- Page 1 OPERATION MANUAL Tabletop Paper Collator FC-10 - Connected Use - A PRODUCT OF CORPORATION The Leader in Paper Handling Equipment 1-800-223-2508 www.mbmcorp.com APRIL.25.2005...
- Page 2 https://www.supplychimp.com...
- Page 3 https://www.supplychimp.com Safety Instructions Definition of Symbols and Notes In this manual following names and signs stand for possible dangers. Danger This Symbol stands for immediate danger threatening the life and health of persons. Disregarding these instructions may cause severe damage to health and even serious injuries.
-
Page 4: Table Of Contents
https://www.supplychimp.com INTRODUCTION Read this “Operation Manual” carefully before use. Keep it at a specific place for handy reference. Since the specifications of this machine are subject to change, be sure not to mistake this manual for one of a different mode, descriptions of may differ. CONTENTS 1. -
Page 5: Precautions For Installation And Use
https://www.supplychimp.com 1. PRECAUTIONS FOR INSTALLATION AND USE 1.1 Place for installation ・Locations with extremely high or low temperatures. Room temperature should be between 5 and 35 degrees centigrade. ・Locations with the potential for producing electrical leaks, for example, owing to splashing water. ・Near heat sources ・Places exposed to wind ・Narrow spots with poor ventilation, or dark places... -
Page 6: How To Connect Two Tabletop Collators
https://www.supplychimp.com 3. HOW TO CONNECT TWO TABLETOP COLLATORS 1. Assemble tabletop collator tables and install the right and left towers on them. Caution! ・As for assembly of collator, refer to the assembly plan. ・In case two connected collators are used, be sure to install them on the collator tables designed for collator. - Page 7 https://www.supplychimp.com 4. Fix the connecting chassis to the left tower (1) It spends by the hand so that the ditch of operation driver in a left tower may become the same as the direction of the pin of connecting shaft, it matches, and the pin is set in the ditch.
- Page 8 https://www.supplychimp.com 5. Install the connecting chassis at the right tower. After moving the collator table to a position where the connecting chassis can be set, hold the connecting chassis in the way as shown on the photo and insert the connecting chassis shaft into the pin (on the left side) of the right tower while pulling the chassis in the direction of arrow with your finger...
-
Page 9: How To Connect The Connector
https://www.supplychimp.com (2) Insert the right side tip of the upper chassis in the sqaure hole on the bridge side plate, and fit the upper chassis to the connecting chassis using the upper chassis fitting knob. 4. HOW TO CONNECT THE CONNECTOR Insert the power cords of the collators (right and left towers) in the power supply outlet and insert the two collators connecting cord in both... -
Page 10: How To Operate Two Collators When They Are Connected
https://www.supplychimp.com 5. HOW TO OPERATE TWO COLLATORS WHEN THEY ARE CONNECTED 1. As for power supply, first turn on the power switch of the left tower and then turn on the switch of the right tower within five seconds. If the interval between the timings to switch on two collators exceeds five seconds, or the right tower is switched on first, the machines may not work properly. -
Page 11: Relocation Or Disposal
https://www.supplychimp.com 6.RELOCATION OR DISPOSAL 6.1 Relocation 6.1.1 Removal of the machine from its present location Before removing the machine from its present location, be sure to remove the power plug from the wall outlet. 6.1.2 Transport 1) Transport the removed parts, attachments and Operation Manual together with the machine. 2) Take care not to expose the collator to strong vibration or shock. - Page 12 MBM Corporation...
