LR-200-072 Quick Reference Card
Power/Charging Port
Front Door Lock
Channel Select Switch:
There are 3 separate channels
(A, E, H) available.
3.5 mm Output Jack: Connect a Listen earphone(s) here.
e le c t
n e l S
C h a n
© 2008 Listen Technologies Corporation
LED: When lit, unit is On or charging.
When batteries are low, the LED flashes.
On/Off and Volume Control Dial
Battery Select Switch: Choose
the type of batteries being
used - Alkaline or NiMH.
le c t
ry S e
B a tt e
N iM H
li n e
A lk a
Battery Compartment: Place two (2) AA
batteries in compartment. Be sure to
follow polarity pattern.
®
All Rights Reserved 200859
le c t
ry S e
B a tt e
N iM H
e le c t
li n e
n e l S
A lk a
C h a n
Advertisement
Table of Contents
Related Manuals for Listen LR-200-072
Summary of Contents for Listen LR-200-072
- Page 1 LR-200-072 Quick Reference Card 3.5 mm Output Jack: Connect a Listen earphone(s) here. LED: When lit, unit is On or charging. When batteries are low, the LED flashes. On/Off and Volume Control Dial Power/Charging Port Battery Select Switch: Choose the type of batteries being used - Alkaline or NiMH.
- Page 2 SELECT switch in your Listen product must be set to the NiMH setting. WARNING: When using a Listen charging case, the case lid MUST be open or removed while the units are charging. For further details regarding advanced options for your Listen products please visit our website at www.listentech.com Resources/Support/Manuals...
