Bulgin Buccaneer 6000 Series Wiring And Assembly Instructions

Buccaneer 6000 Series
Waterproof Connector
For Power - Thermoplastic Body
Wiring and Assembly instructions
IMPORTANT - PLEASE READ
It is important that these instructions are fully complied with to ensure this product is
completely watertight and electrically safe - IF IN DOUBT CONSULT A QUALIFIED
ELECTRICIAN.
Always wire socket insert to supply, wire plug insert to appliance.
However plug/socket inserts can be fitted into any style of main body to give correct
plug/socket combination for your application.
Do not twist bodies when unmating connector, ensure a linear pull is applied.
Cable Glands
To ensure the correct cable sealing pairs of cable glands and collets are available to
accurately fit cable diameters from 4.0mm up to 10.0mm. It is important to match the
correct gland to the cable used, these are:
Cable diameter
4.0-5.0mm
5.0-7.0mm
7.0-9.0mm
9.0-10.0mm
Ratings
Poles: 2
Current Rating: 16A
Voltage Rating: 277V
Conductor
accommodation: 14-18 AWG 14-18 AWG 18-20 AWG
2
metric equivalents: 2.0-0.75mm
For full technical specification visit: www.elektron-bulgin.com
Gland Colour
Dark Grey
White
Yellow
Light Grey
3 8 16
12A 10A 3A
277V 277V 60V
22-26 AWG
2 2
2.0-0.75mm 0.75-0.5mm 0.33-0.14mm
22
3A
60V
22-26 AWG
2
2
0.33-0.14mm
www.elektron-bulgin.com
bulgin
a brand of Elektron Technology
GB
