ENGINE COVER SERVICE

UPPER COVER SERVICE

UPPER COVER SERVICE

Latch Hook Installation

Insert threaded bracket into pocket.
1
1. Bracket
Apply Ultra-Lock t o screw thre ads. Place hoo k
into position with opening toward the front. Tighten
screws to a torque of 60 to 84 in. lbs. (7 to 9.5
N·m).
50

LOWER COVER SERVICE

Lower Cover Removal

Remove lower engine cover screws.
1
006468
1. Lower cover screws
Loosen port side cover
trim/tilt switch conn ector. Then, remove po rt and
starboard covers.
006469
1. Trim/tilt switch connector
002168
slightly, and disconnect
002169
1
1
