- Page 1 Hardware Guide Shadow Tracker Premier Advanced Tracking Technologies Inc. © 2002 ATTI All rights reserved...
- Page 2 All rights reserved. No part of this publication may be reproduced or transmitted in any form or by any means without the prior written permission of Advanced Tracking Technologies, Inc. ATTI, Advanced Tracking Technologies, Shadow Tracker, MobilEyes and Time Traveler are trademarks of Advanced Tracking Technologies, Inc., Microsoft, Windows and the Windows logo are registered trademarks of the Microsoft Corporation.
- Page 3 CAUTION: The Shadow Tracker Premier has maximum transmitted output power of 200mW. It is required that the transmit antenna (located inside the Shadow Tracker™ Premier) be kept at least 23 cm away from nearby persons to satisfy FCC RF exposure requirements.
-
Page 5: Table Of Contents
ABLE OF ONTENTS Introduction to MobilEyes ™ Connecting the Unit Mounting and Placement Connecting Power Wiring Instructions Status Indicator Lights GPS Antenna Removing the Unit for Download Other Information Safety and Care Instructions Specifications of Shadow Tracker Premier ™ Trouble Shooting... - Page 6 NTRODUCTION Please read this manual completely before use. Thank you for purchasing Shadow Tracker™, the cornerstone of the MobilEyes ™ vehicle tracking system from Advanced Tracking Technologies, Incorporated. MobilEyes ™ is a unique hardware and software combination, used for the tracking needs of today’s mobile workforce.
- Page 7 NTRODUCTION The Shadow Tracker™ Premier easily installs into a vehicle and use the vehicles electrical system. The unit gathers and stores vital GPS data which is downloaded into the application software providing detailed distance, location and time information necessary for accurately monitoring your mobile staff. Although rare, time may appear distorted while a Shadow Tracker ™...
-
Page 8: Connecting The Unit
ONNECTING THE Mounting and Placement Mounting devices used and the specific placement location of the Shadow Tracker ™ Premier in the vehicle is left to the discretion of the end-user. Note: It is important, when considering the placement location for a unit, to bear in mind that it is required that the transmit antenna (located inside the... -
Page 9: Wiring Instructions
ONNECTING THE UNIT Wiring Instructions The Red wire must be connected to a CONSTANT 12 volt positive power source, it MUST have power even when the vehicle is turned off. The Blue wire should be connected to a switched 12 volt positive power source, it should have power ONLY when the vehicle is running and NOT when the vehicle is turned off. -
Page 10: Gps Antenna
ONNECTING THE UNIT The GPS Antenna active GPS antenna is required, and must be connected to the Shadow Tracker™ Premier for GPS data collection to occur. The antenna can be positioned on the vehicle by either an internal suction mount or external magnetic mount. -
Page 11: Other Information
ONNECTING THE UNIT Other Information The Shadow Tracker™ Premier unit must remain connected to a continuous power supply during vehicle movement for accurate location readings. -
Page 12: Safety And Care Instructions
AFETY AND Safety Do not place where spills can occur on the unit. Do not place the unit near a heating device. Do not place the unit in direct sunlight. Do not subject the unit to electrical shock. Do not pour liquid onto the unit. Do not apply any physical pressure to the unit. -
Page 13: Specifications Of Shadow Tracker ™ Premier
PECIFICATIONS AND EATURES Shadow Tracker™ Premier at a glance Height 1.23 in. Width: 3.50 in. Length: 6.18 in. Weight: Shadow Tracker™:Premier 10.00 oz Magnetic mount antenna for transceiver 12.40 oz GPS Antenna 2.6 oz. Current draw transmitting: 850ma @ 12v Current draw receiving: 200ma @ 12v Allowable voltage range:... -
Page 14: Trouble Shooting
ROUBLE HOOTING Problem Action !Make sure the Unit LED does not connection is made to turn Red or Green. the back of the unit. Check antenna Unit LED will not connection turn green. Unit is Make sure the antenna not receiving GPS cable is not crimped or signal. - Page 15 Revised 09/10/02 - JLanda...
- Page 16 P.O. Box 168 Sugar Land, Texas 77487 Tel: (800) 279-0035 Fax: (713) 353-6050 Www.AdvanTrack.com...
