ELECTRICAL AND IGNITION

SERVICE CHART

SERVICE CHART
5 to 8 in lbs.
(.6 to .9 N·m)
A
F
24 to 36 in lbs.
(2.7 to 4 N·m)
24 to 36 in lbs.
(2.7 to 4 N·m)
008029
88
100 to 115 ft. lbs.
(136 to 156 N·m)
84 to 106 in lbs.
(9.5 to 12 N·m)
F
120 to 140 in lbs.
(13.5 to 16 N·m)
168 to 192 in lbs.
(19 to 21 N·m)
A
60 to 84 in lbs.
(7 to 9.5 N·m)
IMPORTANT:
DO NOT lubricate TPS
to throttle shaft surface
F
N
F
60 to 84 in lbs.
(7 to 9.5 N·m)
T
24 to 36 in lbs.
(2.7 to 4 N·m)
A
Triple-Guard Grease
B
Gasket Sealing Compound
C
Adhesive 847
D
Moly Lube
E
Red Ultra Lock
F
Blue Nut Lock
N
Starter Bendix Lube
T
Liquid Neoprene
F
