EMM INPUTS AND OUTPUTS DIAGRAM
9
8
A B
1 2
+
2
30
40
20
50
10
0
x 100
RPM
3550
M E N U
14
15
1. Engine Management Module (EMM)
2. Battery (12 volt)
3. Stator
4. Crankshaft Position Sensor (CPS)
5. Throttle Position Sensor (TPS)
6. Neutral Switch
7
A B
INPUTS
J1-A
J1-B
J2
OUTPUTS
60
70
13
7. Low Oil Switch
8. Air Temperature Sensor (AT)
9. Engine Temperature Sensor
10. Fuel Pump (high pressure)
11. Oil Injection Pump and Manifold
12. Ignition Coil
ENGINE MANAGEMENT MODULE (EMM)
EMM INPUTS AND OUTPUTS DIAGRAM
4
3
1
2
3
4
1
18
12
16
13. Fuel Injector
14. Tachometer/SystemCheck Gauge
15. I-Command (CANbus) Display
16. Diagnostic Connector
17. LED Indicators
18. Exhaust Water Valve (60–65 HP)
5
6
1
2
1
2
17
2 1
11
10
008026
4
55
