Industrial Direct Diesel Heater 30KW CT2142
This product is not suitable for primary heating purposes.
Direct-fired
Diesel/Kerosene Heaters
ORIGINAL INSTRUCTIONS
Cannon Tools Limited
Address:20 Station Road, Rowley Regis, West Midlands, B65 0JU.UNITED KINGDOM
SAVE THESE INSTRUCTIONS AND PRECAUTIONS.
READ ALL PRECAUTONS AND INSTRUCTIONS BEFORE USE.
Introduction
Advertisement
Table of Contents
Summary of Contents for Nielsen CT2142
- Page 1 Industrial Direct Diesel Heater 30KW CT2142 This product is not suitable for primary heating purposes. Direct-fired Diesel/Kerosene Heaters ORIGINAL INSTRUCTIONS Cannon Tools Limited Address:20 Station Road, Rowley Regis, West Midlands, B65 0JU.UNITED KINGDOM SAVE THESE INSTRUCTIONS AND PRECAUTIONS. READ ALL PRECAUTONS AND INSTRUCTIONS BEFORE USE.
-
Page 2: Ec Declaration Of Conformity
EC Directive based on its design and type, as brought into circulation by us. In case of alteration of the machine, not agreed upon by us, this declaration will lose its validity. Product description: Industrial Direct Diesel Heater 30KW Model: CT2142 Applicable EC Directives: EC Low Voltage Directive 2014/35/EU... -
Page 3: General Safety Rules
1. General Safety Rules READ INSTRUCTIONS CAREFULLY. READ AND FOLLOW ALL INSTRUCTIONS. PLACE INSTRUCTIONS IN A SAFE PLACE FOR FUTURE REFERENCE. DO NOT ALLOW ANYONE WHO HAS NOT READ THESE INSTRUCTIONS TO ASSEMBLE, LIGHT, ADJUST OR OPERATE THE HEATER. IF THE INFORMATION IN THIS MANUAL IS NOT FOLLOWED EXACTLY, A FIRE OR EXPLOSION MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE. -
Page 4: Product Description
2. Product Description • Diesel or Kerosene direct-fired mobile/portable space heater with open combustion chamber 3. Technical Specifications Model CT2142 Heat Input [kW] * Air Flow Rating [m³/h] Diesel - Fuel Type Kerosene Fuel consumption [Kg/h] Fuel Nozzle Size [gph] 0.80... -
Page 5: Installation Instructions
CT2142 The following accessories are supplied in the shipping carton. Pos. Description Handle Screw 6or8 Spring washer 6or8 Plain washer 6or8 Feet pipe Nut M5 6or8 Nut M12 Wheel Plain washer ø12 Wheel shaft Cotter Fig.2 To assemble the heater, proceed as follows (see Fig. 2): 1、insert the wheel shaft J to the corresponding hole of feet pipe E，insert the cotter K to the... -
Page 6: Instructions For Use
The fuel gauge on top of the tank allows to check fuel level Connect the power cord plug to a 230 V 50 Hz earthed electrical supply system. Earthing is mandatory. Models CT2142: When complete “start-up” above, the power indicator will light, the display window will show the ambient temperature value. -
Page 7: Cleaning, Maintenance And Storage
6.3. Shut-down Move switch to "OFF" (O) position. Unplug the unit when not used for a long time. Never disconnect the heater from mains to stop it while in operation. Always allow the cooling sequence to be completed (BGO1601-50), otherwise the residual heat could damage internal components. - Page 8 Start heater and read air pressure value. If necessary adjust pressure to the correct value turning the adjusting screw (the air vent hole in the adjusting screw middle) clockwise to increase, anticlockwise to decrease the pressure: Model Air Pressure (bar) CT2142 0.31 Fig.6 Electrical Inspect cables, electrical parts and connections.
-
Page 9: Wiring Diagram
8. Wiring Diagram Wiring diagram for CT2142 9. Troubleshooting PROBLEM CAUSE REMEDY Motor does not No power or low voltage Check power line and voltage start Check fuse and replace if necessary Faulty or damaged power cord Check and replace if needed... - Page 10 E1 displayed on the to I screen Call technical service if the problem Reduced airflow persists Overheating Model identifier(s): CT2142 Indirect heating functionality: [no] Direct heat output: 30(kW) Indirect heat output: N/A (kW) Space heating emissions (*) Fuel Select fuel type...
- Page 11 At minimum heat Two or more manual stages, no room temperature [no] control output with mechanic thermostat room temperature control In standby mode [no] with electronic room temperature control [yes] with electronic room temperature control plus day [no] timer with electronic room temperature control plus [no] week timer Other control options (multiple selections possible)
- Page 12 CANNON TOOLS LTD Add: 20 station road, Rowley Regis, west midlands,B65 0JU.U.K. Made in China...
