ENGINE COVER SERVICE
LOWER COVER SERVICE

Latch Handle Installation

Apply a light coat of Triple-Guard grease to latch
handle shaft. Insert handle into lower cover.
1. Triple-Guard grease
Apply Ultra-Lock to sc rew threa ds. Pl ace spring
washer and ho ok in to positio n and tig hten screw
to a torque of 180 in. lbs. (20 N·m).
2
1
1. Spring washer
2. Hook
3. Screw
52

Trim Switch Installation

Place switch into position through cover.
1
006470
Install nut on switch. Tighten nut to a torque of 10
to 16 in. lbs. (1 to 2 N·m).
3
Install electrical connector. Refer to CONNECTOR
006471
SERVICING on p. 116.
006746
006747
006748
