Quick Installation & Start Guide
The UgMO UG1000R-A Repeater is part of the UG1000 family of products. The Repeater extends range
and helps form a multihop above ground mesh network between controllers, bridges and other repeaters
of the UG1000 product family.
• Remote configuration and alert reporting
• Software upgradeable to allow for future
feature expansion
Advertisement
Table of Contents
Related Manuals for UGMO UG1000 Series
Summary of Contents for UGMO UG1000 Series
- Page 1 Quick Installation & Start Guide The UgMO UG1000R-A Repeater is part of the UG1000 family of products. The Repeater extends range and helps form a multihop above ground mesh network between controllers, bridges and other repeaters of the UG1000 product family.
- Page 2 UG1000 Wireless Repeater The UG1000R-A Wireless Repeater serves as a range extender. This device is able to join an above ground multihop mesh network which then allows signals from underground sensors to travel above ground and reach controllers (UG1000C-A), other repeaters and Bridges (UG1000B or UG1000B-A). The UG1000R-A is typically installed outdoors and is wall mounted.
- Page 3 Once powered, a red LED on the front of the Repeater will aluminate followed by a series of Green LEDs as the bridge searches the area for any existing hardware or networks. The LEDs are very helpful in determining the current state and operation of the bridge.
- Page 4 Regulatory Notices FCC ID: YVAUG1000RA; IC ID: 10216A-UG1000RA M/N: UG1000R-A This device complied with Part 15 of the FCC Rules and Industry Canada License Exempt RSS Standard(s). Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
