel Display: Displays the
channel the LR-500 is currently on.
RF Receive
Indicator:
Indicates the
RF receive
level
.
PGM:
Program
function is in
Lock Icon: Indicates the unit is
process.
locked on current channel.
t
Front Door Loc
k
Battery Level
Indicator
L/O: Indicates while in programming
mode the specific channel has
been locked out.
© 2008 Listen Technologies Corporation
3.5 mm Output Jack: Connect a Listen earphone(s) here.
LED: When lit, indicates unit has power. When
batteries are low or charging the LED flashes
On/Off and Volume Control Dial
®
All Rights Reserved 200859
Look&Listen™ Display:
Shows receive level, channel,
programming, battery status,
and lock status.
SEEK Button: Allows the user
to search for or lock onto an
active channel.
Battery Select Switch: Choose
the type of batteries being
used - Alkaline or NiMH.
SQ™ Switch: Turns SQ™ On/Off.
Battery Compartment:
Place two (2) AA batteries
in compartment. Be sure to
follow polarity pattern.
