- Page 1 WIRELESS REPEATER PH100WR Installation Manual UgMO Technologies • 840 First, Suite 300 • King of Prussia, PA 19406 • www.UgMO.com...
- Page 2 The AC adaptor can be placed up to 300’ away from the Repeater The UgMO ProHome PH100WR Repeater has been developed by splicing suitable wire. to provide both improved signal strength and extended range For long distances, multiple repeaters may be used to “hop”...
- Page 3 Components Power indicator Receive (Light toggles on or off each time a sensor packet is received) Offline (Repeater will not transmit when lit) Transmit (Blinks when a sensor packet is transmitted) On/Off Button (Press to change operational mode.) When button light is illuminated - Repeater is in normal mode.
- Page 4 Placement of a Repeater Placement of a Repeater The optimal location of a repeater is half-way between the base station and the hard-to-see Hard-to-see sensor sensor (Sensor 2) at least 5 feet above the ground. The optimal location of a repeater is half-way Sensor 1 between the base station and the hard-to-see The repeater may be placed inside the building...
- Page 5 Checking signal strength The screens to the right are accessible on the ProHome Base Station. View Sensor Screen on Base Station (See page 27 -28 of the user manual) Q Value Q Value Q-Value: This number represents the per- 2) Plug in Repeater in desired location. Menu 5 / 6 cent of the expected transmissions received...
- Page 6 Customer Service: Please visit UgMO.com or call 877-500-UgMO for customer service. This product should not be used for anything other than what is described in this document. This product should only be serviced by trained and autho- rized personnel. FCC Notice: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
