MBM FC-10 Service Manual

Tabletop paper collator
Hide thumbs Also See for FC-10:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Operating Manual
SERVICE MANUAL
for
Tabletop Paper Collator
FC-10
A PRODUCT OF
CORPORATION
The Leader in Paper Handling Equipment
1-800-223-2508
www.mbmcorp.com
APRIL.25.2005
- 0 -

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FC-10 and is the answer not in the manual?

Questions and answers

Related Manuals for MBM FC-10

Summary of Contents for MBM FC-10

  • Page 1 SERVICE MANUAL Tabletop Paper Collator FC-10 A PRODUCT OF CORPORATION The Leader in Paper Handling Equipment 1-800-223-2508 www.mbmcorp.com APRIL.25.2005 - 0 -...
  • Page 2 - 1 -...

  • Page 3: Table Of Contents

    CONTENTS Components........................4 Overview........................ 4 Operation Panel...................... 5 Important for Maintenance and Inspection ..............7 Setting Paper........................8 Precautions for setting paper.................. 8 Order of loading paper ................... 8 Loading paper in Alternate mode ................8 Loading paper in Insert and Program mode............9 Response to Lit and Flashing Lamps ................
  • Page 4 12.12 DOOR lamp remains lit..................39 12.13 Empty feed occurs while paper is fed..............39 12.14 Station lamp flashes red while checking.............. 39 12.15 Double feed frequently occurs................40 12.16 Empty feed frequently occurs................40 12.17 Empty feed or jam frequently occurs..............41 12.18 Paper is fed aslant.

  • Page 5: Components

    1. COMPONENTS 1.1 Overview 2.1 Overview Right Connector (14) and left Connector (15) are non-limited power circuit. Name Operation Panel Paper guide Paper feed table Paper feed pressure shifting lever Power switch Circuit breaker Paper feed roller Left cover Back door (10) Stacking pole (11)

  • Page 6: Operation Panel

    1.2 Operation Panel Name Function Station LED lamp Shows the collating status of each station 1 through 10. DOOR lamp Lights up when the back door is open. Shows direction of paper ejection when lighted green. ERROR (L) lamp Indicates an error in the left side collator when lighted red. Displays the number of collated sheets.
  • Page 7 Name Function Flashes green in the event of no paper or no feed. EMPTY FEE/NO (10) In case of no paper, the lamp for the relevant station blinks slowly. PAPER lamp If empty feed, the lamp for the relevant station blinks quickly. (11) EJECT lamp Lights should a paper ejection jam occur or when the stacking table is full.

  • Page 8: Important For Maintenance And Inspection

    2. PRECAUTION FOR MAINTENANCE AND INSPECTION ・Before starting maintenance and inspection work, be sure to turn the power off and remove the power cord from the outlet. ・Photo sensors are used in various parts of this machine. Be sure to clean them when maintenance work is conducted.

  • Page 9: Order Of Loading Paper

    3.2 Order of loading paper (1) Paper with the printed side down Load the paper on the feed tables from bottom to top in ascending order of pages. In this case Page 1 appears at the top of collated sheets on the stacking table.

  • Page 10: Loading Paper In Insert And Program Mode

    ・Loading paper with the printed side down in Alternate mode 3.4 Loading paper in Insert and Program mode (1) Insert mode Load partitioning paper on the top station to be used. For instance, if 10 stations are used continuously top to bottom, partitioning paper should be loaded on Station 1.
  • Page 11 Counter Other display Possible cause Corrective Action display EJECT lamp flashes red. Paper ejection jam has occurred. Remove the jammed paper. Repeat checking several times. Paper feed photo sensor of Station lamp only flashes red when Then, the luminescence intensity luminescence intensity is not fit checking is conducted.

  • Page 12: Electric Circuit Block Diagram

    5. ELECTRIC CIRCUIT BLOCK DIAGRAM 5.1 Operation circuit board Paper feed photo sensor Stations 1 through 6 Paper feed photo sensor Stations 1 through 6 Paper ejection photo sensor Full stacking photo sensor Table lifting Crisscross starting point Paper switch Back door Left side connector (25P)

  • Page 13: Speed Control Circuit Board

    5.2 Speed control circuit board Speed control circuit board Operation circuit board Main motor Terminal block...

  • Page 14: Wiring Diagram

    6. WIRING DIAGRAM...

  • Page 15: Circuit Board Diagram

    7. CIRCUIT BOARD DIAGRAM 7.1 Operation board...

  • Page 16: Speed Control Circuit Board

    7.2 Speed control circuit board...

  • Page 17: Replacement Of Paper Feed Rubber Roller And Separator

    8. REPLACEMENT OF PAPER FEED RUBBER ROLLER AND SEPARATOR Flat head Separator screwdriver ・ Replacement of paper feed rubber rollers Remove the paper feed tables. While holding the paper feed shaft, push it into the left, then pull it toward you. If the paper feed rollers are dislocated, correct their positions; the center rubber roller should be located at the center of the separator.

  • Page 18: Diagram For Belt Installation

    9. DIAGRAM FOR BELT INSTALLATION...

  • Page 19: Test Mode

    10. TEST MODE 10.1 How to set test mode Test mode is aimed at checking various machine functions individually. (1) Turn the power on while pressing the RESET and CHECK keys simultaneously. (2) The counter displays [ C– ] and the test mode is set. 10.2 Test mode functions While the test mode is on, the following six modes can be selected by pressing the MODE key.

  • Page 20: Check By Sensor

    10.4 Check on sensor function Display Function Remarks Station 1 to 10 Status of paper switch at each The lamp of the station where paper is loaded lights. (Green lamp) station Station 1 to 10 Status of paper feed photo The lamp of the station where paper jam occurs lights.

  • Page 21: Changing The System Constants

    11. CHANGING THE SYSTEM CONSTANTS System constants are aimed at allowing users to adjust the values required for operating the collator by themselves. While, taking advantage of them, users may optimize the machine operation according to the environment in which it is used, erroneous setting will cause the machine to malfunction. Closest care should be taken when system constants are changed.
  • Page 22 (2) List of system constants Item Function Initial value Contents Paper feed photo luminescence intensity can be set at 15 Adjustment of paper feed photo levels as: luminescence intensity 1 (Weak) 1 through 9, A, b, c, d, E, F (Strong) (All station adjustment) Adjustment applicable to all stations 1 through 10.

  • Page 23: Adjustment Of The Paper Feed Photo Luminescence Intensity

    11.2 Adjustment of the paper feed photo luminescence intensity Adjustment will be required if the followings occur when the CHECK key is pressed to feed paper. (A) The station lamp flashes red (due to excess or lack of luminescence intensity) (B) The EMPTY FEED lamp lights though the paper is fed.

  • Page 24: Releasing Double Feed Detecting Function

    11.3 Releasing double feed detecting function In case double feed cannot be detected since paper used is too thick (Err3), collation can be continued by canceling double feed detection function. (1) Press [0] key for three seconds ( [ P x ] will be displayed). (2) Press the [MODE] key to display [A xxx] ( xxx represents the current set value).

  • Page 25: Supplementary Explanation Of System Constants By Purpose

    11.5 Supplementary explanation of system constants by purpose Contents The station lamp blinks in red at check (System constant P)........25 Canceling double feed detection (System constant A)..........26 Changing the paper feed wait time at connection of an option (System constant L) of collator ................

  • Page 26: The Station Lamp Blinks In Red At Check (System Constant P)

    Explanation of System Constant Setting by Symptom and Purpose 1. The station lamp blinks in red at check (System constant P) Double feed detection cannot be performed at check. Accordingly, the lamp blinks in red at check when the sensitivity of the paper feed photo sensor does not match the applied paper. The red lamp blinking condition is classified into 2 cases by paper quality and sensor sensitivity.

  • Page 27: Canceling Double Feed Detection (System Constant A)

    2. Canceling double feed detection (System constant A) There is a rare possibility that the sensitivity of the paper feed photo sensor may not be fitted to paper by adjusting the paper feed photo sensor with the system constant P. At this time, cancel double feed detection to attain a paper feed as a temporary measure.

  • Page 28: Changing The Paper Feed Interval Between Stations At Connection With After Processing Machine (System Constant G)

    In such a case, the occurrence of an error may be suppressed by adjusting the system constant n. Indication Operation Remarks Counter Contents of indication 1000 digit － 100 digit Paper ejection response 10 digit Ten-key wait time 1 digit Note: When the system constant L to adjust the paper feed interval is set to a large value, the wait time for the next paper feed (system constant L) may exceed the paper ejection response wait time (system...
  • Page 29 2. Causing the upper-station paper to first come out (*) When the system constant G is set to a larger value than 180, the upper-station paper will first come out. To feed paper to an after processing machine such as booklet maker in which a transfer roller/belt is placed under the paper, use the above setting.

  • Page 30: Adjusting The Paper Feed Timing Between The Left And Right Towers At 2-Tower Connection (System Constant S)

    However, the ejected sheet-to-sheet distance varies greatly depending on the paper feed condition. • Wear of the paper feed roller/separator • Feed paper slip amount • Feed paper collapse amount Due to the above factors, the ejected sheet-to-sheet distance may be different from what is calculated.

  • Page 31: Ejecting Paper To The Left Side Without An External Connector (System Constant J)

    However, the shift amount of paper feed-out timing changes greatly depending on the paper feed condition. Wear of the paper feed roller/separator Feed paper slip amount Feed paper collapse amount Transfer speed difference between the left and right towers Slip at seizure of the connected transfer section Due to the above factors, the shift amount may be different from what is calculated.

  • Page 32: Changing The Error Input Method (System Constant Y-2)

    Note: The error output of the collator is a transistor output. Transistor operation Voltage output Current Remarks Flow A current of up to 50 mA can be caused to flow. OPEN No flow A voltage of up to 30 V can be applied. 9.

  • Page 33: System Constant Table When A Post-Process Machine Is Connected

    11.6 System constant table when a post-process machine is connected (1/2) System Function Initial Foldnak Foldnak PL-61 ST-31 Effect of system constant constant value -2300 2000/ Increasing the Reducing the value 5000 value Paper feed photo sensor P 3or4 Working with thin paper Working with luminous intensity thick paper...
  • Page 34 11.6 System constant table when a post-process machine is connected (2/2) Left-tower paper feed S 170 Making left-tower paper Making left-tower paper interval feed faster at 2-unit feed slower at 2-unit connection connection Unused U 120 –– –– Paper feed photo o 11 Lowering the paper feed Raising the paper feed...

  • Page 35: Troubleshooting

    12. TROUBLESHOOTING 12.1 The power is not supplied. Power plug is disengaged. Insert the plug in the outlet. ↓ Circuit breaker is tripped. Remove the cause and reset the breaker. ↓ Checking of outside conditions Rated voltage cannot be obtained at the outlet. Use another outlet.

  • Page 36: Paper Is Not Fed Though The Check Key Is Pressed (Main Motor Rotates)

    12.3 Paper is not fed though the CHECK key is pressed (Main motor rotates). The station lamp lights green when the paper Adjust the paper switch. feed table is raised with no paper loaded. ↓ Check the working The paper feed clutch does not work when the Refer to “12.8 Paper feed clutch does not status while setting START key is pressed.

  • Page 37: Paper Feed Table Does Not Rise

    12.6 Paper feed table does not rise. Check while the TEST Paper feed table works while the CHECK Check the back door, paper ejection, paper mode is set. key is set. stacking full or paper feed photo sensor. ↓ AC20V cannot be detected between pins 1 The transformer is faulty.

  • Page 38: Paper Feed Roller Does Not Rotate

    12.8 Paper feed roller does not rotate. Check external Paper feed shaft assembly is not set Set the paper feed shaft assembly properly. conditions. firmly at the main body. ↓ Check the status while Paper feed clutch works when the Refer to “12.3 Paper is not fed though the the TEST mode is set.

  • Page 39: Crisscross Does Not Work

    12.9 Crisscross does not work. CRISSCROSS lamp is not lit. Set the crisscross mode ON. Check external ↓ conditions It works if stacking table is removed. Set the stacking table properly. ↓ AC20V cannot be detected between pins 1 and 3 of the operation circuit board The transformer is faulty.

  • Page 40: Station Lamp Lights Red

    12.11 Station lamp lights red. Slip of paper, etc. is caught in the paper feed Remove the paper. photo. Check exterior conditions ↓ Photo-sensor is stained with paper dust. Clean the paper feed photo. ↓ Check the paper feed sensor harness. Voltage between pins 3 and 4 of 4P connector Check the paper feed photo harness.

  • Page 41: Double Feed Frequently Occurs

    12.15 Double feed frequently occurs. Sheets are not neatly set on the paper feed Arrange the sheets neatly. table. ↓ Printed sheets stick to each other. Reset them after loosening. ↓ Ink on the paper is not sufficiently dried. Use the paper after it is sufficiently dried. ↓...

  • Page 42: Empty Feed Or Jam Frequently Occurs

    12.17 Empty feed or jam frequently occurs. Sheets are not neatly set on the paper feed Arrange the sheets neatly. table. ↓ Use the paper after the printing is sufficiently Printing on the paper is not sufficiently dried. dried. ↓ Paper not specified in the specifications is Use paper specified in the specifications.

  • Page 43: Double Feed Lamp Lights Though A Single Sheet Is Fed

    12.19 DOUBLE FEED lamp lights though a single sheet is fed. Try to check again. ↓ Differently printed sheets are mixed in a Use the sheets of same quality in the same one certain station. station. ↓ Sheets printed by different machines are Set the same printed sheet based on the same mixed in a certain station.

  • Page 44: Stacked Paper Is Not Neatly Aligned

    12.21 Stacked paper is not neatly aligned. Guides and pole of the stacking table are not Set the guides, etc. (5 locations) to fit the paper set to fit the paper size. size. ↓ Stacking wire is not installed. Install the stacking wire. ↓...

  • Page 45: Ejected Paper Is Stained

    12.23 Ejected paper is stained. Ink on the paper is not sufficiently dried. Use the paper after the ink is sufficiently dried. ↓ Clean the paper feed roller using alcoholic or Paper feed roller is stained. detergent. ↓ Clean the separator rubber using alcoholic or Separator rubber is stained.
