SIP MULTIMEDIA STATION
Thank you for purchasing TOA's N-SP80MS1 SIP Multimedia Station.
Please carefully follow the instructions in this manual to ensure long, trouble-free use of your equipment.
This is a quick manual for the N-SP80MS1.
Be sure to see the separate "N-SP80 Series Instruction Manual" before using the N-SP80MS1.
The latest version of the "N-SP80 Series Instruction Manual" can be downloaded from the TOA product
data download site (http://www.toa-products.com/international/).

TABLE OF CONTENTS

1. SAFETY PRECAUTIONS ............................. 2
2. GENERAL DESCRIPTION ........................... 2
3. FEATURES ................................................... 2
4. HANDLING PRECAUTIONS ........................ 2
QUICK MANUAL
Front .............................................................. 3
Rear ............................................................... 4
Right side ...................................................... 4
6. CONNECTION .............................................. 5
N-SP80MS1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the N-SP80MS1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Toa N-SP80MS1

Summary of Contents for Toa N-SP80MS1

  • Page 1: Table Of Contents

    This is a quick manual for the N-SP80MS1. Be sure to see the separate "N-SP80 Series Instruction Manual" before using the N-SP80MS1. The latest version of the "N-SP80 Series Instruction Manual" can be downloaded from the TOA product data download site (http://www.toa-products.com/international/).

  • Page 2: Safety Precautions

    PoE switching hub may cause a fire. 2. GENERAL DESCRIPTION The N-SP80MS1 is a touch-panel type Multimedia station using Google’s Android platform designed for use in combination with the SIP (Session Initiation Protocol) Intercom system. The station can be used not only in SIP server mode but also in peer-to-peer mode: the former enables the station to work by connecting to the SIP server and the latter enables it to work without using the SIP server.

  • Page 3: Nomenclature And Functions

    5. NOMENCLATURE AND FUNCTIONS • Desktop design • Handset, Hands-free (with AEC function), Headset connectable • Built-in touch panel • PoE-compatible (IEEE802.3af compliant) • Built-in camera [Front] 10 11 1. Power ON/OFF button 6. Home button Press this button to turn on the power and pressing Returns the display to the home screen. it again will place the unit in sleep state.

  • Page 4: Rear

    15. Conference button 18. Contact button Starts the three-party conversation function. Press this button when registering or selecting the telephone book. 16. Transfer button 19. Hold button Starts the transfer function during conversation. (Only when in the SIP server mode) Starts the hold function during conversation.

  • Page 5: Connection

    6. CONNECTION N-SP80MS1 unit (Rear) To the switching hub To a PC To AC mains Theft preventing wire Supplied handset [Power supply connection] Power is supplied from the AC adaptor or the PoE-compatible switching hub. For the power supply from the switching hub, see below "2. LAN connection terminal." 1. DC input terminal Connect the AC adapter.* * Use the optional AC adapter AD-1215P or its equivalent. As for the usable adapter, consult your TOA dealer. CAUTION The use of the AC adapter other than the specified one may cause a fire. If both the AC adapter and the PoE switching hub are connected, the power will be supplied from the one that has started feeding first. [Switching hub and PC connections] 2.

  • Page 6: System Setting Using A Browser

    The default IP address is 192.168.1.101. (Subnet mask is 255.255.255.0.) When using the default IP address, enter "http: //192.168.1.101" to establish the connection. The IP address can be confirmed by selecting the "Setting" icon on the unit's touch panel. For the details, see the separate "N-SP80 Series Instruction Manual." The latest version of the "N-SP80 Series Instruction Manual" can be downloaded from the TOA product data download site (http://www.toa-products.com/international/). User name and password settings are as follows. User name: N-SP80 T he user name is fixed. It cannot be changed.
