ENGINE MANAGEMENT MODULE (EMM)
INTERNAL SENSORS
INTERNAL SENSORS
Sensor inp uts and inte rnal EMM contro llers are
used to control outboard operation. Use Evinrude
Diagnostics software to troubleshoot the sensors.
Refer to t he EMM Service Code Chart at the
back of this manual for a comp
engine fault codes.
Internal sensors
are NOT serviceable. Re pro-
gramming or replacement ma y be required to
resolve internal EMM issues.
EMM Temperature Sensor
Monitors the temperature of the fuel injector driver
circuits.
If the EMM temperature exceeds 176°F (80°C) or
the circuit fails, the EMM:
Activates S.A.F.E.
Stores service code 25
EMM LED 4: ON (Running)
Engine Monitor TEMP display: ON
If EMM temp erature excee ds 212°F (100 °C) or
the circuit fails, the EMM:
Activates SHUTDOWN
Stores service code 29
EMM LED 4: FLASHING
Engine Monitor TEMP display: FLASHING
The outboard will not restart until
IMPORTANT:
the en gine co ols be low 2 12°F (1 00°C)and the
EMM temperatu re returns to normal.
SHUTDOWN MODE on p. 62.
If EMM temperature is less tha n -22°F (-30°C) or
the circuit fails, the EMM:
Stores service code 24
EMM LED 3: OFF (Cranking)
EMM LED 3: ON (Running)
56
If sensor read s less than
greater than 313 °F (156°C), a senso r circuit fault
is detected and the EMM:
Stores service code 23
EMM LED 3: OFF (Cranking)
EMM LED 3: ON (Running)
lete list of all
55 V Circuit Sensor
Monitors the EMM's 55 V alternator circuit.
If system voltage exceeds 57 volts, the EMM:
Activates S.A.F.E.
Stores service code 18
EMM LED 1: ON (Running)
Engine Monitor CHECK ENGINE display: ON
If system voltage is less than 45 V, the EMM:
Activates S.A.F.E.
Stores service code 17
EMM LED 1: ON (Running)
Engine Monitor CHECK ENGINE display: ON
12 V Circuit Sensor
Monitors the EMM's 12 V alternator circuit.
If battery voltage exceeds 15.5 volts, the EMM:
Stores service code 27
EMM LED 1: ON (Running)
Engine Monitor LOW BATTERY display: ON
If battery voltage is less than 12.5 V, the EMM:
Re fer to
Stores service code 26
EMM LED 1: ON (Running)
Engine Monitor LOW BATTERY display: ON
-71°F (-57 .4°C) or
